APRILIA
INSTRUCTION
MANUAL
NO.3088-24V BRUSHLESS

Advertisement

loading

Summary of Contents for APRILIA 3088

  • Page 1 APRILIA INSTRUCTION MANUAL NO.3088-24V BRUSHLESS...
  • Page 2 If you have a future motorcycle rider in your life, we have the most amazing gift for you. This is a kids electric ride-on motorcycle. It is aprilia motorcycle miniature. It is ideal option for your little kids to ride on.
  • Page 3 Please charge for 12 hours before initial use. After initial charge follow the charging time on the specifica- tions.
  • Page 4 SAFETY This vehicle must be assembled by an adult who has read and understood the instructions in this manual. Keep the packaging and bags away from children and dispose of all packag- ing before use. Always use common sense and safe practices when operating this vehicle.

  • Page 5: Specifications

    SPECIFICATIONS The data below are for all products in the 3088 series. For reference only. Exact specifications are subject to the purchase page. Weight Capacity 150LBS Age Range 4-10 years old Max Speed 2.5-16MPH Charging Time 8-12hours Run Time 1-3hours...

  • Page 6: Tools Required

    WARNING WARNING ADULT ASSEMBLY REQUIRED CHOKING HAZARD - SMALL PARTS. NOT FOR CHILDREN UNDER 3 YEARS OLD. TOOLS REQUIRED Metal Wrenches 150LBS APPROXIMATELY 150 LBSCAPACITY 45 MIN. 1 PC ASSEMBLY HARDWARE Long Screw Washers Short Screw Nuts (Training Wheels) 4 PCS 3 PCS 14 PCS 3 PCS...
  • Page 7 PARTS Front Wheel Lock Front Fork Front Mudguard 2 PCS 1 PC 1 PC Front Axle Handlebar Side Mirrors 1 PC 1 PC 2 PCS Front Frame Side Leaf-plates Tail-light 1 PC 2 PCS 1 PC Seat Plastic Cap 1 PC 1 PC...

  • Page 8: Product Assembly

    PRODUCT ASSEMBLY Flip vehicle over and lay it on a level surface. Remove all parts and packaging from the vehicle body. Connect the right-foot pedal brake cable.Insert the [2 Foot Pedals] on both sides into the vehicle body(Align with the slot and snap it tight. Moreover take care to hide the extra length of wire in the harness hole).
  • Page 9 Beside the foot pedal, align the [Training Wheels] with the slot.Fixed with 3-long screws and 4-short screws.
  • Page 10 Slide the [Front Fork] into the [Front Wheel Lock]. Then snap onto the [Front Wheel].
  • Page 11 4.Insert the [Front Axle] into the front wheel and secure it with 2 nuts and 2 spacers/washers. Slide the [Front Mudguard] into the front fork.
  • Page 12 Insert the already assembled front wheel set into the vehicle body. Connect the accelerator power wire(Take care to hide the extra length of wire in the harness hole). Then slide the [Handlebar] into the front-fork axle and put in 2 spacers/washers and 1 nut to secure them.
  • Page 13 Attach [2 Side Mirrors] with 2 screws to [Front Frame], 1 screw per mirror. Mounting the front frame set to the vehicle body with 4 screws. And connect the light power wire (Take care to hide the extra length of wire in the harness hole).
  • Page 14 Connect the motorcycle power cord. And test the power cord connection for proper operation. ATTENTION 1.Please connect picture 1,the power connec- 1: After charging,please unplug the charger tor before assembling the seat.Then usinng first.Then usinng the key start switch to turn the key start switch to turn on the vehicle.
  • Page 15 Test the power cord is connected properly and then install the [Seat] with 2 screws. Then attach the [Tail-light] with 2 screws.Finally install the [2 Side Leaf-plates].
  • Page 16 DASHBOARD DIAGRAM Push down on the pedal to drive forward/reverse. Release the pedal to slow down and stop. Power Key Forward/Pause Low/High Speeds Backward Button Light switch AUX port USB port...

  • Page 17: Troubleshooting

    TROUBLESHOOTING Problem Reason Solution Low battery Fully charge the battery Stop use for several minutes Electrical protection and restart Vehicle does not move Switch not in the Completely press in switches correct position Battery connectors Plug in battery connectors disconnected Battery connectors Plug in battery connectors disconnected...
  • Page 18 QR CODE for product installation explaination...
  • Page 19 THANKS FOR YOUR CHOOICE...
  • Page 20 APRILIA MOTORCYCLE FOR KIDS 24V BATTERY POWED Kids Ride-On Motorcycle with Training Wheels...
