OXYSET
MOBILE BRAZING SYSTEM
OPERATOR'S MANUAL
BROMIC Plumbing & Gas
10 Phiney Place, Ingleburn NSW 2565 Sydney Australia
Telephone: 1300 276 642 (AU) 0508 276 642 (NZ)
Email: plumbing@bromic.com Web: bromicplumbing.com
A member of the Bromic Group
V11 - 01/2023
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Bromic Heating OXYSET 1811167-2
- Page 1 PLUMBING & GAS Product Number: 1811167-2 OXYSET MOBILE BRAZING SYSTEM OPERATOR’S MANUAL BROMIC Plumbing & Gas 10 Phiney Place, Ingleburn NSW 2565 Sydney Australia Telephone: 1300 276 642 (AU) 0508 276 642 (NZ) Email: plumbing@bromic.com Web: bromicplumbing.com A member of the Bromic Group V11 - 01/2023...
- Page 2 Part No. 1811167-2 Oxyset Operator’s Manual ATTENTION - THIS PRODUCT IS FOR INDUSTRIAL USE The following instructions must be read carefully and adhere to before using the OXYSET 1811167-2 (which will henceforth be referred to as ‘kit’) and keep the manual for future reference.
- Page 3 Part No. 1811167-2 Oxyset Operator’s Manual CONTENTS 1. General Warnings 2. Safety Information 3. List of Components 4. Technical Specifications 5. How to gas weld 6. Operating instructions 10-11 7. Maintenance Sydney Office: 10 Phiney Place, Ingleburn NSW 2565 Australia Telephone: AU 1300 276 642 NZ 0508 276 642 Email: plumbing@bromic.com Web: bromicplumbing.com...
- Page 4 Part No. 1811167-2 Oxyset Operator’s Manual Hazard Prevention • Always guard against flammable substances, burns, fluxes, filler metals, gases, and fumes. • Never use oxygen or fuel gas to blow off work, equipment, or clothing. Pure oxygen encourages combustion, and gas is flammable. •...
- Page 5 Part No. 1811167-2 Oxyset Operator’s Manual Ventilation • Adequate ventilation must be provided for all welding, cutting, brazing, and related operations. • Adequate ventilation must be enough such that any hazardous concentrations of airborne contaminants exposed to personnel are maintained below the allowable limits specified by the authority having jurisdiction.
- Page 6 Part No. 1811167-2 Oxyset Operator’s Manual Supervision This section pertains the commercial use of the product. Management refers to people responsible for welding operations, while supervisors refer to people responsible for the supervision of welding. Responsibilities Operators and management are both responsible for safety in welding and cutting. Training Welders and their supervisors must be trained in the safe operation of their equipment and emergency procedures.
- Page 7 • 1 x Goggles Introduction The OXYSET 1811167-2 is fuelled by disposable oxygen cylinder (T-PED approval number 0036) and a disposable MAP//Pro cylinder (complying with DOT39). We recommend using Bromic oxygen cylinders (P/N 1811320) and BernzOmatic MAP//Pro cylinders (P/N 1811120).
- Page 8 8. Tighten all fittings and conduct leak test. WARNINGS: • The OXYSET 1811167-2 is for use with disposable oxygen and MAP//Pro cylinders only. These cylinders are not refillable. Use of other cylinders may be dangerous. Do not connect cylinders before reading all relevant instructions.
- Page 9 Part No. 1811167-2 Oxyset Operator’s Manual How to gas weld WARNINGS: a) We recommend to preset regulators’ output pressure to minimum 0.5 bar for gas pressure regulator; and 4 bar for oxygen pressure regulator. b) The maximum working pressure should NEVER exceed 0.9 bar for gas pressure regulator;...
- Page 10 Part No. 1811167-2 Oxyset Operator’s Manual Gas Flow Valve Oxygen Flow Valve Light the torch Ignite using a spark lighter (11), paying attention to keep the flame stuck to the soldering nozzle until you achieve a flame as shown. If the flame comes away from the nozzle and blows out, close the gas knob slightly to slow supply.
- Page 11 • Avoid torsions and overheating of the hoses (10a and 10b). • During use, parts of the OXYSET 1811167-2 can reach high temperatures and must be allowed to cool completely prior to storage • It is dangerous to use damaged or malfunctioning equipment •...
- Page 12 Part No. 1811167-2 Oxyset Operator’s Manual Storage If the OXYSET is not in use, disconnect all components from each other and allow all the system to drain. This will avoid cylinder discharge as a result of imperceptible leaks. Place the OXYSET in its original packaging or another protective case and store in a cool, dry and well-ventilated place.
- Page 13 BROMIC Pty Ltd. 10 Phiney Place, Ingleburn NSW 2565 Australia AU: 1300 276 642 NZ: 0508 276 642 BROMICPLUMBING.COM V11 - 01/2023...
