Summary of Contents for Giorik 2CPG
- Page 1 GAS PASTA COOKER EN - CPG726 - 2CPG CPG746 - 22CPG CPG926 - 3CPG CPG946 - 23CPG ENGLISH: Installation, Use and Maintenance Manual 01/2020 Rev.1_07/2023...
-
Page 3: Table Of Contents
Contents 1. INSTALLATION 1.1 General and safety warnings ..........5 1.2 Positioning ................9 1.3 Equipotential ..............10 1.4 Smoke exhaust ..............10 1.5 Water connection .............10 1.7 Gas Connection ..............11 1.8 Transformation for use with Different Gas .......13 1.8.1 Replacement of the main burner nozzle .....13 1.8.2 Main Burner Primary Air Regulation ......14 1.8.3 Replacement of the Pilot Burner Nozzle .....14 1.8.4 Adjusting the reduced flow rate .........15... -
Page 5: Installation
1. INSTALLATION 1.1 General and safety warnings • Read this manual removed, make sure carefully before installing the appliance is in good and operating the devices condition and there is no because the text provides damage caused during important information about transportation. - Page 6 • The appliances connected • The appliance was designed to a potable water supply cook foodstuffs (temporarily o permanently) indoor environments and shall installed must only be used for this accordance with national function. Any different use regulations. must therefore be avoided as it is considered improper and dangerous.
- Page 7 with nor use the appliance. the equipment. • During operation it is • In the event of prolonged necessary to pay attention non-use of the appliance, to the hot areas of the the gas must be turned off. external surface appliance which, in operating •...
- Page 8 to the appliance, provides important information: this is essential if interventions must requested maintenance or repairs of the appliance; therefore, it must not be removed, damaged or modified. • After installation, recommended set-up a scheduled maintenance plan (at least once a year), performed qualified personnel.
-
Page 9: Positioning
1.2 Positioning The appliance was designed to be installed in enclosed spaces. It cannot be used outdoors and must be exposed to atmospheric agents. The place designated for the installation of the appliance must have a rigid, level and horizontal surface, which must be able to safely support the weight of the appliance (approx. -
Page 10: Equipotential
1.3 Equipotential The appliance must be included within an equipotential system whose efficiency is checked in compliance with the standards in force. For the connection use the clamp, placed on the frame and marked with the symbol Fig.3. If the appliance is installed in the vicinity of other household appliances, ensure the electrical cables and pipes are sufficiently Fig. -
Page 11: Gas Connection
The maximum water pressure allowed is 6 bar. The appliance must be supplied with drinking water for correct installation and operation. The water inlet pipe must be connected to the mains water supply with a shut-off valve (example Fig.5), which can be easily closed when the pasta cooker is not in use or requires Fig. - Page 12 for use with G20 gas at a pressure of 20 mbar, unless requested differently on placing the order. Do not reduce the diameter of the section GASKET SEAL between the reducer and the appliance. Fit a gas filter above the pressure adjuster in order to ensure optimum operation.
-
Page 13: Transformation For Use With Different Gas
Checking Gas Pressure: The supply gas pressure must be measured at the height of the pressure outlet (Fig.7) after removing the seal screws. Use a flexible pipe, connect a gauge to the pressure point (e.g. a liquid manometer with minimum resolution of 0.1 mbar) and measure the inlet pressure whilst the appliance is operating. -
Page 14: Main Burner Primary Air Regulation
• Close the gas valve upstream of the appliance • Open the door or doors. • unscrew the nozzle (Ref.A-Fig.8) and replace it with the one corresponding to the gas chosen as indicated on the technical plate. The nozzles are marked in hundredths of a millimetre. 1.8.2 Main Burner Primary Air Regulation •... -
Page 15: Adjusting The Reduced Flow Rate
To replace the pilot nozzle, proceed as follows: • Close the gas valve upstream of the appliance; • open the door or doors; unscrew the spark plug nut (Fig.10 - Ref.1); • • unscrew the screw-on cap (Ref.2); • remove the nozzle (Ref.3) and replace it with the one for the type of gas chosen;... - Page 16 When conversion or adaptation has been completed for every type of gas, it is MANDATORY to affix the corresponding plate above the technical plate, which is provided along with the nozzles. Once the operations for the gas type conversion have been completed, check the seal of the dismantled parts with the soap water test or with the foam solution indicated.
-
Page 17: General Instructions For Use
2. GENERAL INSTRUCTIONS FOR USE 2.1 Commissioning This appliance allows you to cook food (pasta, rice, etc.) in boiling water through the use of perforated baskets (Fig.12). Any other use should be avoided as it is considered improper and dangerous. Water inlet Level... -
Page 18: Switching On And Off
baskets, basket supports (on the bottom of the tank) and basket support rack (on the top) which can be washed in the dishwasher (the baskets must be thoroughly rinsed and dried after washing) and the tank as follows: • open the water top on the front panel (Fig.14) and fill the tank up to the overflow hole with water and normal detergent, start the appliance, bring the water to the boil and allow it to boil for a few minutes;... -
Page 19: Lighting The Pilot
2.2.1 Lighting the pilot Open the gas valve upstream of the appliance. Open the cabinet door(s). Press and turn the knob (Fig.16) to the pilot position while repeatedly pressing the piezoelectric ignition button (located inside the cabinet (Fig. 13) until the pilot is lit. -
Page 20: Maintenance And Cleaning
an open siphon. If necessary, place a metal container under the appliance that is big enough to collect all the water in the tank. Watch out for splashes of boiling water! 3. MAINTENANCE and CLEANING Before doing any cleaning, close the gas shut-off valve upstream of the appliance. -
Page 21: Maintenace
3.2 Maintenace At least once a year, perform a thorough check to inspect the gas circuit seal and the components. All routine and special maintenance must be performed by qualified personnel. Do not adjust point protected by sealing varisch. Periodically is recommended the greasing of gas taps. 3.3 Spare Parts Parts likely to need replacing during the life of appliance: •... -
Page 22: Technical Specifications
4. TECHNICAL SPECIFICATIONS MAIN BURNER NOZZLES MODEL CODE 30/37 18/20 mbar mbar mbar mbar 2CPG CPG726 165L 145L 250L 275L 22CPG CPG746 2X26 165L 145L 250L 275L 3CPG CPG926 215L 190L 310L 345L 23CPG CPG946 2x40 215L 190L 310L 345L... - Page 23 Primary Air Regulation PILOT BURNER NOZZLES By pass adjustment Distance “X” 30/37 18/20 30/37 18/20 30/37 18/20 mbar mbar mbar mbar mbar mbar mbar mbar mbar mbar mbar mbar Reg. Reg. Reg. Reg. Reg. Reg. Reg. Reg.
-
Page 24: Disposal Of The Appliance
5. DISPOSAL OF THE APPLIANCE At the end of its life span, the appliance must be disposed of in accordance with legal obligations. The symbol in Fig. 18 specifies that, at the end of its life span, the appliance must be disposed of according to the indications of the European Parliament Directive 2012/19/EU dated 04/06/2012. - Page 28 THE MANUFACTURER SHALL NOT BE HELD LIABLE FOR ANY DAMAGES DUE TO IMPROPER INSTALLATION, TAMPERING WITH THE APPLIANCE, MISUSE, IMPROPER MAINTENANCE, FAILURE TO COMPLY WITH APPLICABLE STANDARDS AND INTENDED USE. THE MANUFACTURER RESERVES THE RIGHT TO MAKE CHANGES TO THE PRODUCT AT ANY TIME IT DEEMS NECESSARY OR USEFUL.
