- Page 1 PROFESSIONAL SHOW LIGHTING SR-230PLUS BEAM MOVING-HEAD USER MANUAL GUANGZHOU LIGHTSTAR LIGHT CO.,LTD Http://www.lightskystar.com...
-
Page 2: Technical Parameter
1.INDEX 6.TECHNICAL PARAMETER Many thanks for choosing SR-230 beam moving head. BULB: 7 R230W (8000 K color temperature, 2000 hours) Thedesign&production are passed through the full quality POWER CONSUMPTION: 230 V 50 HZ 380 VA control to ensure the fineness ability. OPTICAL DEVICE: three lens group,0°-3°zoom This manual covers important information about install-... -
Page 3: Dmx Profile
3. DMX profile 5. Trouble Shooting Ø DMX profile CHANNEL VALUE FUNCTION ADJ CH1 0-255 PROBLEM REASON AND ACTION ADJ CH2 0-255 Tilt Ø Check the power connection is correct or not. ADJ CH3 0-255 Pan fine Ø The fuse is damage. ADJ CH4 0-255 Tilt fine... -
Page 4: Reset Control
111-115 Color 11 116-120 Color 11->Color 12 Y RASTER 121-125 Color 12 X HALL 126-130 Color 12->Color 13 Y HALL 131-135 Color 13 FOCUS HALL 136-140 Color 13->Color 14 RESET YES/NO 141-145 Color 14 SEND PARAMETERS YES/NO 146-150 Color 14->Open CHANNEL SETTING PASSWORD 1-20 151-200... - Page 5 182-188 Gobo14 shake(slow to fast) DMX ADDRESS 001-512 189-195 Gobo15 shake(slow to fast) DO NOTHING AND EXIT/OPEN LAMP LAMP CONTROL 196-202 Gobo16 shake(slow to fast) LAMP/CLOSE LAMP 203-209 Gobo17 shake(slow to fast) POWER ON LAMP ON ON/OFF 210-230 CW flow(slow to fast) AFTER RESET LAMP ON/OFF 231-234...
