- Page 1 E M C C o m p o n e n t s May 2017 Noise suppression filter for audio lines For FM bands MAF series MAF1005F type MAF1005F 1005 [0402 inch]* * Dimensions code: JIS[EIA]...
-
Page 2: Safety Reminders
(2/9) E M C C o m p o n e n t s REMINDERS FOR USING THESE PRODUCTS Before using these products, be sure to request the delivery specifications. SAFETY REMINDERS Please pay sufficient attention to the warnings for safe designing when using this products. REMINDERS The storage period is less than 12 months. - Page 3 The storage temperature range is for after the circuit board is mounted. RoHS Directive Compliant Product: See the following for more details.https://product.tdk.com/info/en/environment/rohs/index.html Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm.
-
Page 4: Recommended Reflow Profile
(4/9) E M C C o m p o n e n t s MAF1005F type RECOMMENDED REFLOW PROFILE Preheating Soldering Natural cooling Peak Time Preheating Soldering Peak Temp. Time Temp. Time Temp. Time 150°C 180°C 60 to 120s 230°C 30 to 60s 250 to 260°C Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. - Page 5 (5/9) E M C C o m p o n e n t s MAF1005F type SHAPE & DIMENSIONS 0.10min. 0.10min. 1.00±0.05 Dimensions in mm RECOMMENDED LAND PATTERN Dimensions in mm Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading.
-
Page 6: Electrical Characteristics
(6/9) E M C C o m p o n e n t s MAF1005F type ELECTRICAL CHARACTERISTICS CHARACTERISTICS SPECIFICATION TABLES Impedance DC resistance Rated current Part No. [100MHz] ( )typ. ( )typ. ( )max. (mA)max. 1000 0.75 0.90 MAF1005FSA102AT000 ○... - Page 7 (7/9) E M C C o m p o n e n t s MAF1005F type ELECTRICAL CHARACTERISTICS Z FREQUENCY CHARACTERISTICS 2000 1800 1600 1400 1200 1000 1000 10000 Frequency ( MHz ) INSERTION LOSS VS. FREQUENCY CHARACTERISTICS 1000 10000 Frequency ( MHz ) Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.
- Page 8 (8/9) E M C C o m p o n e n t s MAF1005F type ELECTRICAL CHARACTERISTICS Z, X, R VS. FREQUENCY CHARACTERISTICS MAF1005FSA102AT000 2000 1800 1600 1400 1200 1000 1000 10000 Frequency ( MHz ) Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading.
- Page 9 (9/9) E M C C o m p o n e n t s MAF1005F type PACKAGING STYLES REEL DIMENSIONS 2.0±0.5 +2.0 ø13±0.2 –0.0 ø21±0.8 14.4max. ø180±2.0 Dimensions in mm TAPE DIMENSIONS 2.0±0.05 4.0±0.1 +0.1 Dimensions in mm Type MAF1005F 0.65±0.1 1.15±0.1 2.0±0.05...
