LIGHT UNIVERSAL MULCHER
LUM 110 / 130 / 150
INSTALLATION / HANDLING / MAINTENANCE
e-mail: info@fpm.rs
SPARE PARTS LIST
FPM AGROMEHANIKA d.o.o.
Đorđa Simeonovića br.25
Boljevac-Srbija
SERBIA
LUM 110 - FPM-618.232 - 1,1 m
LUM 130 - FPM-618.197 - 1,3 m
LUM 150 - FPM-618.198 - 1,5 m
Internet: www.fpm.rs
№ 63049
Advertisement
Table of Contents
Related Manuals for FPM Agromehanika LUM 110
Summary of Contents for FPM Agromehanika LUM 110
- Page 1 LIGHT UNIVERSAL MULCHER LUM 110 - FPM-618.232 - 1,1 m LUM 130 - FPM-618.197 - 1,3 m LUM 110 / 130 / 150 LUM 150 - FPM-618.198 - 1,5 m № 63049 INSTALLATION / HANDLING / MAINTENANCE SPARE PARTS LIST FPM AGROMEHANIKA d.o.o.
- Page 2 IMPROVEMENT: FPM AGROMEHANIKA DOO constantly strives to improve its products and therefore reserves the right to make changes or improvements when necessary, without any obligation to change or supplement previously manufactured or sold equipment.
-
Page 3: Read Carefully
- Shaft with one-way coupling F5 / 1R – right The cardan shaft is a product of the company "WALTERSCHEID" and can be purchased under the number: W 100E-SD15-610-F5/1R, 1 3/8''(6) - 1 3/8''(6) - for LUM 110 (FPM-618.232) - for LUM 110 PRO (FPM-618.275) - for LUM 130 (FPM-618.197) -
Page 4: Warranty Limitations
("Official Gazette of the REPUBLIC OF SERBIA", No. 21/2020, valid from 06.03.2020), for each original piece of mulcher delivered to the user by the sales network FPM AGROMEHANIKA DOO Boljevac which guarantees that at the time of delivery each such part of the mulcher is new, without defects in material and workmanship, and that the rotary mulcher is guaranteed for a period of one year from the date of delivery to the end user, provided that the machine is used and serviced in in accordance with the recommendations in this operating and maintenance manual. - Page 5 The following warning labels have been affixed to your mulcher for your safety as well as the safety of the people working with you. Holding this manual in your hand, go around the machine and check these warning labels and instructions in the manual.
- Page 6 Identification table Rotating elements! Keep legs and arms away from rotating elements. Other persons must stand at a safe distance from the machine. A place where there is a greaser! Mandatory, daily, lubrication before starting work. Read the instructions carefully before working with the machine.
-
Page 7: Tool Description
TOOL DESCRIPTION The light universal mulcher is intended for versatile application on all agricultural areas, for the maintenance of green areas and neglected terrains. Light universal mulcher can be used for shredding individual harvest residues, for shredding pruning residues in orchards and vineyards and crushing branches up to 40 mm thick. The construction of the mulcher is intended for work on smaller farms, around weekend houses, in parks. - Page 8 - Knives on the rotor and parts used for their fastening (nuts, screws, etc.) if worn or damaged, immediately replace with original parts FPM AGROMEHANIKA, BOLJEVAC. - Before starting to adjust, lubricate or clean the mulcher, switch off the tractor engine, remove the ignition key, disengage the PTO shaft, and apply the tractor parking brake.
- Page 9 - Never wear loose clothing that can be caught by the rotating parts of the mulcher. Clothes should be clinging to the body. Use protective equipment, goggles, gloves and safety shoes, especially when working on rocky ground. - The operator must be absolutely sure that persons or animals are not in the work area mulcher, before the mulcher starts and starts working.
- Page 10 - Only those cardan shafts supplied with the mulcher or prescribed by the mulcher manufacturer may be used. - Cardan shafts must be installed and in the prescribed condition. - Make sure that the pipes overlap in the transport and working position. - Coupling and uncoupling must only be carried out with the tractor output shaft switched off, the engine switched off and the ignition keys removed.
- Page 11 SPECIFICATION OF TECHNICAL CHARACTERISTICS LIGHT UNIVERSAL MULCHER - LUM LUM 130 LUM 150 LUM 110/ 110 PRO (FPM-618.232 / 275) (FPM-618.197) (FPM-618.198) Working width (m) Overall width - 1,218 1,476 1,638 dimension "A" (m) Tractor power min - max 15 - 23 / 20 - 30...
- Page 12 TRANSPORT OF MULCHERS DANGER: If the mulcher is transported on public roads, be sure to insure it for safe driving, and follow the rules of conduct in public traffic. The tool must be raised at least 40 cm from the ground. If the mulcher is transported by truck or rail, the "SPECIFICATION OF TECHNICAL CHARACTERISTICS"...
- Page 13 Picture 4. Picture 5. - Attach the left lower tractor link to the left tool arm, and secure it with the existing wedges. - Attach the right lower tractor lever to the right tool arm, and secure it with the existing pegs. - Secure the left and right lower link arms with the appropriate chains so that they are parallel to the tractor.
