Summary of Contents for ROADWORX Lighting Stand 1
- Page 1 Lighting Stand 1 Lighting Stand...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 04.12.2023, ID: 442430 (V2)
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features................................9 Operation..............................10 Technical specifications........................15 Protecting the environment......................17 Lighting Stand 1 Lighting Stand... - Page 4 Lighting Stand 1 Lighting Stand...
-
Page 5: General Information
Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. Lighting Stand 1 Lighting Stand... - Page 6 This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – danger zone. Lighting Stand 1 Lighting Stand...
-
Page 7: Safety Instructions
Risk of injury due to tipping of the stand during loaded transport! If the stand is moved without having removed the installed devices, the stand may tip over and cause injuries and property damage. Remove the installed devices before transporting the stand. Lighting Stand 1 Lighting Stand... - Page 8 The plasticiser contained in the rubber feet of this product may react with the coating of the floor and cause permanent dark stains after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and the floor. Lighting Stand 1 Lighting Stand...
-
Page 9: Features
Metal construction with crossbar for up to four spotlights Extension tubes secured by spring lock buttons Crossbar mounting Single truss: 1.20 m Maximum weight-bearing capacity: 20 kg Minimum height: 1.45 m Maximum height: 3.25 m Weight: 4.5 kg Lighting Stand 1 Lighting Stand... -
Page 10: Operation
Risk of injury due to tipping of stand on an unsuitable ground! When the stand is installed on soft or uneven ground, the stand may tip over and cause injuries and property damage. Install the stand only on even and solid ground. Lighting Stand 1 Lighting Stand... - Page 11 The plasticiser contained in the rubber feet of this product may react with the coating of the floor and cause permanent dark stains after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and the floor. Lighting Stand 1 Lighting Stand...
- Page 12 Operation Comply with regulations When installing and operating, make sure to follow the standards and regulations that apply in your country. Lighting Stand 1 Lighting Stand...
- Page 13 Fix the position of the lower extension tube with the safety screw on the lower tube clamp. Attach up to four spotlights to the crossbar. Observe the instructions of the respective manufacturers. The maximum load capacity of 20 kg in total must not be exceeded. Lighting Stand 1 Lighting Stand...
- Page 14 Loosen the safety screw on the carriage to which the three feet are attached. Fold up the feet of the stand. Pack the individual parts of the system in their original packaging if possible, and store the package in a dry place protected against moisture. Lighting Stand 1 Lighting Stand...
-
Page 15: Technical Specifications
Mounting slots Holder type Æ 35 mm tube end Load, max. (with centric load) 20 kg Transport dimensions (W × H × D) 200 mm × 1220 mm × 140 mm Weight 4.5 kg Colour black Lighting Stand 1 Lighting Stand... - Page 16 Technical specifications Further information Stand type Lighting stand Incl. crossbar Crank Incl. T bar Incl. screws for lamp attachment Lighting Stand 1 Lighting Stand...
-
Page 17: Protecting The Environment
Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling. Please follow the instructions and markings on the packaging. Observe the disposal note regarding documentation in France. Lighting Stand 1 Lighting Stand... - Page 18 Notes Lighting Stand 1 Lighting Stand...
- Page 20 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
