Summary of Contents for APT 600C-BLE
- Page 1 User Manual APT Model: 600C-BLE Supplier： APT(Tianjin) Development Co., Ltd. 1001, Building 5 HuaDing, No.1 HuaKe 3 Road, Binhai hi-tech Industrial Development Zone, Tianjin, China TEL: 86 22 26345859 FAX: 86 22 83719955 Email yzhao@aptdevelop.com...
-
Page 2: Table Of Contents
APT (Tianjin) Development Co., Ltd. Content Product model ............................2 Suppliers ..............................2 Specifications ............................2 Dimensions and Material ........................2 Features ..............................3 Main page ............................3 Functional Description .......................... 5 Power On/Off ..........................5 Assist levels ..........................5 Screen Switching ........................ -
Page 3: Product Model
APT (Tianjin) Development Co., Ltd. 1 Product model Model: 600C-BLE 2 Suppliers APT (Tianjin) Development Co., Ltd. 3 Specifications Ø 2.4inch TFT screen(IPS 240*320 pixel) Ø Battery supply:24V/36V/48V/52V Ø Multi-language support(6 languages) Ø Maximum output current to controller: 200mA, off-leakage current <1μA Ø... -
Page 4: Features
APT (Tianjin) Development Co., Ltd. 5 Features Ø 2.4inch TFT screen. Ø Ergonomic external button design, easy to operate, vibration function is provided during button operation. Ø 6 languages: Czech, German, French, English, Italian, Spanish are supported. Ø Speed indicator: Speed (Real-time), AVG Speed, MAX Speed. - Page 5 APT (Tianjin) Development Co., Ltd. Clock Power Battery voltage Speed indication Battery indication Power indication Speed value ODO/Trip/Time Head light Assist level Brake LOGO/Error Classics mode Distance to next junction Bluetooth Battery Remaining time of riding Speed value Warning of low...
-
Page 6: Functional Description
APT (Tianjin) Development Co., Ltd. indicator is 45; when the speed limit is more than 40km/h, the maximum indicator is 90; if the real-time speed exceeds the maximum indicated, its display is not affected. Ø Smart battery Power indicator: Provide a reliable battery Power indicator. -
Page 7: Screen Switching
APT (Tianjin) Development Co., Ltd. 7.3 Screen Switching Press POWER button to switch the screen, including Main Page, Bluetooth Page, Basic information Page and Information Page(The Main Page can be set，refer to 8.1.5 ‘Scenes’). Main Page –Modern/ Classics mode Bluetooth Page... -
Page 8: Bluetooth
7.6 Bluetooth Installing the “I-Bike” mobile app, turn on the Bluetooth of the mobile phone. Open “I-Bike” app, click “Scan for device”, find “600C-BLE” and connect, input the 6-digit pairing key and click "pair". After the Bluetooth pairing is successful, is displayed in blue, and the I-Bike APP will enter the main interface. - Page 9 *Please note: For some Android™ driven smartphones, there might occur eventual Bluetooth™ connection problems with the APT display due to software mismatches. Ø Settings Click the upper left corner of the "I-Bike" app to enter the Settings menu, including Display Settings, E-Bike Info and Battery Info.
-
Page 10: Data Cleanup
APT (Tianjin) Development Co., Ltd. 's navigation interface Main interface Phone 's navigation interface Display * The version information of the “I-Bike” APP is displayed in “More” on the main interface of the APP. 7.7 Data cleanup Press and hold UP & DOWN button together for 1 second can clean temporary data (TRIPB, TIME B, AVG SPD, MAX SPD data). -
Page 11: Display Settings
APT (Tianjin) Development Co., Ltd. * Display doesn’t quit parameter adjustment interface through pressing MENU button. 8.1 Display settings Display settings include several items：Language, System, Brightness, Auto off, Scenes, Clock, Focus. 8.1.1 Language 6 languages are supported: Czech, German, French, English, Italian, Spanish. Default is English. -
Page 12: Auto Off
APT (Tianjin) Development Co., Ltd. The light is turned on Display setting The light is turned off 8.1.4 Auto off This item enables to set the automatic shutdown time of the display, from 1 to 10min. Default value is 5 minutes, represents display shut down when there was no operation and riding for 5 minutes. -
Page 13: Clock
APT (Tianjin) Development Co., Ltd. 8.1.6 Clock This item can set date and time. You can choose Show-12 hour, Show-24 hour on Main Page. Show-12 hour Show-24 hour * Note: When display was powered off, internal Button Battery can keep clock running. When display is power on, Button Battery will be charged by external battery. -
Page 14: E-Bike Settings
APT (Tianjin) Development Co., Ltd. 8.2 E-bike Settings E-bike settings include several items：Start password, Assist levels, Wheelsize, Battery voltage, Battery Indexes, Pow Indexes, Pow range. 8.2.1 Start password The start password includes two parameter settings, Start password, OFF/ON. If you had set start password ON, you must input right password before power on. -
Page 15: Assist Levels
APT (Tianjin) Development Co., Ltd. The boot page after setting the start password * Display will automatically shut down if the correct password is not entered within 30S. Press and hold the POWER button to shut down while entering the password. -
Page 16: Battery Indexes
APT (Tianjin) Development Co., Ltd. 8.2.5 Battery Indexes This item can select battery Indexes setting, including OFF, Percent, Voltage. Voltage Percent Note: The voltage is the remaining voltage or percentage of the battery. 8.2.6 Pow Indexes Main Page can be set to display Power(W) , Current(A), Trip A, Range, Clock. -
Page 17: Advanced Setting
APT (Tianjin) Development Co., Ltd. 8.2.7 Pow range Support Output power range Settings: 250W/500W/750W/1000W/1250W/1500W/1750W/2000W. 8.3 Advanced setting Advanced settings have password to prevent illegal modification, default password is ‘1919’, password may be different according to request. Input correctly password to enter advanced setting page, where you can adjust the speed limit, range 10km/h~60km/h, 99 km/h(6.2Mile/h~37.2Mile/h, 61.4 Mile/h),... -
Page 18: Factory Setting
APT (Tianjin) Development Co., Ltd. Note：The maximum speed is limited by the motor and controller, and it is not necessarily possible to reach the speed limit setting value. 8.4 Factory Setting Select ‘YES’ will restore all setting to factory defaults. -
Page 19: Battery Infor
APT (Tianjin) Development Co., Ltd. 8.5.2 Battery Infor Battery Voltage Information can be showed. *The battery information is displayed when the E-bike is equipped with a battery with communication function. 9 Errors code Display shows error code and at the bottom of the screen when system checked abnormal. -
Page 20: Assembly Instructions
APT (Tianjin) Development Co., Ltd. Motor temperature sensor Check the sensor abnormal Controller temperature sensor Check the sensor failure Speed sensor fault Check the sensor BMS Communication Error Check the cable connection Headlight error Check the cable connection Headlight sensor error... -
Page 21: Copyright Notice
12 Copyright Notice Questions about your e-bike, please contact with dealer firstly. APT reserves the right to modify this specification file, without declaration in advance. Content and Image owner：APT (Tianjin) Development Co., Ltd. 1001, Building 5 HuaDing, No.1 HuaKe 3 Road, Binhai hi-tech Industrial Development Zone, Tianjin, China website：www.aptdevelop.com...
