ALC Truss tower systems demands reading and complete understanding of the instruction manual. It gives practical directives how to handle the ALC Truss products in general in a safe and efficient way. Only by carefully following the step-by-step actions during preparation, set-up and operation of the systems, a safe and successful production can be guaranteed.
TOWER mk2 Base system, which contains the necessary truss pins, hammers, screw jacks, nuts and bolts, MINI TOWER mk2 Top, Cantilever and the optional Platform and Roof. The system is designed to take a minimum of warehouse and transport space: L x W x H in mm.
When connecting two truss elements by a truss pin, make sure the cable (with the safety at the end) is perpendicular to the truss length. This makes the connection of the safety to the pin easier, since the cable length itself is kept at a minimum. MINI TOWER ALC Truss S-60-M2 INSTRUCTION MANUAL V1.0 4/21...
Page 5
Handling is easiest by two persons, who lift the first section slightly and then remove it from the pile, starting at the bottom. Use the inverse procedure to stack trusses of the same length. MINI TOWER ALC Truss S-60-M2 INSTRUCTION MANUAL V1.0 5/21...
• In any case, ALC-engineering does not take responsibility in any way for any of your actions during the preparations, set-up, operation and the lowering and packing of the tower system.
Page 11
S-60-M2B (Base). Screw the rubber cap onto the Screw Jack. Step 9 : Raise the leg. Step 10 : Connect with S-60-M2F (Leg Fastener) MINI TOWER ALC Truss S-60-M2 INSTRUCTION MANUAL V1.0 11/21...
Page 12
Treat the second leg exactly like the first leg. Step 8 Step 12 : Grab the Leg and pull the direction of the arrow until the inserted S-60-M2S (screw jack) touches the floor. MINI TOWER ALC Truss S-60-M2 INSTRUCTION MANUAL V1.0 12/21...
Page 13
S-60-24 with three (3) Truss Pins S-60-TP the previous Stackable Truss section S-60-24 Step 16 : Connect the Top piece S-60-M2T with one (1) Truss Pins S-60-TP Stackable Truss section S-60-24 MINI TOWER ALC Truss S-60-M2 INSTRUCTION MANUAL V1.0 13/21...
Page 14
S-60-TP. Step 20 : Place a chain hoist of ½ or 1 ton, in its flight case next to the Cantilever S-60-M2C MINI TOWER ALC Truss S-60-M2 INSTRUCTION MANUAL V1.0 14/21...
Page 15
Cantilever by the designated Truss Pin S-60-TP Step 23 : Connect the swivel hook of the chain to the appropriate hole on the base by means of a shackle MINI TOWER ALC Truss S-60-M2 INSTRUCTION MANUAL V1.0 15/21...
Page 16
Step 24 : Let the chain hoist lift out of its case by its own power Step 25 : Lower the chain hoist and connect it by a shackle onto the Cantilever MINI TOWER ALC Truss S-60-M2 INSTRUCTION MANUAL V1.0 16/21...
For a smooth operation, the last part must be done manually ! Step 27 : Attach the mast to the Base by fitting the third Truss Pin S-60-TP MINI TOWER ALC Truss S-60-M2 INSTRUCTION MANUAL V1.0 17/21...
Page 18
Step 28 : Level the MINI TOWER mk2 by adjusting the Screw Jacks S-60-M2S Step 29 : Left to Right Make sure the chain hangs parallel to the mast Step 30 : Front to Rear Make sure the chain hangs parallel to the mast 1 meter - 40 in.
Page 19
Step 31 : Fly your line array The illustration shows the use of both front and rear suspension points MINI TOWER ALC Truss S-60-M2 INSTRUCTION MANUAL V1.0 19/21...
Page 20
Step 32 : Place the optional Platform S-60-M2P Make sure the MINI TOWER mk2 mast is perfectly vertical anytime. Check the verticality of the mast after completing the installation of the MINI TOWER mk2 including the full ballast. If this is NOT the case, one has to correct this by means of the screw jacks !
