OPERATOR'S MANUAL
2-Ton Folding Engine Crane
! !
WARNING:
IMPORTANT: READ THESE INSTRUCTIONS AND ALL
WARNINGS PRIOR TO USING THIS EQUIPMENT. UNDERSTAND
ALL OPERATING PROCEDURES, SAFETY WARNINGS AND
MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD
CAUSE AN ACCIDENT RESULTING IN SERIOUS OR FATAL
INJURY AND/OR PERSONAL PROPERTY DAMAGE.
PROD. NO. 030319
MOD. NO. 216-1
030319-INST-1222
Advertisement
Table of Contents
Summary of Contents for Surewerx STRONGARM 216-1
- Page 1 PROD. NO. 030319 MOD. NO. 216-1 OPERATOR’S MANUAL 2-Ton Folding Engine Crane WARNING: IMPORTANT: READ THESE INSTRUCTIONS AND ALL WARNINGS PRIOR TO USING THIS EQUIPMENT. UNDERSTAND ALL OPERATING PROCEDURES, SAFETY WARNINGS AND MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD CAUSE AN ACCIDENT RESULTING IN SERIOUS OR FATAL INJURY AND/OR PERSONAL PROPERTY DAMAGE.
-
Page 2: Package Contents
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. WARNING: Indicates a hazardous situation which, if not avoided, could result in death or serious injury surewerx.com... -
Page 3: Warning Information
A moment of inattention while operating jacks may result in serious personal injury. • Maintain labels and nameplates on the engine crane. These carry important information. surewerx.com... - Page 4 8. Slide the boom extension into the boo and use the bolt, washer, and nut to secure at the desired load rating. Use the bolt, washer, and nut to attach the hook and chain to the end of the boom extension. surewerx.com...
- Page 5 surewerx.com...
-
Page 6: Lifting And Lowering
3. Raise leg until it rests against handle. 4. Insert a front ring pin into the middle hole of the base for each leg and reinsert R-pins. NOTE: Be certain that when unfolding, both ring pins and R-pins are placed back in the proper places. surewerx.com... -
Page 7: Bleeding Instructions
D. Open the valve release screw and pump the handle to bleed air from the system. E. Reinstall the oil filler plug. 4. Wipe dry with a clean cloth. Then, store the jack in a safe, dry location out of reach of children and other non-authorized people. surewerx.com... -
Page 8: Troubleshooting
2. Manually lift the chain / hook several inches. 3. Open the release valve and force the chain/ hook down as quickly as possible. Oil leaking from filler plug Unit may have too much hydraulic oil inside. Check fluid level and adjust if needed. surewerx.com... - Page 9 PUMP HANDLE PCN-216-1P22 WASHER PCN-216-1P36 R-PIN PCN-216-1P09 MAIN SUPPORT POST PCN-216-1P23 BOLT PCN-216-1P37 CASTER A PCN-216-1P10 BOLT PCN-216-1P24 WASHER PCN-216-1P46 HOOK ASSEMBLY 38-49 PCN-216-1P11 BOLT PCN-216-1P25 PCN-216-1P12 BOLT PCN-216-1P26 PCN-216-1P13 BUSHING PCN-216-1P27 PCN-216-1P14 PLASTIC COVER PCN-216-1P28 FRAME PIN W/HAIR PIN surewerx.com...
-
Page 10: Specifications
498 mm 1,656 mm 1,000 mm 800 mm 1,530 mm Ф90x31 Ф90x31 Ф75x28 Boom Extensions Position Capacity Capacity Boom (tons) (lbs) Length Height Height 1,000 54.7" 88.2" 2,000 47.6" 82.9" 1-1/2 3,000 40.6" 9.4" 77.4" 4,000 33.5" 15.7" 72.1" surewerx.com...
