PC-482VN series
Embedded STPC ATLAS 5x86DX2-133
PC/104 CPU Module with on-board
VGA/LAN/CF/TFT LCD interface
and
General Purpose I/O channels
Copy Right Notice
The information in this manual is subject to change without prior notice in order t o improve
reliability ,design and function and dosed not represent a commitment on the part of the
manufacturer. No part of this manual may be reproduced, copied, or transmitted in any
form without the prior written permission of manufacturer.
Acknowledgment
Products mentioned in this manual are mentioned for identification purpose only. Products
manes appearing in this manual may or may not be registered trademarks or copyright of
their respective companies
Edition: 1.02
Printed July. 2003
http:/www.inlog.com.tw
1
2
Advertisement
Table of Contents
Related Manuals for Inlog PC-482VN Series
Summary of Contents for Inlog PC-482VN Series
- Page 1 PC-482VN series Embedded STPC ATLAS 5x86DX2-133 PC/104 CPU Module with on-board VGA/LAN/CF/TFT LCD interface General Purpose I/O channels Copy Right Notice The information in this manual is subject to change without prior notice in order t o improve reliability ,design and function and dosed not represent a commitment on the part of the manufacturer.
-
Page 2: Table Of Contents
Table of contents Chapter 4 VGA BIOS Setup........28 Chapter 1 Introduction Hardware installation......5 4.1.1 Chipset 29 1.1 Introductions 4.1.2 Display memory..............29 1.2 Packing list 4.1.3 Flat Panel BIOS and Utility ..........29 1.3 Specifications Appendix A Chapter 2 Flash Disk Setup & EEPROM R/W..30 Jumper settings ........9 Appendix B Locating jumpers... -
Page 3: Hardware Installation
Hardware installation Hardware installation Chapter 1 Introductions The PC-482VN is a full-function PC/104 CPU Module which integrates the VGA/TFT Hardware installation LCD panel, CompactFlash,GPIO,Ethernet(PC-482VN Only) and other enhanced I/O interfaces on a PC/104 CPU Module. This Module uses an embedded SGS-THOMSON STPC ATLAS Pentium performance x86-133 low power CPU and embedded 32MB SDRAM on board The PC-482VN offers power management to minimize power consumption. -
Page 4: Specifications
Hardware installation Hardware installation Specifications CompactFlash Slot: One Fully IDE CompactFlash Type I/II Compatibility Slot and Support +5VDC or +3.3VDC IDE CompactFlash Card. (CF for PC-482VN only) System Chipset : Serial Ports: The STPC ATLAS chipset integrates a fully static x86-133MHz low power processor, Three RS-232C and One RS-232/422/485 serial Ports. -
Page 5: Jumper Settings
Jumper settings Jumper settings Chapter 2 Locating jumpers Jumper settings... -
Page 6: Compactflash Slot On Solder Side
Jumper settings Jumper settings CompactFlash Slot on solder side Jumper Setting The PC-482VN has a number of jumper that allow you to configure your system to suit your application. The table below lists thefunction of each of the board’s jumper: Label Function COM1 RS-232/422/485 selection... -
Page 7: Com1 Rs-232/Rs-422/Rs-485 Selection ( Jp1 )
Jumper settings Connecting Peripherals 2.3.1 Chapter 3 COM1 RS-232/RS-422/RS-485 Selection ( JP1 ) The COM1 port can be selected as RS-232, RS-422 or RS-485 by Connecting Peripherals setting JP1. The following chart shows the jumper setting. COM1 Type ALL OPEN for RS-232C (Default) ALL CLOSED for RS-422/485... -
Page 8: Locating Connectors
Connecting Peripherals Connecting Peripherals Locating Connectors Connectors Summary On-module connectors link the PC-482VN to external devices such as hard disk drives, a keyboard, or floppy drives. The table below lists the function of each of the board’s connectors: Label Function Page CRT Display connector 3.12... -
Page 9: Hardware Reset Switch (Cn3)
Connecting Peripherals Connecting Peripherals Hardware reset switch (CN3) Floppy drive connector (CN2) The hardware reset switch button is an active low signal (24 mA sink rate). You can attach up to two floppy drives to the PC-482VN’s on-board controller. You can use any combination of 5.25”... -
Page 10: Ide Hard Drive Connector (Cn9)
Connecting Peripherals Connecting Peripherals IDE Hard Drive Connector (CN9) Parallel port connector (CN5) Normally, the parallel port is used to connect the card to a printer. The PC-482VN includes Connect one end of the cable to CN9. Make sure that the red (or blue) wire corresponds a multi-mode (ECP/EPP/SPP) parallel port, accessed through CN5, a 26-pin flat-cable to pin 1 on the connector, which is labeled on the board (on the right side). -
Page 11: Serial Port Connectors (Cn10, Cn8)
Connecting Peripherals Connecting Peripherals Serial port connectors (CN10, CN8) 3.10 General Purpose I/O Connector(GPIO) (CN6) The PC-482VN are supported 16C550 compatible UARTs with 16 byte FIFOs Provide 16 channels General Purpose I/O Serial Port-1(COM1) RS-232/422/485 Connector ( CN10 ) Each channel can be software programmed to input or output Individual software programmable interrupt mask. -
Page 12: Cpld Connector (Cn4)
