Lumena MINILITE LCBR-MLB12P Instructions

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE

SPECIFICATIONS

Voltage: 12v (low voltage)
Max Wattage: 20W
Bulb Holder: MR11 (lamp sold separately)
IP Rating: IP54 (Connector IP44)
Cable Type: 0.75mm 2 Core H05RN-F (VERSA Plug & Play)
Cable Length: Approx. 5m
Materials: Solid Brass / Toughened Glass
Finish: Rustic Bronze
Lens: Glass (Convex) with Glare Shield
Weight: 0.70KG (approx.)
Adjustable: Yes (serrated clamp joint)
Mounting Thread: 21mm
Transformer Required: 12v AC (wattage dependent on total wattage of circuit)
Mounts & Accessories Available: Ground Spike, Surface Mount, Tree Bracket,
Wall Mount, Extension Poles (all sold separately)
•
This is a Class 3 product (Low Voltage) – no earth required.
•
12V TRANSFORMER REQUIRED – sold separately
•
Always use the correct type and wattage of 12v transformer.
•
This unit must be fitted by a competent person – if in doubt consult a qualified electrician.
•
To prevent electrocution, switch off mains supply before installing or maintaining this fitting. Ensure other persons cannot restore
the electrical supply without your knowledge.
•
This light fitting should be connected to a circuit with a 30Ma RCD fitted. Maximum 12-15 fittings on each circuit recommended.
•
If replacing an existing fitting, make a careful note of the connections.
•
All connections should be made as watertight as possible to avoid electrical shortage.
•
Always switch off at the mains & allow the fitting to cool before commencing any electrical work or changing the bulb.
•
Always use the correct type & wattage bulb. Never exceed the wattage stated.
•
The unit may get warm whilst on for a period of time.
•
If the luminaire or cable is found to be damaged, cease use immediately.

CLEANING:

Occasional cleaning and care are recommended for this product. Wipe with a soft, slightly damp cloth to remove any surface
dirt. Do not use abrasive cleaners or a lot of water as this could damage the fitting. Please refer to our website for more
information on the best way to clean different materials.
RETURNS & DISPOSAL: (
rd
If purchased from a 3
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or contact us
for more information. Please recycle packaging wherever possible.
MINILITE Mini Spotlight Brass 12v Plug and Play
THANK YOU FOR YOUR PURCHASE
Our full returns policy is available on our website)
party, please contact your supplier. If purchased direct, contact us by phone or email:
Full product range & more information: www.lumenalights.com
82mm – 117mm
52mm

WARNINGS

Tel: +44 1327 871161
Producer Registration Number: WEE/KC3440XY
INSTRUCTIONS
(LCBR-MLB12P)
60mm
31mm – 72mm
Email: sales@lumenalights.com
✔✔
2 YEAR
GUARANTEE
UK - see website
for more details
