xSTORAGE NVMe
Quick Start Guide
V 0.2
b-plus technologies GmbH
www.b-plus.com
Valid for
Part-Number
B17049-B2S-20x-xxxx
B17102-8S4-10x-xxxx
Copyright © b-plus technologies GmbH ▪ Version V 0.2 ▪ Date 2023-12-14 ▪ Page 1 of 12
Name
BRICK2 STORAGE NVMe
x8 STORAGE Gen4 E1.S
Description
NVMe JBOF – 8x PCIe 3.0 E1.S
NVMe RAID – 8x PCIe 4.0 E1.S
Advertisement
Summary of Contents for Bplus Technology xSTORAGE NVMe
- Page 1 NVMe Quick Start Guide V 0.2 b-plus technologies GmbH www.b-plus.com Valid for Part-Number Name Description NVMe JBOF – 8x PCIe 3.0 E1.S B17049-B2S-20x-xxxx BRICK2 STORAGE NVMe NVMe RAID – 8x PCIe 4.0 E1.S B17102-8S4-10x-xxxx x8 STORAGE Gen4 E1.S Copyright © b-plus technologies GmbH ▪ Version V 0.2 ▪ Date 2023-12-14 ▪ Page 1 of 12...
- Page 2 NVMe Quick Start Guide Note Copyright © 2023 b-plus technologies GmbH The information and data contained in this quick start guide are subject to change without prior notice. Errors and misprints reserved. This document has been created with due care. b-plus technologies GmbH is not liable for damages resulting directly or indirectly from errors, omissions or discrepancies between the product and the document.
- Page 3 NVMe Quick Start Guide Support Product Documentation You can find this Quick Start Guide in the shipping unit. Read the manual with more information about the product. Download Download the newest versions of the documentation and software on https://www.b-plus.com/en/support/download-portal.
- Page 4 NVMe Quick Start Guide Safety Users must read the safety notes and warning messages before they use the product. Obey the instructions in this document and in the manual to prevent damage of the product or data loss.
- Page 5 NVMe Quick Start Guide Safety Injury by products which The product variants have different weights between approximately 1 are not fastened possible and 3 kg. CAUTION: Products which are not fastened can move and hit persons, e.g., in a test carrier environment. This can cause injuries and permanent damage to the product.
-
Page 6: Initial Operation
NVMe Quick Start Guide x8 STORAGE Gen4 E1.S Rear side view Number Interface Description Power supply port To connect with 4pin R7B connector STORAGE connector b-plus PCIe 4.0 x8 interface 2x USB-C connector Easy access, up to 20 Gbit/s, daisy chain compatible... - Page 7 NVMe Quick Start Guide Cold start in the BRICK or DATALynx ATX4 system NOTICE: It is important to follow the order to avoid data loss. Make sure that the system is in shut-down or power-off state. Insert the xSTORAGE from the front.
- Page 8 NVMe Quick Start Guide Unlock the fasteners to power off and safely remove the cartridge. The unlock is incorrect if the LED Status stops to flash after a few seconds and all LEDs turn green. This can be, e.g., because the xSTORAGE is in use.
- Page 9 NVMe Quick Start Guide Initial Operation of the x8 STORAGE Gen4 E1.S in the stand-alone mode NOTICE: It is important to follow the order to avoid data loss. CAUTION: Only operate the product within the temperature range: 0 °C ~ +40 °C.
- Page 10 NVMe Quick Start Guide CAUTION: Operation and high system loads can cause hot surfaces on the housing. It is necessary to use the correct b-plus cartridge stand with an active cooling for copy processes and longer operations. ...
- Page 11 NVMe Quick Start Guide Maintenance, service, and repair CAUTION: Incorrect handling of the product during maintenance, service, and repair can cause electric shock, fire, permanent damage to the product, and/or personal injury. Do not remove identification numbers, repair work by yourself, or modify the product.
- Page 12 NVMe Quick Start Guide Disposal Refer to the European WEEE directive to dispose electrical and electronic equipment. Do not dispose electrical and electronic equipment with consumer waste. Its components must be recycled or disposed apart from each other. Otherwise, contaminative and hazardous substances can pollute our environment.
