- Page 1 USER MANUAL PD08D PD08D Scan the QR Code To Activate Warranty Email：info@ihevillo.com...
- Page 2 If you have any questions or problems about the product, please contact us directly： info@ihevillo.com HEVILLO has an award-winning warranty, exchange, and customer service program that guarantees hassle -free solutions to any issue you might have within 24 hours!
- Page 3 Dear user, Thank you for purchasing our dehumidifier, hope it can bring comfort and convenience to your work and life. It is recommended that you keep the manual properly for future reference. Before using this product, please read the manual carefully to ensure that the product performs its best function.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions P.01 Parts Description P.02 Operation Interface P.03 Operation Instructions P.04-P.09 Care & Cleaning P.10 Troubleshooting P.11 Safety Precautions P.12 Technical Specifications P.13 Warranty P.14 *BEFORE FIRST USE* To prevent any internal damage, it is ver y important to keep refrigeration units (like this one) upright throughout their journey. -
Page 5: Important Safety Instructions
Important Safety Instructions To prevent injury to the user or other people and property damage, the following instructions must be followed when using the Dehumidifier. Incorrect operation due to ignoring of instructions may cause harm or damage. 1. Do not exceed the rating of the power outlet or connection device. 2. -
Page 6: Parts Description
Parts Description Control panel Outlet Front Handle Air inlet Rear Drain Hose Outlet Water tank P.02... -
Page 7: Operation Interface
Operation Interface Control Panel HUMIDITY Button Speed Button Timer Button Mode Button Button CHILD LOCK Status Display Area DEHU. CONT. CHILD HUM. SPEED MODE LOCK Power Button Button description Humidity Button For control of machine switch Use for setting humidity values. machine For working mode selection Setup for timing time... -
Page 8: Operation Instructions
Operating Instructions 1、Function button Mode Setting ● The device has three operating modes: dehumidification mode, drying mode, continuous dehumidification mode. In the power on state, press the [mode] button, and the device will cycle through the dehumidification and dry clothes continuous dehumidification modes. Each time you press the mode key, the working mode will switch accordingly. - Page 9 Operating Instructions Child lock Setting ● Press and hold the CHILD LOCK button for 3-5 seconds to lock or unlock the control panel. When the CHILD LOCK function has been activated, the indicator illuminates, and other buttons will be disabled. To regain use of the buttons, unlock the control button.
- Page 10 Operating Instructions Display Status Description ◆After the device is powered on,only the power light is on in the standby (shutdown)state. TIMER ◆Timing status indicator ：it will be on for a long time if the timing is valid, it will flash when setting and viewing, and it will be off if it is invalid. ◆Slow speed indicator light ：if the wind speed is set to slow speed, it will be On, otherwise it will be off.
- Page 11 Operating Instructions Error Codes: Error code meaning Number Error code Humidity sensor error Defrost Temperature sensor error Room temperature sensor error Water full alarm Note: ·When error happened, error code flashing on display, if there are more than one error, each error code display in turn, if only one error, the error code and the current humidity value are displayed alternately.
- Page 12 Operating Instructions REMOVING THE COLLECTED WATER When the water tank is full, the water is full of lights flashing, and then automatically stop, at this time must empty the water tank . And place the water tank correctly. Empty the Water Tank Put your hand into the groove at the bottom of the water tank, gently pull The Arrow points to a water tank...
- Page 13 Operating Instructions Continuous draining Unplug the power supply, take out the bucket, remove the drain outlet cover, insert the water hose into the continuous drain outlet and then push the water tank back, connect the power to start running. The outlet of water hose should be lower than the continuous drain outlet 10cm(3.9inch) or more, and the hose cannot be bent to ensure smooth drainage.
-
Page 14: Care & Cleaning
Care & Cleaning CAUTION Turn the dehumidifier off and remove the plug from the wall outlet before cleaning. A. Body clean Wipe the body with a soft, damp cloth. B. Clean the filter 1. Pull up to remove the air filter. 2. -
Page 15: Troubleshooting
Troubleshooting Before calling customer ser vice, review this list. It may save you time and expense. This list includes the most common occurr ences that are not the result of defective workmanship or materials in this dehumidifier. PROBLEM CAUSE - Make sure the dehumidifier’s plug is inserted completely into the outlet. -
Page 16: Safety Precautions
Safety Precautions Do not place unit on uneven Do not insert any sharp objects Do not operate unit near radiators, surface. into air inlet/airoutlet. kettles or any object that releases steam. Do not operate unit near windows Do not obstruct air inlet and outlet. Unplug power when the unit is not or doors opening to the outdoor. -
Page 17: Technical Specifications
Technical specifications DEHUMIDIFIER MODEL PD08D POWER SOURCE 120V～60Hz RATED POWER (95 ℉,80%RH) 373W RATED CURRENT(95 ℉,80%RH) 3.5A 15 Pints/Day(7.1L/Day) MOISTURE REMOVAL CAPACITY(65℉,60%RH) 23 Pints/Day(10.9L/Day) MOISTURE REMOVAL(80 ℉,60%RH) MOISTURE REMOVAL(86 ℉,80%RH) 40 Pints/Day(18.9L/Day) 50 Pints/Day(23.5L/Day) MOISTURE REMOVAL(95 ℉,90%RH) INPUT POWER( 65℉,60%RH) 215W INPUT CURRENT( 65℉,60%RH) -
Page 18: Warranty
Warranty HEVILLO offers a 12-month warranty on all of our products purchased new and unused. The warranty does not apply where damage is caused by other factors, E.g: (A) Normal wear and tear. (B) Abuse, mishandling, accident or failure to follow operating instructions. - Page 19 Scan the QR Code To Activate Warranty CUSTOMER SERVICE Email：info@ihevillo.com Company Website：www.ihevillo.com...
Need help?
Do you have a question about the PD08D and is the answer not in the manual?
Questions and answers
I need to replace the hose.
To replace the hose for the HEVILLO PD08D dehumidifier, follow these steps:
1. Unplug the power supply to ensure safety.
2. Remove the bucket from the dehumidifier.
3. Take off the drain outlet cover.
4. Insert the new water hose into the continuous drain outlet.
5. Push the water tank back into place.
6. Ensure proper drainage by positioning the hose at least 10cm (3.9 inches) lower than the continuous drain outlet and avoiding any bends in the hose.
7. Reconnect the power and start the dehumidifier.
This ensures smooth drainage and proper operation.
This answer is automatically generated
can I use any universal hose?
What size hose to get to drain
The HEVILLO PD08D dehumidifier uses a 6.56 feet drainage hose for auto drainage.
This answer is automatically generated
I plugged in the unit and after one minute it starts clicking continuously. The filter is clean and it is on continuous drain with the hose below the unit.
