Summary of Contents for Ruddog IRIS ONE.05 FWD

  • Page 2 Thank you for choosing the IRIS ONE.05 FWD, the latest embodiment of Ruddog’s commitment to excellence in on-road racing. With the original launch of IRIS ONE, we embarked on a groundbreaking journey, reshaping the high-end on-road racing cars. Now, after an exhilarating 10-month run and close collabora- tion with our devoted customers and team drivers, we are thrilled to present the IRIS ONE.05, a...
  • Page 3 2.0MM HEX DRIVER WRENCH MICRO PLIERS SET (5) 1.5MM HEX DRIVER WRENCH STRAIGHT SCISSORS BODY REAMER RACE AHEAD WITH RUDDOG: ESSENTIAL RACING EQUIPMENT FOR YOUR IRIS ONE.05. RXS SPEED RP542 BRUSHLESS RC215AC RR1406 SERVO RR482 RECEIVER CONTROLLER MOTOR CHARGER 64DP ALUMINIUM...
  • Page 4 Please note Lubricate using direction. RUDDOG Red Stuff Steep angle Grease or similiar. inside DIFFERENTIAL IRIS-83000 IRIS-32001 IRIS-32004 IRIS-32008 IRIS-32000 IRIS-32006 IRIS-32011 Lubricate using RUDDOG Red Stuff DIFFERENTIAL Grease or similiar. IRIS-32004 IRIS-32001 IRIS-83000 IRIS-32008 IRIS-32006 IRIS-32011 IRIS-32000 DIFFERENTIAL IRIS-85000...

  • Page 5: Motor Mount

    M2.5x6mm BH DIFFERENTIAL Do not overtighten. M2.5x6mm Button Head Screw IRIS-32011 Fill with 1 .0g of Silico- ne Oil. We recommend 1 00k cst as starting point. IRIS-84003 MOTOR MOUNT M3x6mm M3x6mm BH Button Head Screw M3x4mm Button Head Screw IRIS-21013 4x8x3mm BB IRIS-21008...
  • Page 6 MOTOR MOUNT BULKHEAD LEFT M3x3mm Set Screw IRIS-21018 Build this step twice ! IRIS-21005 M3x3mm SS BULKHEAD RIGHT M3x3mm Set Screw Build this step twice ! IRIS-21005 IRIS-21019 M3x3mm SS...
  • Page 7 CHASSIS x1 1 M3x6mm Start with #0 belt ten- Internal drive ratio is 1 .9 Countersunk Screw sion inserts. 1 0x1 5mmmm Ball Bearing IRIS-71000 IRIS-39002 Build Step 2.2 Build Step 2.1 10x15mm BB Build Step 2.3 Build Step 1.1 IRIS-20005 FWD 2.25mm Carbon Fiber Chassis M3x6mm CS IRIS-20006 FWD 2.0mm Aluminium Linear Flex Chassis...
  • Page 8 CHASSIS AND TOPDECK MOUNTED IRIS-84001 LOWER ARMS LEFT IRIS-49001 Build this step twice ! IRIS-40007 M2.5x1 0mm Button Head Screw M3x6mm Suspension balls should Button Head Screw move freely, yet have not too much play. Adjust by tightening or loosening the M2.5x1 0mm screw.
  • Page 9 IRIS-49001 IRIS-84001 LOWER ARMS RIGHT Build this step twice ! M2.5x1 0mm Button Head Screw M3x6mm Suspension balls should Button Head Screw move freely, yet have not too much play. Adjust by tightening or loosening the M2.5x1 0mm screw. M3x6mm BH M2.5x10mm BH IRIS-84014 LOWER ARMS RIGHT...
  • Page 10 FRONT RIGHT UPPER ARM Suspension balls should IRIS-21017 move freely, yet have not M2.5x14mm BH too much play. Adjust by IRIS-85001 tightening or loosening M2.5x1 0mm M2.5x10mm BH the IRIS-4 1 003 nuts. Button Head Screw IRIS-84004 M2.5x1 4mm Button Head Screw IRIS-41003 IRIS-84000 IRIS-40007...
  • Page 11 REAR RIGHT UPPER ARM Suspension balls should 2mm Plastic IRIS-21017 move freely, yet have not Washer too much play. Adjust by IRIS-84004 M2.5x1 0mm tightening or loosening Button Head Screw the IRIS-4 1 003 nuts. IRIS-84000 IRIS-41003 IRIS-40007 IRIS-85001 M2.5x10mm BH REAR UPPER ARMS ASSEMBLED IRIS icon always in front position on rear suspen-...
  • Page 12 MOUNTING OF FRONT LOWER Build Step 4.4 M3x3mm Set Screw Build Step 4.1 IRIS-41000 Use a 3.0mm arm rea- mer to increase the insert hole size until the IRIS-40007 hinge pin moves freely. M3x3mm SS LOWER ARMS MOUNTED...
  • Page 13 MOUNTING OF REAR LOWER ARMS Build Step 4.4 M3x3mm Set Screw Build Step 4.1 IRIS-41000 IRIS-40007 M3x3mm SS 01 3...
  • Page 14 MOUNTING OF FRONT UPPER ARMS Build Step 4.2 IRIS-82001 IRIS-23003 UPPER ARMS MOUNTED 01 4...
  • Page 15 MOUNTING OF REAR UPPER ARMS Build Step 4.3 IRIS-82001 IRIS-23003 1mm and 0.5mm...

