Summary of Contents for ConvaQuip 3200/P
- Page 1 Digital Scales Model 3200/P Instruction Manual Platform Scales ConvaQuip Ind., Inc. P.O. Box 3417 Abilene, TX 79604 800-637-8436 www.convaquip.com email: info@convaquip.com...
-
Page 2: Table Of Contents
Contents YOUR NEW SCALE ....................................3 .........................................3 EATURES ......................................3 RECAUTIONS ................................3 ONDITIONS FOR EIGHING ................................3 NITIAL P AND PERATION CONTROLS AND INDICATORS................................4 ....................................4 ISPLAY CREEN ..................................5 RONT ANEL EYBOARD Main Function Keys.....................................5 Menu Navigation Keys..................................5 Secondary Function Keys ..................................5 SYSTEM OPERATION ...................................6 ..................................6 ASIC PERATION... -
Page 3: Your New Scale
Your New Scale Congratulations on your purchase of an ConvaQuip Digital Scale. This Scale offers a combination of versatility, accuracy and simplicity in an easy to use and easy to maintain package. Advanced menu driven operating software, large memory capacity and an easy to use menu structure allows the scale to be configured for almost any application. To obtain the best performance and greatest utilization from your scale, read this instruction booklet completely and carefully. -
Page 4: Controls And Indicators
4) If your scale comes equipped with ramps, fix them to the floor using the mounting holes provided. This way the ramp will not move during normal use. Be careful not to let the scale platform rub up against the ramp or any other surface, as this would cause non-repeatability of other inaccuracies. -
Page 5: Front Panel / Keyboard
Front Panel / Keyboard The front panel has a twelve button, click touch key panel that allows easy menu navigation as well as full text and floating point entry. The main scale functions are shown in black, menu navigation and floating point numeric entry keys are blue and the secondary functions are yellow. -
Page 6: System Operation
System Operation Basic Menu Operation The scale operating system uses a menu driven interface that is both intuitive and easy to use. To access the setup menu press the MENU/BACK key. There are two basic menu types. The first is a simple list of items. To select an item in the list, use the UP and DOWN ARROW keys to line up on the desired item and then press ENTER. -
Page 7: Sample Acquisition
Sample Acquisition There are two methods for acquiring samples. First is the “Quick Sample” method and the second is to define a sample in the scale’s memory for permanent storage. In general the more parts that you use during your sample acquisition the more accurate your parts counting will be. -
Page 8: Text Descriptions
Text Descriptions Many items carry descriptions, which can be changed at any time. These descriptions are useful in the case of tares and counting samples because the descriptions are shown on the display when activated, eliminating confusion. The scale itself also has a description and ID number that can be changed in the SETUP MENU/SYSTEM/SCALE DESCRIPTION menu. -
Page 9: Configuration And Calibration
Erase User Memory The entire user memory can be erased at one time, if necessary, using this option. It will erase all user-defined tares, counting samples, text definitions, print frames and set points but will leave platforms and other system memory intact. Revision Number Reads out the current operating system revision number. -
Page 10: Calibration And Troubleshooting
Resolution-Overload Each platform has the capability of displaying its reading in any of eight standard conversion units. Only four are enabled by default and the user can enable the rest. The conversion units that are automatically enabled are pounds, kilograms, grams and ounces. -
Page 11: Scale Reading Is Different On Different Areas On The Platform
Scale reading is different on different areas on the platform? • On platform scales, check that all four level legs are solid against the floor. If a level leg is screwed in all the way then the stud from the level leg may be contacting the underside of the platform not allowing the load sensor to flex. •... -
Page 12: Menu Tree Diagram
Menu Tree Diagram The following menu tree will help you navigate through the various system menus. SETUP MENU Next Screen Tares Tare List Actv Edit Descr Value Acqui Parts Counting Samples List Actv Edit Descr Value Acqui Platform Setups Platform List (scales with multiple platforms only) Actv Edit Edit Description... -
Page 13: Specifications
FITNESS FOR A PARTICULAR PURPOSE. CONVAQUIP WILL NOT, IN ANY EVENT, BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. CONVAQUIP AND BUYER AGREE THAT CONVAQUIP SOLE AND EXCLUSIVE LIABILITY HEREUNDER IS LIMITED TO REPAIR OR REPLACEMENT OF SUCH GOODS. IN ACCEPTING THIS WARRANTY, THE BUYER WAIVES ANY AND ALL OTHER CLAIMS TO WARRANTY.
