Summary of Contents for Italiana Camini TEKNO 1 UP
- Page 1 ® TEKNO 1 UP WOOD-BURNING FIREPLACE EN Installation, use and maintenance page 2...
-
Page 2: Table Of Contents
Regulation 305/2011 and the harmonised EU standard Standard EN 13229:2001+A1:2003+A2:2004+AC:20 06+AC:2007 WOOD-BURINING FIREPLACE, bearing the brand ITALIANA CAMINI called TEKNO 1 UP SERIAL NO.: Rating plate reference Performance declaration: (DoP No. EK 163): Rating plate reference The liability of the Manufacturer is limited to the supply... -
Page 3: Introduction
Dear Sir/Madam The product is uniquely identified by a number, the We thank you for and congratulate you on choosing our “counterfoil”, which is indicated on the warranty certificate. product. Before using it, we ask you to read this manual carefully, in order for you to be able to make the most of all Please keep: its functions in total safety. -
Page 4: Safety Information
SAFETY INFORMATION ® WHILE IT IS HOT. Risk of damage to the • The product is not designed for use by cleaner and smoke in the room. people, including children, with limited • cleaning the fumes duct with various physical, sensory and mental abilities. substances. -
Page 5: Technical Data
TECHNICAL CHARACTERISTICS in accordance with EN 13229 The above data is for guidance only and was taken during the certification phase by a notified body under the conditions specified by the standard. TEKNO 1 UP Nominal power Available power 15,3... -
Page 6: Dimensions
DIMENSIONS ® TEKNO 1 UP dimensions in cm - combustion chamber dimensions cm 78 x 48 x 53 (h) - glass dimensions cm 67x45h smoke outlet Ø 20 cm. rear hot air outlet diameter 14 cm Use two of the four air vents according to... -
Page 7: Installation
INSTALLATION ® PREPARATION AND UNPACKING The packaging materials are neither toxic nor noxious and do not require special disposal. The user is responsible for storing, disposing of and recycling them in a regulatory fashion. Always move the stove vertically with suitable equipment and in compliance with safety regulations. Do not turn the package over, and handle all parts requiring installation with care. - Page 8 INSTALLATION ® TO REMOVE THE PRODUCT FROM THE PALLET Remove the brackets securing the product to the pallet. Remove the product from the pallet, taking special care to protect the door and its glass pane from impact. brackets securing the product to the pallet.
- Page 9 INSTALLATION ® PACKAGING The packaging can provide a useful indication of the product’s condition. Check the packaging on receipt and report any anomalies to the reseller straight away. The packaging consists of a single pack with the contents as below. Description Number in Quantity...
- Page 10 INSTALLATION ® * Remove the screws on the side elements BEFORE raising the door There are some information stickers on the product. WOOD FENDERS The wood fenders are secured by snap fastening to the hearth. The bar is snap fastened onto the wood fenders...
- Page 11 INSTALLATION ® SMOKE BAFFLE Single unit equipped with a smoke baffle inside the hood above exchanger pipe. Adjust the smoke baffle in order to balance the chimney draught as shown in the figure below. Wide baffle (B) “reducing smoke outflow Retracted baffle (B) “increasing smoke section”...
- Page 12 INSTALLATION ® REMARKS ON INSTALLATION FLUE SYSTEM Note that: (Fumes duct, flue and chimney pot) • the appliance must be installed by authorised This chapter has been drawn up pursuant to European technical personnel regulations EN 13384, EN 1443, EN 1856 and EN •...
- Page 13 Il tubo di alluminio Ø20 può essere posizionato indipendentemente destra o a sinistra del meccanismo di regolazione. INSTALLATION ® È consigliabile applicare all'esterno del THE FUMES DUCT EXTERNAL AIR INTAKE condotto presa aria una griglia di prote- • if it is metal, it must have CE marking (EN 1856-2) or The connection to the outside with a section of 300 cm zione che comunque non deve ridurre la some similar national standard marking;...
