Item #1010 000 436
Model #FDS50285C-ST5
USE AND CARE GUIDE
AMBERVIEW 6-PIECE SLING DINING SET WITH UMBRELLA
Questions, problems, missing parts?
Before returning to the store, call Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this set. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement
needs. Thank you for choosing StyleWell!
Advertisement
Table of Contents
Related Manuals for StyleWell AMBERVIEW FDS50285C-ST5
Summary of Contents for StyleWell AMBERVIEW FDS50285C-ST5
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Planning Assembly ..............3 Important Safety Instructions ........2 Table Hardware Included ............3 Save These Instructions ............2 Table Package Contents ............Read All Instructions Before Use ..........2 Umbrella Package Contents ............ -
Page 3: Warranty
Warranty 1 YEAR FRAME AND FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frame to be free of manufacturing defects to the original purchaser for one year, and the fabric to have a one year limited warranty. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Umbrella Package Contents
Pre-Assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Table Top Leg Connector Table Leg UMBRELLA PACKAGE CONTENTS Part Description Quantity Umbrella Shade Umbrella Pole... - Page 5 Table Assembly Attaching the Table Legs to the Table Top Place the table top (A) upside down on a soft surface. Attach the table legs (C) to the table top (A). Attaching the Leg Connector to the Table Legs Attach the leg connector (B) to the table legs (C) using M8 35 combination bolts (AA).
-
Page 6: Umbrella Assembly
Table Assembly (continued) Checking the Table Turn the table right side up. Ensure the table is tightly assembled and stable before use. Umbrella Assembly Connecting the Umbrella Shade to the Umbrella Pole Place the umbrella shade (D) over the umbrella pole (E). Press the tab on the umbrella pole (E) while you slide the umbrella pole (E) into the umbrella shade (D) until the two pieces snap into place. -
Page 7: Umbrella Operation
Umbrella Operation Opening the Umbrella Shake the umbrella fabric before opening the umbrella. Hold the hub on the umbrella shade (D) and move upwards until the umbrella shade locks into place. Closing the Umbrella To close the umbrella hold the hub on the umbrella shade (D) and move downwards. NOTE: Be careful of your fingers when pulling the hub on the umbrella shade (D) downwards. -
Page 8: Care And Cleaning
Care and Cleaning For best results, clean the table with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. Do not clean with abrasive materials, bleach, or solvents. Store the set in a dry, sheltered place when not in use. Keep the set away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind. - Page 9 Questions, problems, missing parts? Before returning to the store, call StyleWell Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use. Factory Table ID # FTS50442X...
- Page 10 AMBERVIEW 6-PIECE SLING DINING SET WITH UMBRELLA – FOLDING CHAIR Use and Care ITEM #1010 000 436 MODEL #FDS50285C-ST5 Guide Operation OPENING THE CHAIR FOLDING THE CHAIR Slide the seat downward and the Lift the seat upward and the backrest backward until the legs backrest forward to fold the chair.
