- Page 1 Heel angle sensor Product reference : 90-60-343 USER GUIDE Version 1.0 Zi de Kerandré – Rue Gutemberg – 56700 – HENNEBONT – FRANCE www.nke-marine-electronics.com +33 297 365 685...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ................................3 LIST OF CHANNELS DISPLAYED ..........................4 SENSOR CALIBRATION ..............................4 OFFSET ..................................4 SETTING FILTERING OF THE CHANNELS ..........................5 NMEA 0183 OUTPUT ................................ 5 SENSOR DEMONSTRATION SOFTWARE ........................6 TECHNICAL SPECIFICATIONS ............................ 7 DIAGNOSTIC OF 1 LEVEL TROUBLESHOOTING .................... -
Page 3: Introduction
The nke Heel Angle sensor is a measuring instrument that provides the heel angle (rolling) of the boat. It can be connected to the nke TOPLINE bus of your installation, or, thanks to its NMEA 0183 output, to any NMEA receiver that processes XDR frames. -
Page 4: List Of Channels Displayed
LIST OF CHANNELS DISPLAYED The heel angle sensor, connected to the TOPLINE bus of your installation, creates the following channels: Channel Display Unit Heel (degrees) HEEL 2° Degrees R_Heel (degrees) (no display) Degrees The Heel channel is accessible from the displays of the TOPLINE range. The other channel (R_Heel) corresponds to the fast heel angle of the boat, i.e. -
Page 5: Filtering Of The Channels
5 times per second, the heel angle sensor transmits the heel angle to its NMEA output (yellow wire). The measurements of its sensors (accelerometer and rate gyro) are also sent to its NMEA output, using an nke proprietary frame. Note that is is possible to independently use the NMEA 0183 output and the Topline bus link. -
Page 6: Sensor Demonstration Software
SENSOR DEMONSTRATION SOFTWARE The demonstration software, downloadable from www.nke.fr, allows to check the good operation and to set the sensor’s parameters. The PC must be connected to the Topline bus via the interface TOPLINE PC reference 90-60-466. After selecting the type of connection (Topline or NMEA) and the associated port, click on the “Connect”... -
Page 7: Technical Specifications
TECHNICAL SPECIFICATIONS General : Power supply : 10 to 16VDC Power consumption : 25mA Tightness : IP54 Weight : 270 g (with 5 meters of cable) Operating temperature : -10°C to +50°C Storage temperature: -20°C to +60°C Measurement : Measurement range: -180° to +180° Resolution : 0.1 °... -
Page 8: Diagnostic Of 1 St Level Troubleshooting
DIAGNOSTIC OF 1 LEVEL TROUBLESHOOTING Before contacting technical support, please check the troubleshooting table below. Problem Possible causes and solutions The bus cable is not or is badly connected to the terminal box : check the The Topline installation does not detect the Heel Angle sensor. plugging and the connection inside the terminal box. -
Page 9: Sensor Installation
SENSOR INSTALLATION Fix the housing using Ø4 screws Figure 1 (dimensions in mm) CONNECTION TO THE TOPLINE BUS Connect the bus cable of the sensor inside the terminal box according to the drawing below: Yellow wire Green wire 12Vdc supply DATA black NOIR NMEA-... - Page 10 List of accessories TOPLINE Terminal box : 90-60-121 TOPLINE bus cable : 20-61-001 NOTES _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ - 10 - Heel_angle_sensor_um_EN_20_12...
- Page 11 NOTES _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ - 11 - Heel_angle_sensor_um_EN_20_12...
