Draper WTM1 Original Instructions

MECHANICAL
WATER TIMER
36748
(1)
(2)
(3)
Read this manual in full before using this product
and retain it for future use. Always use the latest
version of the manual, available from
drapertools.com/manuals
1. Intended Use
This product is designed for controlling water
flow directly from the tap and is suitable for
applications such as irrigation hoses and
sprinklers. The product functions like an egg
timer: water flow can be enabled for a designated
period of time or left on indefinitely with manual
cut-off. Any other application beyond the
conditions established for use will be considered
misuse. Draper Tools accepts no responsibility for
improper use of this product.
Important: This product is suitable for use with
clean water ONLY. DO NOT attempt to use this
product to control the flow of any other liquid.
Draper Tools Limited, Hursley Road, Chandler's Ford, Eastleigh, Hampshire, SO53 1YF
(4)
(5)
2. Specification
Stock No. 36748
Part No. WTM1
Max. watering time: 120mins
1" BSP female with 3/4" BSP
Inlet
female adaptor ring and filter
3/4" BSP male with 1/2"
Outlet
hose connector
Recommended
0.5–12bar
water pressure
Recommended
6–60°C
operating temp.
Recommended
Cold mains water
water source
Website: drapertools.com
EN
Original Instructions
Version 3 – March 2023
(1) Timer dial
(2) Inlet
(3) Inlet reducer and filter
(4) Outlet
(5) Hose connector
