Bake Max America BAFA Series Installation & Operation Manual

Countertop thermostatic gas griddle, countertop radiant gas charbroiler, countertop manual gas griddle, gas hot plate

Advertisement

Quick Links

R
Installation
and
Operation
Manual
COUNTERTOP THERMOSTATIC GAS GRIDDLE
COUNTERTOP RADIANT GAS CHARBROILER
COUNTERTOP MANUAL GAS GRIDDLE
GAS HOT PLATE
WARNING
Improper installation, adjustment, alteration, service or maintenance can
cause property damage, injury or death. Read the installation, operating and
maintenance instructions thoroughly before installing or servicing this
equipment.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS
OR LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the America BAFA Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Bake Max America BAFA Series

  • Page 1 Installation Operation Manual COUNTERTOP THERMOSTATIC GAS GRIDDLE COUNTERTOP RADIANT GAS CHARBROILER COUNTERTOP MANUAL GAS GRIDDLE GAS HOT PLATE WARNING Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
  • Page 2 SAFETY PRECAUTIONS Important safety instructions THIS MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. READ CAREFULLY AND SAVE FOR FUTURE CONSULTATION. Our service contacts are on the back cover of this manual, so always keep it handy for any need. This is the safety alert symbol. All safety messages will come after this symbol and the message "WARNING", "IMPORTANT"...
  • Page 3 Please observe all local and national codes and ordinances. • Installation must conform with local codes, or in the absence of local codes, the • National Fuel Gas Code, ANSI Z223.1 (latest edition). In Canada, installation should conform to installation codes for gas burning appliances and equipment standard CAN/CGA-B149.1 or the propane installation code, CAN/CGA-B149.2, as applicable.
  • Page 4 Important tips Carrefully keep this manual for future reference. Ÿ Failure to follow the instructions in the consumer manual for equipment installation Ÿ conditions will void your warranty. Never use the equipment if it is damaged or not working properly. Ÿ...
  • Page 5: Table Of Contents

    SUMMARY 01. INTRODUCTION 02. EQUIPMENT INSTALLATION 2.1 Equipment installation instructions 2.2 Recommendations before installation 2.3 Gas installation 2.4 Installation - Standards and gas codes 2.5 Gas pressure regulator 2.6 Gas conversion instruction 2.7 Gas leak check 2.8 Foot leveling 2.9 First time use 2.10 Turning on the equipment - product ignition 03.
  • Page 6: Introduction

    01. INTRODUCTION Gas Hot Plate It is another revolution that we offer you, being this a equipment that unites economy, technology and innovative design, thus becoming indispensable for your establishment. Please read this manual carefully to know your equipment and ensure its correct operation and maximum performance, thus increasing its useful life.
  • Page 7: Recommendations Before Installation

    CLEARANCES The appliance area must be kept free and clear of all combustibles. Combustible Non-combustible Model Rear Sides Rear Sides 0" Countertop Thermostatic Gas Griddle 8" 6" 0" 0" Countertop Manual Gas Griddle 8" 6" 0" 0" Countertop Radiant Gas Charbroiler 8"...
  • Page 8: Installation - Standards And Gas Codes

    2.4 Installation - gas standards and codes IMPORTANT FAILURE TO INSTALL THE PRESSURE REGULATOR WILL VOID YOUR WARRANTY. In North America, gas appliances equipped with casters must be installed with connectors that comply with the Standard for Connectors for Movable Gas Appliances, ANSI Z21.69.CSA 6.16 Latest Edition.
  • Page 9: Gas Conversion Instruction

    Air vent cap. Direction of the arrow at the bottom of the regulator. IMPORTANT Visually check all inlet pipes supplied by the installer and/or blow them out using compressed air to clean out any dirt or debris (threads or other foreign matter) before installing a service line.
  • Page 10 For conversion the following guidelines should be followed: COUNTERTOP THERMOSTATIC GAS GRIDDLE . Close the manual gas valve and disconnect the equipment from the main pipeline gas making sure that there is no leakage. Then remove the pressure regulator from the gas inlet on the equipment to make work easier.
  • Page 11 COUNTERTOP MANUAL GAS GRIDDLE For conversion the following guidelines should be followed: 1. Close the manual gas valve and disconnect the equipment from the gas main pipeline gas, making sure that there is no leakage. Then remove the pressure regulator from the gas inlet on the equipment to make work easier.
  • Page 12: Gas Leak Check

    5. Remove the injectors (5) with a 1/2" wrench. 6. In place of the removed gas injectors (3), place the new injectors that are included with the kit shipped with the equipment. But first apply some pipe sealant to the valve thread and then screw-in the new injectors to the correct gas type.
  • Page 13: First Time Use

    2.9 First-time use Against shock damage or rocking from transportation, the sides and waste tray have a protective PVC film. Remove any plastics, straps, or protective film from the equipment before operating the equipment. COUNTERTOP GRIDDLE THERMOSTATIC GAS AND COUNTERTOP GRIDDLE MANUAL GAS To protect the equipment against possible moisture damage between fabrication and installation on site, the fllat-tops are coated with a layer of vegetable shortening and...
  • Page 14 COUNTERTOP GRIDDLE MANUAL GAS 1. Open the manual gas supply valve (which will release gas into the equipment). 2. Put your lighting device (wick) past the ignition hole in the flame of the pilot on the equipment panel until contact with the pilot burner and until the flame ignites, repeat this procedure on all pilots (see following image).
  • Page 15 GAS HOT PLATE 1. Open the manual gas supply valve (which will release gas into the equipment). 2. Light the burner pilot until the flame ignites, repeat on all others. (see image below). Note: The ignition order does not interfere with the use of the equipment. 3.
  • Page 16: Cleaning And Maintenance

