- Page 1 Installation and user manual Smart, app connectivity Battery powered Unisenza Plus - Electronic Thermostatic Head Geo location 5 year guarantee...
- Page 2 Unisenza Plus - Electronic Thermostatic Head Installation and user manual Release Date First release August 2023...
-
Page 3: Table Of Contents
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Index Safety warnings ........................4 Pictograms used in this manual....................4 Purpose of the manual .......................4 Intended use ...........................4 Safety regulations ........................5 Technical data .........................6 Unisenza Plus Electronic Thermostatic Head ..............6 Dimensions ..........................7 Pack contents .......................... -
Page 4: Safety Warnings
Unisenza Plus - Electronic Thermostatic Head Installation and user manual SAFETY WARNINGS Pictograms used in this manual To make reading clearer and more enjoyable, three types of symbols have been used in this manual to convey to the reader the meaning or importance of the information provided: Hazard signs. -
Page 5: Safety Regulations
Unisenza Plus - Electronic Thermostatic Head Installation and user manual • Modulating control algorithm optimizes the energy efficiency and comfort • Open window detection function for energy savings • Support standard M30 x 1.5 mm valve connection with optional adaptor to support RA valve types •... -
Page 6: Technical Data
Unisenza Plus - Electronic Thermostatic Head Installation and user manual TECHNICAL DATA Unisenza Plus Electronic Thermostatic Head Temperature Scale °C or °F Temperature display range 0°C - 40°C (32°F - 104°F) Temperature display resolution 0.5°C (1°F) Temperature setting range 5°C - 35°C (41°F - 95°F) Temperature setting resolution 0.5°C (1°F) Temperature measurement accuracy... -
Page 7: Dimensions
Unisenza Plus - Electronic Thermostatic Head Installation and user manual DIMENSIONS PACK CONTENTS a. Unisenza Plus Electronic Thermostatic Head b. 2 x AA-sized Alkaline Batteries c. RA Adapter... -
Page 8: Overview
Unisenza Plus - Electronic Thermostatic Head Installation and user manual OVERVIEW Unisenza Plus Electronic Thermostatic Head Display LCD Button Button Button Battery compartment Securing ring Display icons Icon Meaning Description On: the device is joined to a Unisenza Plus network Antenna Flashing: the device is searching for a Unisenza Plus network On: the device pairs with a room thermostat or a receiver... -
Page 9: Button Usage
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Button usage When LCD backlight is Off Turn on the LCD backlight Press any buttons When LCD backlight is On Change mode (Off -> Manual > Schedule) Press Increase set point Press Decrease set point Press... -
Page 10: Download The App
Unisenza Plus - Electronic Thermostatic Head Installation and user manual DOWNLOAD THE APP The management of the Unisenza Plus Electronic Thermostatic Head is also possible through a dedicated APP that allows its configuration and the management of the devices you will pair. In order to download the APP, you need to connect to the STORE of your device used for con- figuration and install the Unisenza Plus. -
Page 11: Installation
Unisenza Plus - Electronic Thermostatic Head Installation and user manual INSTALLATION Recommendations for a correct installation 50°C 0°C Heating system compatibility The Unisenza Plus Electronic Thermostatic Head is compatible with the majority of thermostatic ra- diator valves. When mounting the Unisenza Plus Electronic Thermostatic Head on the Danfoss RA valve, please use the RA adapter as shown in below picture. -
Page 12: Inserting The Batteries
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Inserting the batteries The Unisenza Plus Electronic Thermostatic Head, to work, requires 2 AA alkaline batteries (included in the package). Use only and exclusively the batteries indicated by the manufacturer in the table in the "Tech- nical data"... -
Page 13: Installation On Standard Valve
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Installation on standard valve To mount the Unisenza Plus Electronic Thermostatic Head on a standard valve proceed as shown. During assembly, be very careful not to use too much force in tightening the various compo- nents. -
Page 14: Installation On Danfoss Ra Valve
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Installation on Danfoss RA valve To mount the Unisenza Plus Electronic Thermostatic Head on a Danfoss RA valve proceed as shown. During assembly, be very careful not to use too much force in tightening the various compo- nents. -
Page 15: Use
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Main screen operation The LCD backlight is Off during stand by in normal operation. Press any key to turn on the LCD backlight before performing other user operations as descried below. The LCD backlight will be turned off automatically when no key press for 15 seconds. -
Page 16: Joining To Unisenza Plus Gateway
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Joining to Unisenza Plus Gateway With APP The association between the Unisenza Plus Electronic Thermostatic Head and the Unisenza Plus Gateway can be done through the system management APP. To proceed with the association you need to have already installed and configured the Gateway. Unisenza Plus Gateway Instruction Manual... - Page 17 Unisenza Plus - Electronic Thermostatic Head Installation and user manual Without APP The association between the Unisenza Plus Electronic Thermostatic Head and the Unisenza Plus Gateway can also be made directly between the two devices. To proceed with the association you need to have already installed and configured the Gateway. Cloud WiFi ZigBee...
