KMC Controls BAC-5051AE Installation Manual

Complete the following steps to install a
Conquest™ BAC-5051AE BACnet Router.
Refer to the Conquest BAC-5051AE BACnet
Router data sheet for router specific information
on the web at kmccontrols.com.

INSTALL CONTROLLER

NOTE: Complete steps 1–2 to install the
router with screws.
Complete steps 3–7 to install the
router on a 35 mm DIN rail.
NOTE: Install the router in a metal UL
approved energy management
equipment panel.
1. Position the router so the removable color
coded terminal blocks
for wiring.
NOTE: The black terminals are for power. The
gray terminals are for communication.
2. Screw a #6 sheet metal screw through the
mounting tab of the DIN Latch on each end of
the router 2 .
2
NOTE: Pull out each DIN Latch mounting tab
one click to be 6 inches on center for
mounting.
KMC Controls, 19476 Industrial Drive, New Paris, IN 46553
BAC-5051AE BACnet Router
1 are easy to access
1
NOTE: Complete steps 3–7 to install the
router on a 35 mm DIN rail.
3. Position the DIN rail
router is installed the color coded terminal
blocks are easy to access for wiring.
4. Pull out one DIN Latch
5. Position the router so the top tab
DIN release rests on the DIN rail.
6. Lower the router against the DIN rail.
7. Push in both DIN Latch
rail.
NOTE: To remove the router, pull the DIN
Latch until it clicks once and lift the
router off the DIN rail.
3
5
/ 877-444-5622 / Fax: 574-831-5252
Installation Guide
3 so that when the
4 until it clicks once.
of the
5
4 to engage the DIN
/ www.kmccontrols.com
4
