Neon Flex - Installation Guide
Horizontal bendable weatherproof RGBW silicone pixel strip
Contents
Safety ............................................................................................................................................................................................................................................ 2
Electrical Safety ................................................................................................................................................................................................................. 2
System Planning and Specification ........................................................................................................................................................................ 2
Protection from Injury During Installation .......................................................................................................................................................... 2
Installation Safety and Guidelines .......................................................................................................................................................................... 3
Physical Dimensions ............................................................................................................................................................................................................. 4
Electrical Connections ......................................................................................................................................................................................................... 5
Voltage Drop .............................................................................................................................................................................................................................. 6
Control Channels .................................................................................................................................................................................................................... 6
Wiring Application .................................................................................................................................................................................................................. 5
Mounting Installation ............................................................................................................................................................................................................ 7
Servicing, Inspection & Maintenance .......................................................................................................................................................................... 9
Cleaning ..................................................................................................................................................................................................................................... 10
Ordering Information ......................................................................................................................................................................................................... 10
Neon Flex ...................................................................................................................................................................................................................... 10
Neon Flex Accessories ............................................................................................................................................................................................ 10
1
|
ID: 5951130
Neon Flex (73060)
Visit the ENTTEC
website
for the latest version
INSTALLATION GUIDE
Advertisement
Table of Contents
Summary of Contents for Enttec Neon Flex
-
Page 1: Table Of Contents
Neon Flex (73060) Visit the ENTTEC website for the latest version Neon Flex - Installation Guide Horizontal bendable weatherproof RGBW silicone pixel strip Contents Safety ................................................2 Electrical Safety ..........................................2 System Planning and Specification ..................................2 Protection from Injury During Installation ................................2 Installation Safety and Guidelines .................................. -
Page 2: Safety
When installing the Neon Flex above ground level, ensure that the installation hardware and supporting structure can hold the weight of all the devices they support. In an overhead installation or where the Neon Flex system may cause injury if it falls. Block access ▪... -
Page 3: Installation Safety And Guidelines
Ensure proper data flow by following the direction indicated on the Neon Flex. ▪ Avoid covering Neon Flex with any insulating material. ▪ Take care not to apply tension on the cabling while installing Neon Flex or accessories. ▪ Qualified personnel should perform the installation, and professional consultation is advised when ▪... -
Page 4: Physical Dimensions
Neon Flex (73060) Visit the ENTTEC website for the latest version Physical Dimensions Neon Flex – SPI 12V Neon Flex – DMX 24V Female Connector Male Connector INSTALLATION GUIDE ID: 5951130 ... -
Page 5: Electrical Connections
It is recommended to ensure the feeder cable is long enough to reach the cable entry point of flex where connection can be made. ▪ Do not cut the Neon Flex and the waterproof connectors. DIY cutting of this product will void the warranty. ▪ Tighten the female and male connectors with pliers when installing to ensure there are no gaps. -
Page 6: Voltage Drop
▪ The hard upper limit to the number of Neon Flex you can run from one data feed can be calculated by dividing the maximum number of data channels per output of the ENTTEC controller by the DMX channel footprint of the Neon Flex. -
Page 7: Mounting Installation
White Fine Mounting Installation Neon Flex is an incredibly durable product; however, it must be installed following the provided picture guide. It ▪ is essential to have at least two people during the installation process to support the product at various locations as shown in the guide. - Page 8 To maintain the waterproof performance of the connector, it is important to avoid bending the Neon Flex against the light terminal. Make sure to keep a minimum distance of 100mm before shaping the Neon Flex. This will help prevent any potential damage or compromise to the waterproof seal of the connector.
-
Page 9: Servicing, Inspection & Maintenance
▪ Check for dust or dirt build-up on the Neon Flex System and schedule cleaning if necessary. – Dirt or dust buildup can limit the ability of the Neon Flex system to dissipate heat and can lead to damage. -
Page 10: Cleaning
Dust and dirt buildup can limit the ability of the Neon Flex system to dissipate heat resulting in damage. It’s important that the Neon Flex system is cleaned in a schedule fit for the environment it is installed within to ensure maximum product longevity.
