Designed for use in small office, home office, and residential environments.
WARNING –
equipment furniture. A remote control or toys placed on the furnishing may encourage a child to
climb on the furnishing and as a result the furnishing may tip over on to the child.
For Warranty information go to
For convenience, write serial Number located on underside of the desk below:
Lillipad Work Solutions INC
N19 W24400 Riverwood Drive, Suite 350
Waukesha, WI 53188
www.lillipad.com/pages/faqs
Patent Pending
Made in USA with U.S. and imported parts
V. 3.23.1
Instruction Manual
Models Lillipad 42 and Lillipad 48
Power Distribution Unit
125 Vac 50-60Hz 12A DC 5V 2.1A
Height Adjustable System
Input: 100-240V~,50/60Hz,4A
Output: Max.32V
Duty Cycle: 10%, Max. 1 min. ON./ 9 min. OFF
Max Load: 75 pounds
Caution: Indoor Use Only
Manufactured by Lillipad Work Solutions INC
Risk of death or serious injury may occur when children climb on video/computer
For Support contact: Support@Lillipad.com
___________________________________
__
---
,Max. 10A
www.lillipad.com/pages/warranty
Conforms to UL STD 962
Certified to CSA STD C22.2#68
Advertisement
Table of Contents
Related Manuals for Lillipad 42
Summary of Contents for Lillipad 42
- Page 1 Instruction Manual Models Lillipad 42 and Lillipad 48 Power Distribution Unit 125 Vac 50-60Hz 12A DC 5V 2.1A Height Adjustable System Input: 100-240V~,50/60Hz,4A Output: Max.32V ,Max. 10A Duty Cycle: 10%, Max. 1 min. ON./ 9 min. OFF Max Load: 75 pounds...
-
Page 2: Important Safety Instructions
Remove all plugs from power unit when operating below 27” height. Always unplug Lillipad before moving. Always unplug Lillipad before cleaning or servicing Do not expose any electrical components to water or other liquids. Surge Protected outlets are for computers and accessories only. Not for use with household appliances, irons, coffee makers, hair care products, etc.. -
Page 3: Grounding Instructions
IMPORTANT SAFETY INSTRUCTIONS Working height is 26.5” to 42” for Lillipad 42 and 27” to 48” for Lillipad 48 Do not put load on desktop when operating below working height. Maximum Load in working height range is 75lbs Use only Lillipad approved accessories. Go to www.lillipad.com/collections/accessories... - Page 4 Transporting your Lillipad 1. Your Lillipad lowers to 6” in height to be moved to convenient locations for working or storage. 2. Only move Lillipad when unplugged and in stored position 3. store power cord in compartment under desktop before moving your Lillipad 4.
-
Page 5: Getting Started
27” User Tip: “A little help”. If your Lillipad is out of the box for the first time or has been stored for an extended period, it may need help raising from the 6” height. A gentle lift... -
Page 6: Safety Feature
Safety Feature Lillipad has an integrated safety stop as a reminder to take precautions prior to lowering from working heights to storage height. A specific code must be entered to lower the desktop below 27”. Do not share this code with children or anyone who should not operate this unit. - Page 7 Lillipad X42 and Lillipad X48 • Working height range for Lillipad XL is 27” to 48” • Working height range for Lillipad X is 26.5” to 42” Do not put load on desktop between 6” to 27” • Touchpad Guide...
- Page 8 5. Setting the Memorized Position Lillipad supports a maximum of 2 memory positions. • Presets cannot be set below 27” How to program preset position: Adjust the desk to the desired height.
-
Page 9: Collision Detection
Collision Detection Always make sure the desk and wheels are clear of all obstructions before raising or lowering the desktop. As an added precaution, your Lillipad is programmed to stop movement and reverse direction in the event of encountering uneven surfaces or obstructions. -
Page 10: Faqs And Troubleshooting
Sometimes Lillipad has a slow start to the day, especially before coffee. If your Lillipad is just out of the box, or has been stored for an extended period, it may need a little boost! Position your left hand to the center of the desktop, while pressing the Up Arrow with your right hand, provide a slight upward lift with your left hand and it should rise and function normally (see page 4.)
