- Page 1 ELECTRICAL INSTALLERS GUIDE For models: Single Phase 7.4kW 230V VEVA TETHERED & VEVA UNTETHERED Electric Vehicle Charge Points...
- Page 2 CONTENTS This guide is intended for qualified electrical installers and provides information on the electrical installation of a VEVA charging unit and includes the following information... Safety Information and advice Description of the parts supplied General Features of the unit Wiring Diagram Fixing and installation How to wire the unit, supply requirements and connection...
- Page 3 SAFETY ADVICE • The electrical installation of this device must only be undertaken by a suitably trained and qualified electrician. • All work must satisfy Building/IEE Wiring regulations in force at the time. • Failure to comply with these installation instructions may result in damage to the unit and invalidate the warranty.
- Page 4 GENERAL FEATURES VEVA UNTETHERED VEVA TETHERED Removable front facia assembly Ring Light status indicator Holster (Tethered unit only) Tethered charging cable (8m length) Type 2 Charging socket with integral cable lock (Untethered unit only) The VEVA charging unit is designed to allow a tethered charging cable to be wrapped around the body of the unit for cable stowage.
- Page 5 WIRING DIAGRAM Consumer Unit Home Router Electricity Meter 12345 Connector We recommend the use of a combined power and Blocks data cable (3 core power cable, with integrated 2 (if fitted) core screened data cable or CAT 5 data cable) Regular power cabling plus separate CAT 5 data cable when extending the measurement clamp Measuring...
- Page 6 INSTALLATION Locating the unit - To operate fully, the VEVA must have a Wi-Fi connection. Before in- stalling, check the chosen location has good signal strength to the users Wi-Fi network. • Check for a Wi-Fi signal at the installation location using a mobile phone. •...
- Page 7 4. Install cable entry. Select one of the Spirit six possible cable entry locations level shown opposite. • When cable entry is from the back of the unit, use the cable grommet supplied (not the gland). Main • Cut a 25mm hole to fit either the Seal cable gland or grommet.
- Page 8 WIRING THE UNIT SUPPLY The VEVA unit should be connected to a 230V nominal AC supply using a cable with a conductor CSA suitable for the installation run, and selected according to the current wiring regulations. The supply should be run from a dedicated 32A* circuit breaker to provide isolation and overcurrent protection.
- Page 9 EARTHING ARRANGEMENTS The VEVA unit features on-board safety monitoring to provide protection to the user against electric shock in the event that the PEN conductor becomes damaged or disconnected. The unit continuously monitors the incoming supply to detect problems with the PEN conductor, and if so, automatically disconnects the supply to the output of the charger.
- Page 10 INSTALLING THE MEASUREMENT CLAMP The measurement clamp must be fitted if Charging by Solar or the dynamic Demand Control functions are to be used. The measurement clamp is a sensor used to monitor the current flowing to, or from, the grid.
- Page 11 COMMISSIONING AND TESTING Before commissioning, the installer must carry out sufficient checks to ensure the installation is compliant with the requirements of BS7671: 2018. COMMISSIONING PROCESS To commission the VEVA unit, you will need to download the VEVA app... 1. Search for VEVA in the App Store or on Google Play and install the app onto your smartphone There is no need to create an account.
- Page 12 2. CONNECTING TO THE VEVA UNIT The commissioning process is carried out by connecting your mobile device to a Wi-Fi hotspot created by the VEVA unit. Connection is simple as follows... 1. Push the Wi-Fi pair button. Pairing With the front fascia removed, power up the unit. button Push down on the Wi-Fi pairing button and hold for two seconds.
- Page 13 3. SET UP AND ELECTRICAL TESTING Using the Charger Settings page, set up and test the following... 3. Configure settings for the installed unit: • Current measuring clamp fitted – Select whether a measurement clamp has been fitted, yes/no. • Demand Control Supply rating –...
- Page 14 5. Wi-Fi SET UP After all tests are completed, the VEVA unit may be connected to the homeowners Wi-Fi network. From the Charger Settings page, select “Connect charge point to Wi-Fi” to con- tinue with Wi-Fi set up or “Skip Wi-Fi setup” if you are unable to do so at this point. To set up a Wi-Fi connection follow as below...
- Page 15 TECHNICAL SPECIFICATIONS PRODUCT INFORMATION CHARGING CONNECTOR (DEPENDANT ON MODEL): VEVA TETHERED: Type 2 Tethered Cable (8 metre length) VEVA UNTETHERED: Type 2 Socket with lock CHARGING PROTOCOL: Mode 3 Charging (according to IEC 61851-1) MOUNTING TYPE / LOCATION: Indoor or Outdoor (permanent mounting) CHARGING CURRENT Variable 6A –...
- Page 16 If there’s anything you’d like help with or to send us feedback on how to improve our services and devices, please don’t hesitate to contact us: support@vevacharger.com tel: 01536 447861 www.vevacharger.com Version 1.0 290623...