- Page 14 INSTALLATION ® AIR BOX In order to understand the installation procedures indicated below, we now mention the operation of the air box found under the product. The air is drawn from outside and mixed with the inside air via a mechanism with a wired control. In the version with natural convection, the box (4) is not equipped with a fan (V), the regulator and the probe trigger the control (4c) - pulled knob - and the outside air reaches the inside of the connector (4b) where it is mixed with air drawn in from the room through the opening (4e).
- Page 15 INSTALLATION ® Natural convection functioning In the natural convection model, box (4) is not equipped with fans (12), electronic switch (13) and bulb-shaped thermostat (14). Triggering control (4c) – pulled knob – outside air reaches the internal fitting (4b), mixing with the room air intake throughout the opening (4e).
- Page 16 Deflettore (B) rie Deflettore (B) esteso “riduce la la sezione passa sezione passaggio fumi” e quindi terminal Italiana Camini non risponde di quindi il tiraggio il tiraggio della canna fumaria board M Ventilatore fumaria conseguenza degli oneri derivati...
- Page 17 INSTALLATION ® INSTALLATION AND CONNECTION OF FAN COMPONENTS (Version V) Regulator connections In order to install correctly, remove the power supply; undo the screw and lift off the cap. Fix the base to the wall through the special holes, perform the electrical connections as per the diagram, put the cap back on the base and then close the device, by putting the screw back on.
- Page 18 INSTALLATION ® Facings, gather hood and vents Carry out all the finishing operations, Face the product only after having completed the for example the gather hood, the following steps: cladding etc. only after the tests • connecting the product to the smoke outlet and have been completed successfully air intake;...
-
Page 19: User Instructions
USER INSTRUCTIONS ® OPENING DOOR WITH HINGED LEVER FOR LOCKING/UNLOCKING THE DOOR MOVEMENT To open the door in the hinged-type mode: - move the lever (L) fully to the right so as to lock the sliding movement (1) Per l’apertura ad anta, usare la chiave a brugola in dotazione: LOCKED UNLOCKED OPENING... - Page 20 USER INSTRUCTIONS ® AIR LIMITATION Tekno2 Up has two types of regulation: • one for regulating the combustion air flow • one for regulating the post-combustion air flow To increase or reduce the air intake, move the levers according to the instructions below. Ignition/Maximum power Ember maintenance...
- Page 21 USER INSTRUCTIONS ® FUEL Ignition with the combustion chamber The product is designed for burning wood pellets or cold. logs. Use dry wood logs (max. 20% humidity) 1. Check that the existing ash bed is not too high. If the Using damp wood will make the product and flue dirty, ash bed becomes too high there is a danger that hot risk the release of smoke and provide a lower heat...
- Page 22 USER INSTRUCTIONS ® OPERATION OF THE ELECTRONIC REGULATOR AUTO MAN OFF ON OPERATION OF THE ELECTRONIC REGULATOR Automatic use: Set the two switches to the “ON” and “AUTO” position. When the probe detects a temperature of about 50°C, the fan comes on and runs at the speed set on the regulator knob.
-
Page 23: Maintenance
MAINTENANCE ® Cleaning the glass Cleaning the outside of the stove Do not use aggressive detergents to clean the outside Use specific products for cleaning the door glass (see of the stove. our Glasskamin price list). Do not use cold water to clean the stove when it is hot; Do not spray the product onto the painted areas or doing so can damage it. -
Page 24: Troubleshooting
TROUBLESHOOTING ® TROUBLESHOOTING DISPOSAL At the end of its service life, dispose of the product as 1) If smoke comes out of the combustion required by regulations. chamber opening, check whether: The installation is correct (smoke duct, flue, chimney pot; air intake). The wood being used is dry. - Page 28 *941947-GB* ® cod. 941947-GB 07.18/A...