    03. CLEANING AND MAINTENANCE 3.1 Cleaning DANGER Do not use toxic or high chemical cleaning materials. See all instructions given by the cleaning equipment manufacturer. Ÿ After using the equipment and with the equipment not working or hot, clean it to remove food residue.
  • Page 17: Technical Specifications

    04. TECHNICAL SPECIFICATIONS 4.1 Equipment dimensions and weight COUNTERTOP THERMOSTATIC GAS GRIDDLE Exterior Product Dimensions & Weight Shipping Crate Dimensions & Weight Model Width (W) Depth (D) Height (H) Weight Width Depth Height Weight 15" 30 33/64" 16 27/32" 9 5/64" 112 lb 18 29/32"...
  • Page 18 COUNTERTOP RADIANT GAS CHARBROILER Exterior Product Dimensions & Weight Shipping Crate Dimensions & Weight Model Width Depth Height Weight Width Depth Height Weight 18" 30 33/64" 16 27/32" 9 5/64" 88 lb 20 7/8" 34 1/4" 19 19/64" 132 lb BACGG18-2 (457 mm) (775 mm)
  • Page 19: Technical Data

    4.2 Technical data GAS SUPPLY MANIFOLD PER BTU PER Kcal TUBE PRESSURE PRODUCT MODEL BURNERS GAS TYPE NOZZLE (in. W.C) BTU/h kcal/h NATURAL GAS 35,000 8,820 BACT15-1 L.P GAS 35,000 8,820 NATURAL GAS 70,000 17,640 BACT24-2 L.P GAS 70,000 17,640 Countertop NATURAL GAS 105,000...
  • Page 20: Main Components

    05. MAIN COMPONENTS COUNTERTOP MANUAL GAS GRIDDLE MAIN COMPONENTS OF COUNTERTOP MANUAL GAS GRIDDLE QUANTITY SIZE CODE DESCRIPTION BACG15-1 BACG24-2 BACG36-3 BACG48-4 BACG60-5 15" 8.01.53.00006700 24" 8.01.52.00072100 36" 8.01.52.00074300 GRIDDLE PLATE ASSEMBLY 48" 8.01.52.00074700 60" 8.01.53.00008900 15" - 24" - 36" - 48" - 60" 8.01.53.00009500 BURNER ASSEMBLY 15"...
  • Page 21 COUNTERTOP RADIANT GAS CHARBROILER MAIN COMPONENTS OF COUNTERTOP RADIANT GAS CHARBROILER QUANTITY SIZE CODE DESCRIPTION BACGG18-2 BACGG24-2 BACGG36-3 BACGG48-4 18" - 24" - 36" - 48" 8.01.25.00000105 TOP GRATE 18" - 24" - 36" - 48" 8.01.53.00000063 RADIANT 18" 8.01.53.00018500 8.01.52.00073000 EXTERNAL FRAME ASSEMBLY 36"...
  • Page 22 GAS HOT PLATE MAIN COMPONENTS OF GAS HOT PLATE QUANTITY SIZE CODE DESCRIPTION BAFA2M-12 BAFA4M-24 BAFA6M-36 1 12" - 24" - 36" 8.01.25.00000110 TOP GRATE 2 12" - 24" - 36" 8.01.53.00009400 SMALLER BURNER ASSEMBLY 3 12" - 24" - 36" 8.01.53.00009300 LARGER BURNER ASSEMBLY 12"...
  • Page 23 COUNTERTOP THERMOSTATIC GAS GRIDDLE MAIN COMPONENTS OF COUNTERTOP THERMOSTATIC GAS GRIDDLE QUANTITY SIZE CODE DESCRIPTION BACG15-1 BACG24-2 BACG36-3 BACG48-4 BACG60-5 15" - 24" - 36" - 48" - 60" 8.09.03.00000400 LEG ASSEMBLY 15" - 24" - 36" - 48" - 60" 8.01.53.00001900 KNOB ASSEMBLY 15"...
  • Page 24: Limited Original Commercial Equipment Warrant

    06. LIMITED ORIGINAL COMMERCIAL EQUIPMENT WARRANTY BAKEMAX offers a warranty to manufactured equipment as is specified below: Every alleged manufacturing defect must be analyzed only by technical assistance from BAKEMAX. When proven, an eventual manufacturing defect repair will be free of charge.Equipment repaired without proper authorization from the manufacturer or altered, disassembled, and/or utilized ajar from the indications presented in their respective guides, are not covered by this warranty.
  • Page 25 CONSUMER AND PRODUCT IDENTIFICATION Purchase Date: Model Number: Serial Number: Installed Date: Install By: Gas Type: Keep this manual, as it contains important information for questions, and adjustments. The same will be required for the warranty claim if required.
  • Page 26 Titan Ventures International Inc. 270 Baig Blvd, Suite A3 Moncton, NB E1E 1C8 Phone: (506) 858-8990 Email: sales@bakemax.com Web site: www.bakemax.com Rev. 03 052022...