  • Page 16: Front Driveshaft

    2x4x1 .5mm Ball Bearing IRIS-83000 IRIS-30011 2x4x1.5mm BB Build this step twice ! IRIS-30002 FRONT DRIVESHAFT Lubricate using RP-0494 RUDDOG Drivetrain Oil REAR DRIVESHAFT M2.5x8mm SH IRIS-30007 Build left and right ver- M3x6mm sion. Button Head Screw 6x10x3mm BB M2.5x8mm...
  • Page 17 STEERING KNUCKLE FRONT L+R M2.5x8mm SH IRIS-39000 STEERING KNUCKLE REAR L+R IRIS-40000 M3x6mm Button Head Screw 6x10x3mm BB M2.5x8mm Socket Head Screw IRIS-30007 6x1 0x3mm IRIS-30015 Ball Bearing IRIS-40005 M3x6mm BH Build left and right ver- sion. STEERING KNUCKLE REAR L+R 01 7...
  • Page 18 MOUNTING OF STEERING KNUCKLES 2mm Plastic Shim MOUNTING OF STEERING KNUCKLES KNUCKLES MOUNTED...
  • Page 19 Lubricate using Insert guide shim and fill RUDDOG Red Stuff with silicone oil. After- Grease or similiar. wards insert piston and SHOCKS LEFT complete shock build. x1 0 IRIS-50018 M2x6mm IRIS-50014 IRIS-50007 Counter Sunk Screw IRIS-50019 M2x6mm CS 500 cst for front shocks...
  • Page 20 Build left and right ver- sion. REAR ROCKERS RIGHT Version LEFT Version IRIS-50033 IRIS-50034 M2x4mm Counter Sunk Screw M2x5mm IRIS-50030 Socket Head Screw IRIS-50031 M2x4mm CS M2x4mm CS M2x5mm SH M2x5mm SH SPRING MOUNTS FRONT Build this step twice ! IRIS-50015 IRIS-51001 Use some grease to...
  • Page 21 Build Step 7.3 MOUNTING OF FRONT SHOCKS Build Step 7.2 M3x6mm Counter Sunk Screw Build Step 7.5 Build Step 7.1 M3x6mm CS Build Step 7.4 MOUNTING OF REAR SHOCKS Build Step 7.1 M3x6mm Build Step 7.6 Counter Sunk Screw Build Step 7.2 M3x6mm CS...
  • Page 22 SHOCKS MOUNTED SERVO Servo is not included. We recommend the RUDDOG Racing RR1 406 servo. M3x6mm Button Head Screw M3x6mm Countersunk Screw IRIS-21012 M3x6mm BH M3x6mm CS...
  • Page 23 SERVO LINK 63.0mm IRIS-40002 IRIS-21014 Short Ball Cup SHOCK LINK 12.0mm IRIS-40002 Build the shock link 4 times! Short Ball Cup IRIS-40006 FRONT STEERING LINKS IRIS-40001 IRIS-40006 Build this step twice! Long Ball Cup IRIS-84005 26.0mm...
  • Page 24 REAR SUSPENSION LINKS 26.5mm Build this step twice! MOUNTING OF FRONT LINKS M3x6mm Button Head Screw M3x8mm Button Head Screw M3x6mm IRIS-84005 Countersunk Screw M3x6mm CS Build Step 9.1 IRIS-84002 Build Step 9.2 M3x6mm BH M3x6mm BH Build Step 9.3 M3x6mm BH Use middle hole on steer- ing arm.