-
Page 18: Valve Calibration
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Valve calibration When the Unisenza Plus Electronic Thermostatic Head is firstly installed to the radiator valve, follow below step to perform the valve adaptation. To carry out the procedure, proceed as indicated in the following images. Start calibration °... -
Page 19: Pairing With Other Unisenza Plus Device (Optional)
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Pairing with other Unisenza Plus device (optional) After the Unisenza Plus Electronic Thermostatic Head joined a ZigBee network, it can be paired with a Unisenza Plus Receiver or Unisenza Plus Thermostat. MENU BOOST - MAIN -... - Page 20 Unisenza Plus - Electronic Thermostatic Head Installation and user manual Pair device using the Unisenza Plus Electronic Thermostatic Head local interface ° C ° C ° C ° F ° F ° F MENU BOOST >3 SEC - MAIN - AUTO - AUX - °...
-
Page 21: Change Operation Mode
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Unpair device using the Unisenza Plus Electronic Thermostatic Head local interface ° C ° C ° F ° F ° C ° F MENU BOOST >3 SEC - MAIN - AUTO - AUX - °... -
Page 22: Change Set Point In Manual Mode
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Change set point in Manual mode ° C ° C ° F ° F ° C ° F ° C ° F Temporarily change set point in Schedule mode ° C °... -
Page 23: Off Mode With Frost Protection
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Off mode with frost protection When change to Off mode, the icon is displayed and the frost protection is active. The Unisenza Plus Electronic Thermostatic Head actuator will open and close the valve occasionally when the room temperature drops below 5°... -
Page 24: Maintenance
Unisenza Plus - Electronic Thermostatic Head Installation and user manual 10 MAINTENANCE Low battery When the Unisenza Plus Electronic Thermostatic Head detects low battery, is displayed. Bat- tery should be replaced as soon as possible. When battery is at extremely low level, is displayed and flashes. -
Page 25: Cleaning
Unisenza Plus - Electronic Thermostatic Head Installation and user manual Cleaning P ON E U TR O... -
Page 26: Manual Download And Updates
Unisenza Plus - Electronic Thermostatic Head Installation and user manual 11 MANUAL DOWNLOAD AND UPDATES Due to the requirement for continuous improvement, we constantly update the user manuals of our systems. We therefore invite you to periodically check whether the manual in your possession is always the latest written version. - Page 27 Unisenza Plus - Electronic Thermostatic Head Installation and user manual...
- Page 28 A PURMO GROUP BRAND Bulevardi 46 P.O. Box 115 FI-00121 Helsinki Finland www.purmogroup.com Every care has been taken in the creation of this document. No part of this document may be reproduced without the express written consent of Purmo Group. Purmo Group accepts no responsibility for any inaccuracies or consequences arising from the use or misuse of the information contained herein.
