Summary of Contents for Rapsodo GOLF SIM STUDIO ENCLOSURE 13
- Page 1 Golf Simulator Studio Bu Golf Simulator Studio Bundle 13 Deep Enclosure 4m x 3m x 3m / 13’ (W) x 10 Assembly instru...
- Page 2 Packaging Packagi g Your Golf Simulator Enclosure will come in 2 separate cartons. 1 x long carton - metal frame & 1 x rectangular carton - enclosure material with screen...
- Page 3 Packaging Long carton contents Male 27 x 3.3ft (1m) pole Female Male 11 x 3.3ft (1m) pole Male Male 1 x 2ft (0.6m) pole Female Male 1 x 3.3ft (1m) pole Hole Male HDMI cable Hole...
- Page 4 Packaging Long arton ontents 2 x 105˚ 3-way connector 2 x 105˚ 3-way connector 2 x 2-way feet connector 2 x 3-way feet connector 2 x crossover clamp 1 x Mounting Bracket...
- Page 5 Pa c k a g n g Rectangular carton contents 1 x Enclosure material with Screen. 1 x Replacement Hitting Screen (attached on inside It is a single piece construction containing the of Enclosure Material with Velcro) projector screen, side and ceiling panels 9 x Clip 2 x Clip with Velcro...
- Page 6 F r a m e A s s e m b ly I d e n t i f i c at i o n Pa rt s Pole...
- Page 7 F r a m e A s s e m b ly I d e n t i f i c at i o n Pa rt s Connector The arrows on the angled 3-way connectors should point toward each other. For example, the label on front left 3-way (1) should face you and the arrow points to the right;...
- Page 8 Assembly – STEP 1 Step Assemble the upper frame by connecting the poles as shown on Figure 1 57.52° Figure 1...
- Page 9 Assembly – STEP 2 Step Attach projector mounts to the upper frame 57.52°...
- Page 10 Assembly – STEP 3.1 Step 3. Place the material in the centre of your enclosure area and spread the black material out so that you can identify the bottom of the screen. The front of your hitting screen (wear you hit the ball into) is the smooth side.
- Page 11 A s s e m b ly – S T E P 3 . 2 Step 3 2 Secure all 4 top edges of the enclosure material to the upper frame using the Velcro attachments as shown on Figure 2 Start at the rear, before moving on to each side.
- Page 12 A s s e m b ly – S T E P 3 . 3 Step 3 3 Secure material to the projector pole using the Velcro attachments as shown on Figure 2 Figure 2...
- Page 13 A s s e m b ly – S T E P 3 . 4 Step 3 4 Secure material to the upper left frame using the Velcro attachments as shown on Figure 2 Figure 2...
- Page 14 Assembly – STEP 3.5 Step 3. Secure material to the upper right frame using the Velcro attachments as shown on Figure 2 Figure 2...
- Page 15 A s s e m b ly – S T E P 3 . 6 Step 3 6 Secure material to the upper front frame using the Velcro attachments as shown on Figure 2 Figure 2...
- Page 16 Assembly – STEP 3.7 Step 3. Three clips and velcro need to be attached on the top of the enclosure. Velco straps are already sewn on the enclosure. Attach clip to Velcro. Hook it over the back bar. Pull firmly and reattach strip to the Velco.
- Page 17 Assembly – STEP 4 Ste 4 Once the top is secured, attach the enclosure to each of the vertical upright legs as shown on Figure 1 Figure 1...
- Page 18 Assembly – STEP 5 Step Assemble the lower frame as shown on Figure 4 Figure 4...
- Page 19 Assembly – STEP 6 Step Wrap and secure the remaining perimeter edges to the frame using the Velcro attachments as shown on Figure 2 Figure 2...
- Page 20 Assembly – STEP 6 Step Tighten screen with clips and velcro on the back side of the enclosure. Attach clip to Velcro. Hook it over the back bar. Pull firmly and reattach strip to the Velco.
- Page 21 Assembly – STEP 6 Step Tighten screen with clips and velcro on the front bottom side of the enclosure. Slide the hook underneath the bottom side bar. Slip the velcro through the clip and make a loop out of it. Pull the loop tight and put the bottom of the screen on it.
- Page 22 P r o j e c t o r i n s ta l l at i o n Projector insta ation What’s in the box?
- Page 23 Projector installation Setting up the brac et The bracket needs to be reassembled as it's shown on the picture below. Follow the instructions on the next slides.
- Page 24 Projector installation Setting up the brac et Step 1 One of the arms is redundant and needs to be removed. Unscrew this screw at the top using cross-head screwdriver. Remove the arm.
- Page 25 Projector inst ll tion Setting up the bracket Step 2 Loosen this particular arm wingnut and remove it. Slide out the long attachment. Turn the long attachment around and slide it back in. Tighten the arm wingnut in about this position.
- Page 26 Projector inst ll tion Setting up the bracket Step 3 Loosen this particular arm wingnut and remove it. Slide out the long attachment. Take a short attachment and slide it in instead of long one. Tighten the arm wingnut in about this position.
- Page 27 Projector inst ll tion Setting up the bracket Step 4 Loosen this particular arm wingnut and remove it. Slide out the long attachment. Take a short attachment and slide it in instead of a long one. Tighten the arm wingnut in about this position.
- Page 28 Projector inst ll tion Setting up the bracket Step 5 Loosen this screw at the top using cross-head screwdriver. Rotate the arm to about this position and tighten the screw at the top.
- Page 29 Projector inst ll tion Positioning the bracket on the bottom of the projector Turn projector upside down with the lens facing towards you and find three mounting holes. Ensure that when you position your recently formed bracket, the holes on it match up exactly to the holes on the bottom of your projector.
- Page 30 Projector inst ll tion Attaching the gimbal to the F Pole The gimbal mount is welded on the F Pole. Line up the holes of the gimbal with the holes on the gimbal mount on the F Pole and simply screw four screws in.
- Page 31 Projector inst ll tion Attaching projector to the gimbal Hang the projector on the gimbal Screw one screw in as it shown on a picture and the other one on the opposite side of the gimble.
- Page 32 Projector inst ll tion Connecting the projector to the power Plug in the power cord to the projector.
- Page 33 Projector inst ll tion Connecting HDMI cord to the projector Plug the HDMI cable into either of the two HDMI ports...
