World Dryer DryBaby ABC-300H Manual

DryBaby Changing Stations
Durable Baby Changing Stations
World DryBaby baby changing stations offer exceptional features that enhance
convenience and safety. DryBaby are meticulously designed, engineered and
manufactured to meet the toughest standards in the industry.
General Product Features & Benefits
• Easy-to-clean and high-density polyethylene interior
• Easy-to-clean smooth nylon safety belt
• Safety belt adjustable with one hand
• No measurable bacterial and fungal growth
• Built-in liner dispenser
• Bag hooks on both sides for added convenience
• Resistance to Fungi ASTM G21 Pass Rating
• Resistance to Bacteria ASTM G22 Pass Rating
• ANSI compliant safety labels
• ADA compliant
ABC-300H DryBaby Horizontal Polyethylene Station
• The industry standard as the most preferred changing position
• Meets ASTM F2285 for weight bearing commercial changing stations
• CPSIA compliant to applicable sections
• Required mounting surface 16" high by 34.25" wide
• Changing surface extends 17.5" from wall in open position
ABC-300V DryBaby Vertical Polyethylene Station
• Suitable for narrow footprint space
• Meets ASTM F2285 for weight bearing commercial changing stations
• CPSIA compliant to applicable sections
• Required mounting surface 34" high by 19" wide
• Changing surface extends 34" from wall in open position
ABC-300HS DryBaby Surface Mounted Horizontal Stainless Steel Station
ABC-300HSR DryBaby Recessed Mounted Horizontal Stainless Steel Station
• Polyethylene interior with brushed stainless steel exterior
• Available in both surface mount and recessed versions.
• Meets ASTM F2285 for weight bearing commercial changing stations
• CPSIA compliant to applicable sections
• Rough-in dimension for recessed model is 35.625" W x 19.75" H
• ADA and ANSI compliant when properly installed
ABC-300BQS DryBaby Baby Quick Seat
• Provides safe, clean and secure location for child while adult is changing
another child or using facilities.
• Supports up to 80 lb or 36.3 kg
• Required mounting surface 12" W x 15.25" H
• Seat extends 13.5" from wall when open
Model # Type Mounted
ABC-300H Horizontal Surface
ABC-300V Vertical Surface
ABC-300HS Horizontal Surface
ABC-300HSR Horizontal Recessed
ABC-300BQS Wall Seat Surface
ABC-300L Sanitary Bed Liners (500 qty)
Material, Color, Note, ... Unit Wt.
Polyethylene 15 lbs
6.8 kgs
Polyethylene 17 lbs
7.7 kgs
Stainless Steel, Brushed 55 lbs
24.9 kgs
Stainless Steel, Brushed 50 lbs
22.6 kgs
Polyethylene 8 lbs
3.63 kgs
Shipping Wt. Unit Size (HxWxD) inch/
17 lbs 18" x 34.5" x 4"
7.7 kgs 457 x 876 x 100
19 lbs 34" x 19" x 5.5"
8.6 kgs 864 x 483 x 140
66 lbs 21.5" x 37.5" x 4"
29.9 kgs 546 x 953 x 100
61 lbs 18" x 34.5" x 0.13"
27.6 kgs 457 x 876 x 3
4.7 lbs 15.5" x 11.8" x 3.8"
2.1 kgs 394 x 300 x 97
ABC-300H
ABC-300V
ABC-300HS
ABC-300HSR
ABC-300BQS
Shipping Size (HxWxD) inch/
mm mm
35.5" x 18" x 4.3"
900 x 460 x 110
33" x 20" x 4.3"
840 x 510 x 110
43.3" x 27" x 5.8"
1100 x 685 x 145
41.3" x 24.5" x 5.8"
1045 x 625 x 145
16.25" x 12.25" x 4.25"
412 x 311 x 108
