FULL OVERVIEW
The large, bright 8-inch touch display provides
a clear overview, bringing the full range of
required functions to a single control desk. As a
result, control room staff can easily keep an eye
on everything, even in challenging situations.
MODULAR CONTROL DESK
The device can be extended with up to 5
physical direct dialling button modules.
Optional extras include a gooseneck
microphone and a handset as well as an input/
output module to suit individual needs.
ID8 TD/ID8 TD CM
CALL MANAGEMENT, SIMPLY FASTER
The id8 is a control desk of the Symphony MX product family. This allows shorter call answering times than ever before.
This way, the id8 makes workflows and processes more efficient while taking pressure off control room staff, thanks to the
convenient direct dialling buttons. Regardless of the application scenario, the control desk provides full control of the entire
security system to ensure that no emergency call goes undetected or unanswered.
Whether using a gooseneck microphone or a handset, users can rely on their message getting across in crystal clear voice
quality. That's Intercom at the highest level. Of course, the id8 is also fully compatible with previous-generation Commend
systems.
id8 data sheet – V1.0/1023
CYBER SECURITY
Ensuring the protection and security
of audio, video and customer data is
essential. At Commend, cyber security
is one of our topmost priorities.
trust.commend.com
CUSTOMISABLE DISPLAY LAYOUT
Various available layouts allow the control
desk's design to be customised to individual
user preferences and applications – not just for
offices but also for industrial environments.
Subject to change without notice.
PHYSICAL BUTTONS
The device comes with a freely configurable
button to complement touch interativity, which
can be extended further with direct dialling
modules. This takes user friendliness to
an even higher level.
CLEAR COMMUNICATION
The id8 loudspeaker is perfectly suited and
well prepared for loud environments. The
optional version with camera for bi-directional
video widens the choice of convenient
communication channels even further.
commend.com
P 1 / 12
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Commend ID8 TD
- Page 1 Whether using a gooseneck microphone or a handset, users can rely on their message getting across in crystal clear voice quality. That’s Intercom at the highest level. Of course, the id8 is also fully compatible with previous-generation Commend systems.
- Page 2 – Optionally available with built-in high-resolution colour video camera – Suitable for virtually any environment, for the desk(top) or for wall mounting – Based on Commend’s Symphony MX technology – ready for ID8 TD ID8 TD CM Symphony Cloud The control desk solution of the The Symphony MX control desk –...
- Page 3 SIP SERVER INTEGRATIONS In addition to Commend servers, devices can be Commend solutions can be connected to used with a multitude of SIP PBX systems. leading manufacturers systems – from video...
- Page 4 CYBER SECURITY AT COMMEND Because every word matters, high speech intelligibility is crucial in Security is above all a question of trust. At Commend, cyber security security and communication solutions. In everyday life, it enables as a core competence has always been given a very high priority.
-
Page 5: Technical Data
MECHANICAL PROPERTIES Keypad: illuminatable push-to-talk (PTT) button IP rating: IP20 using ID8 DK IP30 using ID8 SH or ID8 FB CAMERA (ID8 TD CM ONLY) IK rating: IK07 (acc. to EN 62262) Image sensor: RGB CMOS, 1/3 in Front panel: chemically strengthened glass, Lens: F2.2, fixed aperture... - Page 6 ACCESSORIES ID8 DK – The id8 desk kit provides excellent ID8 DKHS – The proven Commend handset with ID8 GM – A Gooseneck microphone for superior ergonomics while keeping a sleek look and desk kit extends your Symphony control desk audio quality that keeps your hands free and clutter free desk.
-
Page 7: Installation Instructions
– Connect the equipment into an outlet on a circuit different from – When mounting the Intercom station ID8 TD CM, pay attention to that to which the receiver is connected. the correct camera angle in terms of accessibility so that wheelchair Consult the dealer or an experienced radio/ TV technician for help. - Page 8 Measuring units in mm (in), not to scale! 16 (0.63) 245 (9.65) ID8 TD/ID8 TD CM WITH DESK KIT ID8 DK AND ID8 TD/ID8 TD CM WITH DESK KIT ID8 DK HANDSET WITH DESK KIT ID8 DKHS Measuring units in mm (in), not to scale! Measuring units in mm (in), not to scale! 111 (4.37)
- Page 9 ID8 TD/ID8 TD CM WITH DESK KIT ID8 DK AND GOOSENECK MICROPHONE ID8 GM Measuring units in mm (in), not to scale! 102 (4.01) 149 (5.87) max. 370 (14.6) ID8 TD/ID8 TD CM WITH GYPSUM WALL/PANEL MOUNT KIT ID8 FB...
- Page 10 ID8 TD/ID8 TD CM WITH SURFACE MOUNT KIT ID8 SH Measuring units in mm (in), not to scale! WALL KIT WITH HANDSET ID5 WMHS (WITH ID8 FB) WALL KIT HANDSET ID5 WMHS ( WITH ID8 SH) Measuring units in mm (in), not to scale! Measuring units in mm (in), not to scale! 50 (1.97)
- Page 11 To unmount the device, push firmly onto the locking latches gently remove the device upwards. If necessary, use a tool (i.e. a screw- driver) to push the locking latches in. commend.com id8 data sheet – V1.0/1023 Subject to change without notice.
- Page 12 NOTE: To prevent overextension and avoid premature wear, the gooseneck must not be bent more than 90°. Commend products are developed and manufactured by Commend International in Salzburg, Austria. Our development and ESSIVE manufacturing processes are certified in accordance with EN ISO 9001:2015. Since mid-2020 Commend International GmbH...
