OCTANE
Seat Connector Kit Instructions

Where to find the Seat Connector Kit

Scan this QR code for an
instructional video.
https://vimeo.com/696205281
Tip the seat over and locate the Velcro strip on the attached arm. Open it to
expose the inside compartment of the arm. The Seat Connector Kit will be
in a bag attached to the inside of the arm.

Seat Connector Kit Contents

- or -
Qty (4) Wing Screws
Qty (2) Right Arm Brackets
Qty (2) Left Arm Brackets
Open the fabric covering the arm and locate the threaded holes. There will be 2
on each side, for a total of 4.
Seat-Connector-Kit-Instructions-v.2022-2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Seat Connector Kit and is the answer not in the manual?

Questions and answers

Related Manuals for Octane Seating Seat Connector Kit

Summary of Contents for Octane Seating Seat Connector Kit

  • Page 1 Tip the seat over and locate the Velcro strip on the attached arm. Open it to expose the inside compartment of the arm. The Seat Connector Kit will be in a bag attached to the inside of the arm.
  • Page 2 OCTANE Seat Connector Kit Instructions Slide each of the Brackets onto the arm and line it up with the threaded holes (there will be pre-cut slits in the cover for each bracket). Screw the Wing Screws through the Brackets into the pre-drilled threaded holes.
  • Page 3 OCTANE Seat Connector Kit Instructions Once the Brackets are attached, close the fabric cover using the Velcro strip. Turn the seat back upright. Attach the seat to the chair next to it by slightly lifting it up and positioning it into the bracket of the connecting seat.
