Solid SmartScan50 Application Note

Volume and custom flume configuration

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Volume and Custom Flume

This document contains proprietary information that is the sole property of Solid Applied

Technologies Ltd. The document is submitted to the recipient for his use only. By receiving

this document; the recipient undertakes not to duplicate or to disclose, in part or the

whole, any of the information contained herein; to any third party; without a-priory

written permission from Solid Applied Technologies Ltd.

________________________________________1 of 13 _____________________________________

Solid Applied Technologies Ltd.

40, Hutzot Hayozer,

Ashkelon 78170, Israel

Application Note

SmartScan50

Configuration

Version 1.1

June 2011

www.solidAT.com

info@solidAT.com

Tel: +972 (8) 674 4051

Table of Contents

Need help?

Do you have a question about the SmartScan50 and is the answer not in the manual?

Questions and answers

Summary of Contents for Solid SmartScan50

Page 1 Version 1.1 June 2011 This document contains proprietary information that is the sole property of Solid Applied Technologies Ltd. The document is submitted to the recipient for his use only. By receiving this document; the recipient undertakes not to duplicate or to disclose, in part or the whole, any of the information contained herein;...
Page 2: Table Of Contents
8. WEIGHT CALCULATIONS ........................9 9. FLOW MEASUREMENT OF CUSTOM FLUME ..................10 10. LOOP-CURRENT CONFIGURATION FOR CUSTOM FLUMES ..............12 APPENDIX A: VOLUME CALCULATIONS ....................13 ________________________________________2 of 13 _____________________________________ Solid Applied Technologies Ltd. www.solidAT.com 40, Hutzot Hayozer, info@solidAT.com Ashkelon 78170, Israel...
Page 3: Scope
For VOLUME, the user should configure SmartScan50 to map between LEVEL and VOLUME. SmartScan50 provides for a mapping table (also known as strapping table) of up to 24 points. The user enters a minimum of 8 points and for each point the user defines LEVEL and corresponding VOLUME.
Page 4 6. The thickness of the “slices” does not need to be equal. On the contrary, for different vessel shapes it is reasonable to define thinner slices where the volume does not increase linearly. 7. Minimum of 8 strapping points is required. ________________________________________4 of 13 _____________________________________ Solid Applied Technologies Ltd. www.solidAT.com 40, Hutzot Hayozer, info@solidAT.com...
Page 5: Manual Insertion Of Strapping Table
• enters the corresponding VOLUME value. Loop current values 4-20mA are set after strapping table is configured. SmartScan50 is ready for volume measurement after exiting the configuration menu. Important notes: It is recommended to map vessel interferences using Scan Distance option. Refer to the User Manual of SmartScan for details.
Page 6: Semi-Automatic Insertion Of The Strapping Table
When entering Pr.1, SmartScan50 will prompt with the first point, P1. For each point the user should define the required LEVEL and corresponding VOLUME. For example, for the vessel discussed above: P1 <Ent> Level: 001.000 <Ent> Volume, first screen: 001200 <Ent>...
Page 7 The procedure for semi-automatic insertion of mapping table is as follows: 1. Start with an almost empty vessel or at the first point where the contained volume is known. 2. In semi-automatic mode, the level is measured and calculated automatically by SmartScan50. Accept the display level by pressing <Ent>.
Page 8: Loop-Current Configuration For Volume
Pressing <Esc> after the eighth point indicates that point eight is the last point in the strapping table. 6. LOOP-CURRENT CONFIGURATION FOR VOLUME Once the user configures SmartScan50 to volume and sets the strapping table points, it is possible to configure 4mA and 20mA parameters to represent volume values.
Page 9: Configuring Special Vessel Shapes
Important note: It is recommended to use all 24 strapping table points for better accuracy. 8. WEIGHT CALCULATIONS ________________________________________9 of 13 _____________________________________ Solid Applied Technologies Ltd. www.solidAT.com 40, Hutzot Hayozer, info@solidAT.com...
Page 10: Flow Measurement Of Custom Flume
When custom flume measurements are required, the user should configure SmartScan50 to map between FLOW and corresponding LEVEL. SmartScan50 provides for a 24 point mapping table (also known as strapping table). For each point the user should define the level and the corresponding flow for this level. The drawing below illustrates the LEVEL to FLOW mapping.
Page 11 5. A minimum of 8 strapping points is required. 6. No LEVEL value should be greater than TOTAL HEIGHT. ________________________________________11 of 13 _____________________________________ Solid Applied Technologies Ltd. www.solidAT.com 40, Hutzot Hayozer, info@solidAT.com...
Page 12: Loop-Current Configuration For Custom Flumes
The device is ready for custom flume measurement after exit from the configuration menu. 10. LOOP-CURRENT CONFIGURATION FOR CUSTOM FLUMES Once the user configures the SmartScan50 to custom flume and sets the strapping table points, it is possible to configure 4mA and 20mA parameters for FLOW values.
Page 13: Appendix A: Volume Calculations
Using the equations, it is easy to calculate the height-to-volume mapping. For example, assume a cylinder shaped vessel with 2-meter radius and 8 meter height. The following table defines the height- to-volume mapping: ________________________________________13 of 13 _____________________________________ Solid Applied Technologies Ltd. www.solidAT.com 40, Hutzot Hayozer, info@solidAT.com...
