- Page 1 Washing Machine User’s Manual WCV7512* WCV8612* WCV9612* EN VN...
- Page 2 This product was manufactured using the latest technology in environmentally friendly conditions.
-
Page 3: General Safety Instructions
General safety instructions This section includes security instructions which may help prevent the injuries and material damage risks. All kinds of warranties shall be invalid if these instructions are not observed. 1.1 Life and property safety Never place the product on a carpet-covered floor. Electrical parts will get overheated since air cannot circulate from under the device.This will cause problems with your product. -
Page 4: Important Instructions For Environment
The service life of your product is 10 years. During this period, original spare parts will be available to operate the appliance properly. Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark Beko Beko Beko Model name WCV7512XB0ST... - Page 5 4.1 Installation Apply to the nearest authorised service agent for the installation of your product. Preparation of the location and electrical, tap water and waste water installations at the place of installation is under customer's responsibility. Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or crushed while pushing the product into its place after installation or cleaning procedures.
- Page 6 CAUTION: laundry will get damaged or the product will switch to protection mode and will not operate. CAUTION: Do not use old or used water inlet hoses on the new product. It may cause stains on your laundry. Tighten the nuts of the hose by hand. Never use a tool when tightening the nuts.
- Page 7 4.1.7 Electrical connection Connect the product to a grounded outlet protected by a 16 A fuse. Our company shall not be liable for any damages that will arise when the product is used without grounding in accordance with the local regulations. •...
- Page 8 4.2.3 Things to be done for energy saving Following information will help you use the product in an ecological and energy-efficient manner. • Operate the product in the highest capacity allowed by the programme you have selected, but do not overload; see, "Programme and consumption table". See, “Programme and consumption table" •...
- Page 9 CAUTION: Use only detergents manufactured specifically for washing machines. CAUTION: Do not use soap powder. Adjusting detergent amount The amount of washing detergent to be used depends on the amount of laundry, the degree of soiling and water hardness. • Do not use amounts exceeding the dosage quantities recommended on the detergent package to avoid problems of excessive foam, poor rinsing, financial savings and finally, environmental protection.
- Page 10 • Do not use bleaching agent and detergent by mixing them. • Use just a little amount (approx. 50 ml) of bleaching agent and rinse the clothes very well as it causes skin irritation. Do not pour the bleach onto the laundry and do not use it with the colored items.
- Page 11 4.3 Operating the product 4.3.1 Control panel 90° 1200 60° 1000 40° 30° 20° 1 - Programme Selection knob (Uppermost 6 - Auxiliary function button 3 position On / Off) 7 - Auxiliary function button 2 2 - Display 8 - Auxiliary function button 1 3 - Delayed Start Button 9 - Spin Speed Adjustment button 4 - Programme Follow-up indicator...
- Page 12 4.3.4 Programme and consumption table WCV7512* Auxiliary functions Program 2.25 1600 Cold - 90 • • • • 1.70 1600 • • • • Cold - 90 Cottons 1.05 1600 Cold - 90 • • • • 20** 0.18 1600 •...
- Page 13 WCV8612* Auxiliary functions Program 2.40 1600 Cold - 90 • • • • 1.80 1600 • • • • Cold - 90 Cottons 0.97 1600 Cold - 90 • • • • 20** 0.267 1600 • • • • Cold - 90 0.90 1600 Cold - 60...
- Page 14 WCV9612* Auxiliary functions Program 2.50 1600 Cold - 90 • • • • 1.90 1600 • • • • Cold - 90 Cottons 0.99 1600 Cold - 90 • • • • 20** 0.21 1600 • • • • Cold - 90 1.10 1600 Cold - 60...
- Page 15 Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature,ambient temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage. You can see the washing duration on the display of your machine while selecting a programme. Depending on the amount of laundry you have loaded into your machine, there may be a difference of 1-1.5 hours between the duration shown on the display and the actual duration of the wash cycle.
- Page 16 • Hygiene Applying a steam step at the beginning of the programme allows to soften the dirt easily. Use this programme for your laundry (baby clothes, bed sheets, bedlinen,underwear, etc. cotton items) that requires an anti-allergic and hygienic washing at high temperature with intensive and long washing cycle.
- Page 17 • Select the stain programme. • Select the stain you want to clean by locating it in the groups above and selecting the related group with the quick auxiliary function button. • Read the garment tag carefully and ensure that correct temperature and spin speed are selected. 4.3.7 Special programmes For specific applications, select any of the following programmes.
