EE Systems Group eLEDing/TesLit EE828WTL-AI Quick Start Manual

Thank you for choosing eLEDing! World's First AI SMART Lighting:
This innovative AI SMART light is unlike all solar light on the current market without any manually functional setting up, it's able to Auto-
Optimization via AI firmware self-calibration in four seasons and its geographical location. US and international patents granted and pending
worldwide. All rights reserved. Users must read this manual before installation, comply with local standard and regulations of construction &
electrical/electronic projects, follow the safety guidelines to prevent any possible accidents, incidents and/or injuries. Consult experienced
contractor/installer and electrical technicians for assistance.
One Step Setup (Just plug into the plug!)
Plug –In the
solar plug to
Activate
the Automatically
system
Calibrate
AI SMART lighting profile
Full brightness
The fixed Hours high
brightness period is able
to automatically
adjusted depends on
the multiple factors to
Dimming brightness
ensure all-night
until dawn
illumination
Second stage Intelligence Power Management (IPM) system : monitor & adjust power consumption
Switch to
If low power
Motion
(20% left) AUTO Mode
No
Light OFF
Setup
Mount solar panel must
directly facing to Sun always
Installation Guidelines (video link: https://youtu.be/oaRHKocifVA)
1. Securely mount or even one screw hanger-on the unit on the wall or other surface, etc., Then One Step: Plug the solar panel into plug of light
body to lit-up the light, by adjust the light head direction and sensor angles based on your need.
2. Built with upgraded and full adjustable BIFACIAL solar panel, it is a must to place it in a completely unobstructed location where there is
direct sunlight for at least 5-6 hours on average every day throughout the year. For most of the North America projects, adjust the tilt of the
solar panel at 25°- 60° degrees based on your actual location. The solar panel can be pointed to between east and west, but south is the best
facing direction and definitely NOT to North. For northern hemisphere installations, a south-facing position is best and visa-versa for southern
hemisphere installation.
Optional AUX 12-15VDC/<1.0A power sources can be used as back-up power or fast charging source to give the light a quick charge before
installation or for indoor emergency lighting.
3. Solar Panel Maintenance: Use soft, wet cloth to clean the solar panel periodically (at least once a one year) to avoid energy output reduction
resulted from accumulated dust. Clean accumulated snow ASAP during snowing season.
4. Built in Li-ion battery is replaceable
5-min walk
Light ON
test mode
5 min
If
Yes
Light ON
Motion
No
Light OFF
Up to 3 hours
Motion
detected
Yes
ON with full
brightness
Back to
Mount/hanger-on it with screws, Light heads & Sensor adjustability
Polycarbonate/PC with Beige color
12346 Valley Blvd, El Monte, CA 91732 Phone Number: 1-877-579-3889 Fax: 626-452-9194 Web: www.eleding.com/www.eesgi.com
AI SMART Solar Light ... Built with Dual Ultra-Bright LED Head
Yes
Light
Daytime?
OFF
No
When
night
Light turns ON
comes
In real critical weather
AI Mode
come to
Max
Motion
brightness
detected
NO
Critical Reserve
Full Charge
(10% left)
Yes
AI Mode
eLEDing/TesLit EE828WTL-AI
10-3/4"
5-1/2"
Auto convert to
Dimming mode
In most case, occur
on continuous
cloudy/snowing
days during the
Dusk to Dawn with
winter season
dimming brightness
Yes
ON with half
Motion
brightness
No
After Fully
Light OFF
Charged
Plug-in the solar panel plug under Sensor
head will turn On the light for automatically
normal operation
Rev: 05212023
