Speedway 52178 Operating Lnstructions

Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

lmportant Operating lnstructions
Bigfoot Racer Wagon
DO NOT RETURN TO STORE.
Please CALL 1-800-348-5004
for parts and service.
Important!
Please read the complete
operating manual with due care.
Keep this manual in a safe place,
so that the information is available
at all times. If you give the
equipment to any other person,
give them these operating
instructions as well. We accept no
liability for damage or accidents
which arise due to non-
observance of these instructions
and the safety information herein.
SPECIFICATIONS
Tires: (4) Pneumatic 10
Deck Size: 33-1/2 x 15-1/2 x 5-
1/2
Max. Weight Capacity: 300 Lbs.
UNPACKING
When unpacking your wagon,
check to make sure the following
parts are included. The Parts list is
located on page 6.
For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping.
For Customer Service, Call 1-800-348-5004
or e-mail customerservice@focus-ontools.com
SAFETY
Do not operate this product if you
are under the influence of alcohol
or drugs. Read warning labels on
prescriptions to determine if your
reflexes and/or judgment may be
impaired.
Be careful not to get fingers,
hands, or feet under the tires.
Protective gloves and non-skid
footwear is recommended.
Be very cautious when going
over steps and curbs.
Be careful when navigating the
wagon on rough terrain.
Do not exceed the maximum
weight capacity of 300 Lbs.
Wagon is not designed for
passenger use.
For ages 5 and up. Use only
under adult supervision.
1
52178/53486/53487
BEFORE OPERATING
Insure that all of the screws
are tight and nothing appears
to be damaged. Do not use if
the wagon does not appear to
function properly.
Do not over inflate the tires.
Check the instructions for
proper air pressure.
Inspect all parts for sharp
edges before using your
wagon. Sharp edges may
cause injury.
Make certain to park the
wagon on a level and secure
area.
ASSEMBLY
Read and follow the
assembly steps carefully.
WARNING:
The product is to be assembled
by adult
52178
07/2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 52178 and is the answer not in the manual?

Questions and answers

Summary of Contents for Speedway 52178

  • Page 1 Operating lnstructions Bigfoot Racer Wagon 52178/53486/53487 SAFETY BEFORE OPERATING DO NOT RETURN TO STORE. Please CALL 1-800-348-5004 Do not operate this product if you Insure that all of the screws for parts and service. are under the influence of alcohol are tight and nothing appears or drugs.
  • Page 2 Step 1 - Step 2 - Take Wagon out of Rear Support Assembly Carton Attach the rear axle support (2) to the bed using 16mm bolts (10), 6mm washers (11), 6mm Spring washers (12), and 6mm nuts (9). Remove the wagon and its pieces from the box.
  • Page 3 Step 3 - Front Support Assembly Attach front support -1(5) and front support -2(6) with bolts (13), washers (14), lock washers (15), nuts (16), and pins (17). NOTE: Make sure the pin is bended as the diagram shown. Attach the assembled front support (5, 6) to the bed using 16mm Bolts (10), washers (11), Spring washers (12), and...

  • Page 4: Handle Assembly

    Step 4 - Handle Assembly Attach the handle (7) using a M6 x 65mm bolt (18), 6mm washer (11), 6mm Spring washer (12), and M6 nut (9) on the front support. Step 5 - Wheel Assembly Attach wheels on the front & rear support with pins (17), and wheel covers (20).

  • Page 5: Fence Assembly

    Step 6 - Fence Assembly Attach front (22), back (23), left and right (24) fences to the bed with 45mm bolts (19), 6mm nuts (9), 6mm washer (11), and 6mm Spring washers (12). Tighten all bolts and nuts securely. Assemble with the bolt head on the inner side of the wagon tub to prevent scratching...

  • Page 6: Parts List

    Parts List Description Description Wagon Bed Bolt M10 Rear Axle Support 10mm Washer Left Support Braces 10mm Lock Washer Right Support Braces 10mm Nut Front support-1 Pins Front support-2 Bolt for Handle M6x65mm Handle Bolts for Fence M6x45mm Washer Wheel Cover Nut M6x8pcs &...

  • Page 7: Limited Manufacturer Warranty

    Limited Manufacturer Warranty FOT makes every effort to ensure that this product meets high quality and durability standards. FOT warrants to the original retail consumer a 1-year limited warranty from the date the product was purchased at retail and each product is free from defects in materials.

This manual is also suitable for:

5348653487