- Page 18 4.3.10.1 Auxiliary functions • Prewash A Prewash is only worthwhile for heavily soiled laundry. Not using the Prewash will save energy, water, detergent and time. Prewash without detergent is recommended for tulle and curtains. • Fast+ When this function is selected, the durations of the relevant programmes get shorter by 50%. Thanks to the optimised washing steps, high mechanic activity and optimum water consumption, high washing performance is achieved in spite of the reduced duration.
- Page 19 and unload the machine. Just press any button or turn the programme selection knob to end the function. The programme follow-up light will remain on even if you end the function by pressing any button. If you end the function by turning the programme selection knob, the programme follow-up light will remain on or go off depending on the selected programme.
- Page 20 If the level is unsuitable, Loading Door light turns off and the loading door cannot be opened. If you are obliged to open the Loading Door while the Loading Door light is off, you must cancel the current programme. See. "Cancelling the programme" 4.3.15 Changing the selections after programme has started Switching the machine to pause mode Press the Start / Pause button to switch the machine to pause mode while a programme is running.
- Page 21 4.4 Maintenance and cleaning Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals. 4.4.1 Cleaning the detergent drawer Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time.
-
Page 22: Troubleshooting
CAUTION: Foreign substances left in the pump filter may damage your machine or may cause noise problem. CAUTION: If the product is not being used, shut the tap shut, remove mains pipe and drain the water inside the machine against any likely freezing. CAUTION: After each use, turn off the water tap to which the mains hose is connected. - Page 23 Problem Reason Solution Machine vibrates or makes noise. Machine might be standing unbalanced. Adjust the feet to level the machine. A hard substance might have entered into the Clean the pump filter. pump filter. Transportation safety bolts are not removed. Remove the transportation safety bolts.
- Page 24 Problem Reason Solution Washing performance is poor: Insufficient amount of detergent has been used Use the recommended amount of detergent Laundry turns gray. (**) over a long period of time. appropriate for water hardness and the laundry. Washing was made at low temperatures for a Select the proper temperature for the long time.
- Page 25 Problem Reason Solution Detergent residue in the Detergent is put in wet drawer. Dry the detergent drawer before putting in detergent drawer. (**) detergent. Detergent has gotten damp. Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
- Page 26 Máy giặt Hướng dẫn sử dụng...
- Page 27 Kính gửi Quý khách hàng, Xin vui lòng đọc hướng dẫn này trước khi sử dụng! Cảm ơn bạn vì đã tin dùng sản phẩm của Beko. Chúng tôi hy vọng được sản xuất với chất lượng cao và công nghệ...
- Page 28 Hướng dẫn chung về an toàn Phần này bao gồm các hướng dẫn an toàn có thể giúp tránh bị chấn thương và các rủi ro gây thiệt hại vật chất. Tất cả các loại bảo hành sẽ không có hiệu lực nếu không tuân theo các hướng dẫn này. 1.1 An toàn về...
-
Page 29: Đặc Tính Kỹ Thuật
• Sản phẩm của bạn có thời gian sử dụng là 10 năm. Trong thời gian này, sẽ có sẵn các phụ tùng dự phòng gốc để vận hành thiết bị đúng cách. Đặc tính kỹ thuật Tên nhà cung cấp hoặc nhãn hiệu thương mại Beko Beko Beko Tên dòng máy... - Page 36 90° 1200 60° 1000 40° 30° 20°...
- Page 37 4.3.4 Bảng chương trình và tiêu thụ WCV7512* Chức năng phụ Chương trình (°C) 2.25 1600 Lạnh - 90 • • • • 1.70 1600 • • • • Lạnh - 90 Vải cottons 1.05 1600 • • • • Lạnh - 90 20** 0.18...
- Page 38 WCV8612* Chức năng phụ Chương trình (°C) 2.40 1600 Lạnh - 90 • • • • 1.80 1600 • • • • Lạnh - 90 Vải cottons 0.97 1600 • • • • Lạnh - 90 20** 0.267 1600 • •...
- Page 39 WCV9612* Chức năng phụ Chương trình (°C) 2.50 1600 Lạnh - 90 • • • • 1.90 1600 • • • • Lạnh - 90 Vải cottons 0.99 1600 • • • • Lạnh - 90 20** 0.21 1600 • •...
- Page 40 / M1546 / M13985. Chương trình sử dụng hơi nước ngay từ ban đầu giúp làm mềm các vết bẩn trước khi giặt.
- Page 43 Ấn và giữ nút chức năng giặt sơ trong 3 giây để chuyển sang chương trình vệ sinh lồng giặt. Sử dụng chương trình này định kì từ 1 đến 2 tháng để duy trì điều kiện vệ sinh cần thiết.
- Page 52 5774450520/AA www.beko.com...
