Kerb Stone Clamp S100
Overview - does not replace the operation manual
A
Jaw Combination
A
A
= 1 x Rubber Jaw 12 cm long, outmost position
B
= 2 x Rubber Jaws 6 cm short, innermost position
C
= 1 x Gap Jaw 7 oder 9 cm wide, outmost position
B
Stop Brackets define Clamping Position of
Gap Jaw
F
F
= Setting of Stop Bracket
C
B
100 cm
F
G
G
= Stop Bracket -> clamping position
Joice of Gap Jaws
D
= Border Stone 8/10 cm: Gap Jaw 7 cm
E
= Kerb Stone 12/15 cm: Gap Jaw 9 cm
= Line
Rubber Jaw 12 cm
G
D
10 cm
F
G
= Line
E
F
G
Advertisement
Summary of Contents for Hunklinger allortech S100
- Page 1 Kerb Stone Clamp S100 Overview - does not replace the operation manual Jaw Combination Joice of Gap Jaws 10 cm 100 cm = 1 x Rubber Jaw 12 cm long, outmost position = Border Stone 8/10 cm: Gap Jaw 7 cm...
- Page 2 Height Compensation -> Hanger Flange on chain = bolted out (BA S. 30) Factory default: Without height compensation Recommended: With height compensation = Bolt, = Hanger Flange Carrier machine doesn‘t put pressure on the Kerb Stone Clamp or bedding. Hanger flange is directly connected with Only the stone‘s weight puts pressure on the Keb Stone Clamp.
