GENERAL
Power Requirements:
Power Consumption:
Dimensions:
Weight:
FM
SECTION
Tuning Range:
Antenna:
Intermediate
Frequency:
Sensitivity at
50d8 Quieting:
SPECIFICATIONS
240 V ac, 50 Hz (UK model)
120 V, 220 V or 240 V ac adjustable,
50 Hz (AEP model)
110 W (UK model)
95 W (AEP model)
Approx.
410 (w) x 145 (h) x 305 (d) mm
16 (w) x 5 % (h) x 12 (d) inches
including projecting parts and controls.
5.9 kg, 13 Ib (net)
Approx.
7.1 kg, 15 1b 11 oz {in shipping carton)
87.5 — 108 MHz
300 2 balanced
75 2 unbalanced
10.7 MHz
4 nV (12 dB) (MONO)
45 nV (33 dB) (STEREO)
Sensitivity at
46dB Quieting:
(at 40kHz deviation)
Usable Sensitivity:
S/N Ratio:
Harmonic
Distortion:
IM Distortion:
Separation:
Frequency Response:
AEP
Model
UK Model
4.5 uV (13 dB) (MONO)
50 uV (34 dB) (STEREO)
1.9 nV (5.5 dB), tHE
1.7 nV (4.5 dB), S/N = 26 dB
(40 kHz deviation)
73 dB (MONO)
68 dB (STEREO)
At 1 kHz
0.3 % (MONO)
0.5 % (STEREO)
0.3 % (MONO)
0.5 % (STEREO)
45 dB at 1 kHz
40 — 12,500 Hz *°:
+0.
30 — 15,000 Hz ">
— Continued on page 2 —
SAFETY-RELATED
COMPONENT
WARNING!!
COMPONENTS
IDENTIFIED
BY
SHADING
AND
MARK
A
ON
THE
SCHEMATIC
DIAGRAMS,
EXPLODED
VIEWS
AND
IN THE
PARTS
LIST
ARE
CRITICAL
TO
SAFE
OPERATION.
REPLACE
THESE
COMPONENTS
WITH
SONY
PARTS
WHOSE
PART
NUMBERS
APPEAR
AS
SHOWN
IN
THIS
MANUAL
OR
IN SUPPLEMENTS
PUBLISHED
BY SONY.
®
SERVICE MANUAL