  • Page 25: Front Bumper

    MOUNTING OF REAR LINKS IRIS-84005 M3x6mm M3x6mm CS Button Head Screw M3x6mm Countersunk Screw M3x6mm BH Build Step 9.4 M3x6mm BH 10.1 FRONT BUMPER M3x8mm CS M3x8mm IRIS-70000 Countersunk Screw IRIS-23001 M3x8mm CS IRIS-23000 IRIS-21021 IRIS-85013...
  • Page 26 10.2 REAR BODY MOUNT M3x6mm IRIS-23001 Button Head Screw IRIS-22005 M3x6mm BH 10.3 MOUNTING THE FRONT BUMPER M3x6mm Countersunk Screw M3x8mm Countersunk Screw Build Step 10.1 M3x6mm CS M3x8mm CS...
  • Page 27 10.4 MOUNTING OF THE REAR BODY M3x6mm Countersunk Screw M3x6mm M3x6mm CS Button Head Screw M3x6mm BH Build Step 10.2 10.5 INSTALL BATTERY MOUNT AND WEIGHTS M3x6mm Button Head Screw M3x6mm BH M3x3mm IRIS-21015 Set Screw M3x3mm SS IRIS-21010 M3x1 2mm IRIS-21009 Countersunk Screw IRIS-23002...

  • Page 28: Option Parts

    OPTION PARTS FRONT CENTER WEIGHT IRIS-75008 Use this optional Front Center Weight to shift the weight balan- ce forward, thereby increasing steering responsiveness. IRIS-75008 M3x12mm CS +15MM SERVO MOUNT SET IRIS-75006 This set repositions the servo 1 5mm further back, allowing you to mount a large speed controller, such as the Hobbywing...
  • Page 29 ALUMINIUM DIFFERENTIAL COVER IRIS-3201 0 The Aluminum Diffe- rential Cover not only adds aesthetic appeal, but it also enhances the sealing and consis- tency of your differen- tial. BODY POST HEIGHT ADJUSTMENT IRIS-75000 The Body Post Height Adjustment Set ena- bles you to easily modify the body height while also enhancing...
  • Page 30 STEEL LIPO HOLDER IRIS-75005 The Steel Lipo Hol- der allows you to add extra weight to the front of the car, shif- ting the weight bias further forward. 4.5MM AND 3.5MM WHEEL HEX IRIS-3001 3 IRIS-3001 4 The 3.5mm and 4.5mm Wheel Hexes for the Iris One allow you to easily adjust...
  • Page 31 GEAR UP, SPEED UP: CHOOSE RUDDOG FOR YOUR IRIS ONE.05. 1/10 TOURING TIRE HD LIPO RSS65 SOLDERING HEATING SYSTEM CHARGING BAG STATION 65W CAR BAG - 1/10 ONROAD ALUMINIUM SMALL TOURING CAR CAR STAND RACING BAG...