-
Page 14: During Work
WORKING POSITION DANGER: The operator of the tool must sit exclusively in the driver's seat, because only from that place can he properly operate the tool. Before leaving the driver's seat, the operator must stop the tool, apply the parking brake and switch off the tractor engine. DURING WORK After properly attaching the implement to the tractor, taking the driver's seat, and starting the tractor, do the following:... - Page 15 When you move the roller to a position closer to the ground, you must also adjust the third connection point (topling) so that the tool is parallel to the ground surface. USEFUL TIPS, FOR YOU Here are some helpful tips on how to troubleshoot some issues that may occur during operation. VEGETABLE RESIDUES ARE TOO CRUSHED - slightly lift the blades off the ground, adjust the height with the roller (cutting blades must not touch the ground) - increase the speed of the tractor...
-
Page 16: Regular Maintenance
- switch off the tractor output shaft drive - by releasing the hydraulics, lower the tool to the ground - switch off the tractor engine and apply the parking brake - make sure that all parts of the tool are at rest Only after checking the above operations can the operator leave the driver's seat. -
Page 17: V-Belt Replacement
V-BELT REPLACEMENT V-belts are properly tightened if the deflection is max. 10 mm (as given in Figure 9), to prevent excessive slipping. Insufficiently tightened belts are the cause of poor work of mulchers and premature damage and tearing of belts. When replacing belts, or checking their tightness, do the following: - Loosen the nuts and remove the V-belt guard. -
Page 18: Recommended Lubricant
For lubrication of gears in the multiplier, the use of hypoid oil SAE 85 W-140 is recommended, to achieve a quality level of American military specification MIL-L-2105C and API Service Classification GL-5 or standard JUS B.H3.303 Type "MP-5" . RECOMMENDED LUBRICANT - For lubrication of all places where lubricators are located, use calcium grease with an additive that increases adhesion to metal surfaces, and which meets JUS B.H3.634 VM-2 specifications NLGI-2. - Page 19 When checking the tightness of the bolts and replacing the parts, tighten the bolts based on the tables shown strana | 19...
- Page 20 strana | 20...
-
Page 21: Spare Parts List
SPARE PARTS LIST - Instructions for ordering spare parts – To order spare parts or components, contact the sales department - spare parts. The existing images on the following sheets show the machine parts marked with numbers. The text next to the picture contains: the ordinal number of the machine part, its identification number, the quantity within the mulcher and, if necessary, the dimensions or standard. -
Page 22: Declaration Of Conformity
FPM AGROMEHANIKA DOO Đorđa Simeonovića 25 19370 Boljevac – Srbija DECLARATION OF CONFORMITY FPM Agromehanika DOO, Djordja Simeonovića 25, 19370, Boljevac, Srbija We hereby declare, as manufacturers, within our responsibility, that the products listed below are in accordance with the requirements of the Ordinance on the safety of machinery ('' Official Gazette of the REPUBLIC OF SERBIA '', No. - Page 23 strana | 23...
- Page 24 618010219 618010220 618010221 618010224 618010232 618010233 618010259 618010260 618010271 618010328 618 010419 618 010468 618010449 19.1. LUM 110 (FPM-618.232) 618010454 19.2 LUM 130 (FPM-618.197) 618010455 19.3 618110456 LUM 150 (FPM-618.198) 618 010467 618010468 618010474 23.1. LUM 110 (FPM-618.232) 618010477 23.2.
- Page 25 618015110 618015345 618017212 618017213 51.1. LUM 110 (FPM-618.232) 618017316 51.2. LUM 130 (FPM-618.197) 618017351 51.3. 618017317 LUM 150 (FPM-618.198) 52.1. LUM 110 (FPM-618.232) 618018043 52.2. 618018044 LUM 130 (FPM-618.197) 52.3. 618018045 LUM 150 (FPM-618.198) 53.1. LUM 110 (FPM-618.232) 618018047 53.2.
- Page 26 ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ strana | 26...
- Page 27 ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ strana | 27...
- Page 28 HEALTH CARE, AS WELL AS REGULATIONS ON ROAD TRAFFIC. FOR THE PURPOSE OF YOUR OWN SAFETY, USE ONLY ORIGINAL PARTS PRODUCED BY FPM AGROMEHANIKA DOO - BOLJEVAC. THE MANUFACTURER IS NOT RESPONSIBLE FOR THE CONSEQUENCES OF INCORRECT USE OR NON-COMPLIANCE WITH THE RECOMMENDATIONS...
- Page 29 FOR YOUR PERSONAL SAFETY AND TO GET THE BEST FROM YOUR PLANT REMOVER MULCHER, USE ONLY THE ORIGINAL PARTS PRODUCED FPM AGROMEHANIKA DOO BOLJEVAC FPM AGROMEHANIKA DOO 19370 Boljevac, ul. Đorđa Simeonovića br.25 TELEFONI: Služba prodaje: Tel: +381 30 461 171 Mob: +381 63 485 312 Služba Servisa: Tel: +381 30 463 619...
