GATEXPERT BC Series Instruction Manual

Dc brushless barrier gate

Advertisement

Quick Links

DC Brushless Barrier Gate
BC Series
Instruction Manual
Website: www.gatexpertstore.com
E-mail: sales@gatexpertstore.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BC Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GATEXPERT BC Series

  • Page 1 DC Brushless Barrier Gate BC Series Instruction Manual Website: www.gatexpertstore.com E-mail: sales@gatexpertstore.com...
  • Page 2 Warning: Please read this instruction manual carefully before installation, in which contains some important information about installation, usage, maintenance and safety. Any undefined operation under this instruction is not allowed. Improper usage will result in damage to this product and cause serious injury or property losses. Please keep this instruction manual properly for future reference.
  • Page 3  Please fill in the order information in the form below.  All personal information you provided will be only used for warranty service and kept strictly confidential.  Refer to this list when contacting GATEXPERT for technical service or assistance with your automatic gate opener. Order Number...
  • Page 4: Table Of Contents

    Table of Contents: 1. Product Outline………………………………………………………………………………..1 2. Functions and Features………………………………………………………………………1 3. Technical Parameter List……………………………………………………...……………..2 4. Machine Components………..….…..……………………………………………………….3 5. Installation Direction....………………………………………………………………3 6. Assembly and Installation……………………………………………………………………4 6.1. Pre-Installation Check……………………………………………………………………..4 6.2. Basic Structure Installation………………………………………………………...……..4 6.3. Boom Balance Adjustment………………………………………………………………..6 6.4. Mains Wiring…………………………………………………………….………………….7 6.5. Electrify Check………………..……………………………………………………..…..7 6.6.
  • Page 5: Product Outline

    1. Product Outline On the basis of absorbing essence of similar products at home and abroad, the company has researched and developed this BC series DC brushless barrier gate. This product adopts international advanced technology, with mechanical and electrical integrated design, which fully realizes automation and intelligence of operating, brings convenience、...
  • Page 6: Technical Parameter List

     Open first anti-smash function: barrier boom will perform opening action once received an opening signal during the closing process.  Humanized anti-collision boom dropping-out mechanism, when the vehicle accidentally hits the barrier boom, the anti-collision mechanism will rotate the boom to avoid damage to the vehicle and the barrier gate.
  • Page 7: Machine Components

    4. Machine Components Motor Motor Link Link rod Crank Crank arm 10 10 Rocker Rocker spring spring arm Spring Spring Spring Spring rod(upper) rod(upper) Reduction Reduction gearbox gearbox Output Output shaft shaft Boom Boom tray tray head head Boom Boom 11 11 Figure 1 5.
  • Page 8: Assembly And Installation

    6. Assembly and Installation 6.1 Pre-Installation Check Note:  Barrier gate installation must be carried out by qualified technician; Installation must comply with relevant regulations. Before installation, please read this instruction manual carefully.  Please definite the installation direction of the barrier gate to be Leftward or Rightward fixed.
  • Page 9  Fastening Screws Installation Instruction : If the installation site didn’t set with a foundation, then please make sure that the installation ground is strong enough to be fix with the barrier gate. Drill holes for fastening screws with diameter of 16mm, depth of 80mm, drive the M12 x 150mm fastening screw into the hole, then tighten the nut before withdrawing it.
  • Page 10: Boom Balance Adjustment

    6.3 Boom Balance Adjustment The tension of the spring is related to the boom length, the spring has been assembled in the factory according to the different boom length, also the relative adjustments on operating speed 、 operating balance during opening/closing process has been set up before delivery.
  • Page 11: Mains Wiring

    6.4 Mains Wiring The power module of the barrier gate has been connected to the control board before delivery. To ensure operational safety and avoid damage to the components, please disconnect the circuit breaker first, and then connect the L and N of AC power into the input port of circuit breaker.
  • Page 12: Vertical Adjustment Of Barrier Boom

    6.6 Vertical Adjustment of Barrier Boom If the barrier gate boom cannot open to its vertical position or close to its horizontal position. Please take the following steps to adjust it: 1. Open the barrier gate door, unplug the power cord. 2.
  • Page 13 with a specific tool to enable the barrier boom to move, after which barrier boom can be manually pressed down for closing. To open when boom in closed position, please clockwise rotate the motor shaft with a specific tool to enable the barrier boom to move, after which barrier boom can be manually lifted up for opening.
  • Page 14: Spring Configuration

    Figure 9 Figure 10 6.8 Spring Configuration Boom Length Spring 3M Octagonal Boom 80x46 mm Φ4.5x1pc 4M Octagonal Boom 80x46 mm Φ5.5x1pc 5M Octagonal Boom 100x45 mm φ4.5 x1pc; φ5.5 x1pc 6M Octagonal Boom 100x45 mm φ5.5x2pcs Note: If the boom length is shorter than 4m, it’s recommended to use 80x46mm octagonal boom, if length is longer than 4m, to use 100x45mm octagonal boom.
  • Page 15: Control Board Wiring

    7. Control Board Wiring Figure 11 Warning! The controller of this product is specially designed for the use of low speed and medium speed barrier gates. The position of the barrier boom will be continuously detected by the motor hall during running, which replaces the limit switches used in conventional barrier control systems.
  • Page 16: Terminal Instruction

    The combination of the hall encoder and the controller unit ensures the maximum control to the boom optimum running position. Note! For other special functions, please note that the controller's wiring may differ from which shown in this wiring illustration. Important Note: All input signals (like push buttons, limit switches, etc.) must be connected in the volt-free contact way.
  • Page 17: Setting Button Instruction

    OPEN Barrier gate in opening HOLD Open in place LOCK Barrier gate locked 7.2 Setting Button Instruction There are 4 buttons on the control board for setting all the parameters: open/+, close/-, menu/confirm, stop/cancel. Open/+: Under normal working mode, press this button, barrier will open. While control board in setting mode, pressing this this button will increase the value, press and hold this button, the value will be increased to the max.
  • Page 18 faster the speed will be. The larger the number is, the F-01 Close speed 10-100 faster the speed will be. The position that barrier starts to F-02 Slow open position 45-80 run at a slower speed during opening. Unit: degrees The position that barrier starts to F-03 Slow close position...
  • Page 19: Technical Support

    be used for burn-in test. 0 means the normal working mode. Restore factory 5:Delete all remote controls 10: F-21 0-255 setting Restore factory setting The angle that barrier starts to run F-28 Slow close angle 0-45 at a slower speed during closing. Unit: degrees F-29 Relay output mode...
  • Page 20: Packing List

    If there is any operation failure that can ’ t be handled by your technical staff, please contact our authorized service representative or professional assistance. Please provide the barrier gate model, product serial number, controller version and other information when contact us for technical support services, which you can find in the barrier gate machine case model plate.
  • Page 21: Terms Of Service

    10. Terms of Service  One-year free maintenance for the system(barrier gate boom、remote control is not covered by this warranty)  Lifetime repair guarantee.  Technical support. The following situations are not covered by free maintenance (or replacement):  Damages to this product caused by installation which is not complied with the instructions under this manual.