Connecting Peripherals Connecting Peripherals 3.11 CPLD Connector (CN4) 3.13 Flat panel display connector (CN11) CN11 is a 20*2-pin connector which can support a 9/12/18bit 640*480 or 800x600 TFT LCD.It is recommended that the LCD bias voltage not be applied to the panel until the logic Signal supply voltage (+5 V) and panel video signals are stable.Pin assignments for connector CN11 are detailed in... -
Page 13: Usb1 & Usb2 Connector (Cn12)
Connecting Peripherals Connecting Peripherals 3.14 USB1 & USB2 connector (CN12) 3.17 External “+12VDC / +5VDC” power input connector (CN16) The connector CN12 is 8 pins header for USB1 and USB2 port The connector CN16 is four pins +12V/GND/+5VDC power input connector USB-1 USB-2 Signal... -
Page 14: Compactflash Slot (Cn18)
Flash Disk Setup & EEPROM R/W Connecting Peripherals Chapter 4 3.19 CompactFlash Slot (CN18) The PC-482VN is equipped with a CompactFlash type I/II Slot on the solder side, which VGA BIOS Setup supports at the secondary master IDE interface CompactFlash card and on-board +5VDC to +3.3VDV regulator. -
Page 15: Introduction
Flash Disk Setup & EEPROM R/W Flash Disk Setup & EEPROM R/W Appendix A Introduction The PC-482VN has an on-board flat panel/VGA interface. The specifications and Flash Disk Setup & features are described as follows: EEPROM R/W 4.1.1 Chipset The PC-482VN uses a STPC Atals chipset for its SVGA controller. Display Type Supports CRT and TFT LCDs. - Page 16 Flash Disk Setup & EEPROM R/W Flash Disk Setup & EEPROM R/W How to use EEPROM About solid state disk The PC-482VN provide a EEPROM for backup system configures and reserved 240 The PC-482VN provides one extended solid state disk sockets (M1) which can accept words for user R/W through the software interrupt vector by System BIOS setup...
- Page 17 Programming Watch dog timer Programming Watch dog timer Appendix B The following steps show how to program the watchdog timer you must write a program which write I/O port address 543(hex) to write timeout value(0-255 sec) to Watchdog REG. and reads I/O port address 443 (hex) to enable Programming Watch dog watch-dog timer.
- Page 18 Award BIOS Setup Award BIOS Setup Appendix C Starting Setup The Award BIOS is immediately activated when you first power on the computer. The BIOS reads the system information contained in the CMOS and begins the process of Award BIOS Setup checking out the system and configuring it.
- Page 19 Award BIOS Setup Award BIOS Setup C.3.6 Power Management Setup Main Menu This entry only appears if your system supports Power Management, “Green PC”, Once you enter the System BIOS CMOS Setup Utility, the Main Menu will appear on the standards.
- Page 20 Award BIOS Setup Award BIOS Setup Standard CMOS Features Advanced BIOS Features The items in Standard CMOS Setup Menu are divided into 10 categories. Each category This section allows you to configure your system for basic operation. You have the includes no, one or more than one setup items.
- Page 21 Award BIOS Setup Award BIOS Setup C.5.3 PCI / VGA Palette Snoop Advanced Chipset Features Setup It determines whether the MPEG ISA/VESA VGA Cards can work with PCI/VGA or not. This section allows you to configure the system based on the specific features of the installed chipset.
- Page 22 Award BIOS Setup Award BIOS Setup C.6.7 User Define 1 C.6.3 ISA Clock This item allows you to select the ISA clock type. This item is reserved for user define and read from CMOS RAM address 5Eh (bit-4) 14.3MHz / 2 System clock type Enabled CMOS RAM Address 5Eh (bit-4) = 0...
- Page 23 Award BIOS Setup Award BIOS Setup Integrated Peripherals PnP/PCI Configuration Setup C.10 Load Optimized Defaults When you press <Enter> on this item you get a confirmation dialog box Power Management Setup with a message similar to: Load Optimized Defaults (Y/N) ? N Pressing ‘Y’...
- Page 24 Programer’s Reference Programer’s Reference Appendix D How to use this driver The PC-482 driver is Called by software interrupts INT 6Fh, 7Fh, 8Fh, 9Fh, AFh, BFH, CFh, DFh or EFh and selected by Award BIOS setup “Advanced Chipset--> Function Programer’s Reference Call Entry:”...
- Page 25 Programer’s Reference Programer’s Reference (AL) = 01h - Read GPIO input port (AL) = 05h - Set GPIO Interrupt Number (IRQ) (DL) - Port Number (DL) - Interrupt Number (IRQ 1-15) = 0 - Port-0 ( Channels 7-0 ) bit(7) –...
- Page 26 Programer’s Reference System configuration Appendix E (AL) = 02h - Enabled Watch-dog and Refresh Cycle System configuration On Return: none (AL) = 03h - Disabled Watch-dog Reset On Return: none (AH) = 04h PassWord (AL) = 00h - Set PassWord (DX,BX) - Password On Return: none...
- Page 27 System configuration System configuration DMA channel assignments System I/O ports Addr. range (Hex) Device Channel Function 000-01F DMA controller Available 020-021 Interrupt controller 1, master Available 040-05F 8254 timer Floppy disk (8-bit transfer) 060-06F 8042 (keyboard controller) Available (Parallel Port) 070-07F Real-time clock, (NMI) mask Cascade for DMA controller 1...
- Page 28 System configuration System configuration...
