User Manual

UH8K-2VE

8K 1x2 HDMI 2.1 Splitter with Down-scaling,

Audio De-embedding and CEC Pass-Through

Version: UH8K-2VE_2023V1.3

www.ute.de

Table of Contents

Need help?

Do you have a question about the UH8K-2VE and is the answer not in the manual?

Questions and answers

Summary of Contents for UTE UH8K-2VE

Page 2 UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling U.T.E. electronic GmbH & Co. KG www.ute.de...
Page 3 UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling Statement Thanks for purchasing this product, please read this user manual carefully before using this product. Pictures are shown in this manual for reference only. Different models and specifications are subject to real product.
Page 4 UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling U.T.E. electronic GmbH & Co. KG www.ute.de...
Page 5 UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling Safety Precaution To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Do not dismantle the housing or modify the module to avoid electrical shock or ⚫...
Page 6: Table Of Contents
UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling Contents 1 Introduction ....................... 1 1.1 Product Introduction..................1 1.2 Features ......................1 1.3 Packing List ...................... 1 2 Panel Description ...................... 2 2.1 Front Panel ....................... 2 2.2 Rear Panel ......................3 3 System Connection ....................
Page 7: Introduction
1 Introduction 1.1 Product Introduction Thanks for choosing the 1x2 8K HDMI 2.1 Splitter UH8K-2VE, which can distribute one HDMI input to two outputs. The splitter supports HDMI video resolution up to 8K@60Hz 4:4:4 / 4K@120Hz 4:4:4, HDR and DTS/Dolby audio formats.
Page 8: Panel Description
UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling 2 Panel Description 2.1 Front Panel Figure 2-1 UH8K-2VE Front Panel ① POWER LED: The LED illuminates green when power is applied. ② INPUT & OUTPUT LEDs: • Input LED: The LED illuminates blue when the HDMI input signal is connected and HDCP is connected, flashing when the HDMI input signal without HDCP, light off when there is no input signal.
Page 9: Rear Panel
UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling 2.2 Rear Panel Figure 2-2 UH8K-2VE Rear Panel ① INPUT: Type-A female HDMI input port to connect a HDMI source. ② OUTPUTS (OUT1 & OUT2): Two type-A female HDMI output ports to connect HDMI displays.
Page 10: System Connection
UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling 3 System Connection 3.1 Usage Precautions 1) Make sure all components and accessories included before installation. 2) System should be installed in a clean environment and has a prop temperature and humidity.
Page 11: Dip Switch Operation
(ON) position. Switch 1~3 are used for EDID setting. The DIP switch status and its corresponding setting are shown at the back of the product. Figure 4-1 EDID cart at the back of UH8K-2VE U.T.E. electronic GmbH & Co. KG www.ute.de...
Page 12: Dip Switch Settings (Edid)
UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling 4.1.1 DIP switch settings (EDID) Switch 1~3 are used for EDID setting. The switch represents “0” when in the lower (OFF) position, and it represents “1” while putting the switch in the upper (ON) position.
Page 13: Hdcp Mode/ Management
UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling 4.2 HDCP Mode/ Management Put switch 4 on “ON” position to select HDCP Active mode, or to “OFF” for HDCP Passive mode. Switch Status Mode HDCP Passive OFF (0) Automatically follows the input’s HDCP version.
Page 14: Firmware Upgrade
UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling 6 Firmware Upgrade Please follow the below steps to upgrade firmware by the USB-C port: Step1. Connect the FW port on the front panel of the machine to the computer with a USB Type-A to Type-C cable, and power on the machine;...
Page 15: Technical Specification
UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling 7 Technical Specification Video Input Input (1) HDMI Input Connector (1) Type-A female HDMI HDMI Input Resolution Up to 8K@60Hz 4:4:4 8bit HDMI Standard HDCP Version 2.3, 2.2, 1.4 compliant Supported Supported...
Page 16 UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling General Bandwidth 48Gbps 8K@60Hz 4:4:4 ≤ 3m, HDMI V2.1 Cable Length 4K@60Hz 4:4:4 ≤ 5m, 4K@60Hz 4:2:0 ≤ 10m, 1080p ≤ 15m Operation Temperature -5 to +55℃ (+23° to +131°F) Storage Temperature -25 to +70℃...
Page 17: Panel Drawing
UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling 8 Panel Drawing Figure 8-1 UH8K-2VE Panel Drawing U.T.E. electronic GmbH & Co. KG www.ute.de...
Page 18: After-Sales / Customer Service
UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling 9 After-sales / Customer Service Any transport costs are borne by the users during the warranty. The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter.
Page 19 UH8K-2VE: 8K60 1x2 HDMI 2.1 Splitter with Down-scaling 5) Technical Support: Email to our after-sales department or make a call, please inform us the following information about your cases. ⚫ Product version and name. ⚫ Detailed failure situations. ⚫ The formation of the cases.
Page 20 U.T.E. electronic GmbH & Co. KG Tel: +49-2302-28283-0 Fax: +49-2302-28283-10 Email: info@ute.de Website: www.ute.de U.T.E. electronic GmbH & Co. KG www.ute.de...
