Introduction
The Heatmiser WR1 is a repeater designed to extend the communication distance of the
Wireless/WiFi RF 868MHz thermostats/time clocks.
•
Compatible with 868MHz thermostat & receiver models.
•
The WR1 repeater requires 240v Live & Neutral supply.
•
The WR1 does not need to be paired to any receivers or thermostats, the WR1 only
requires a 230v power supply.
•
The repeater will detect the signal that is being sent from the thermostat, and
boost this onto the receiver.
Model: WR1
Model: WR1
Advertisement
Summary of Contents for Heatmiser WR1
- Page 1 • The WR1 repeater requires 240v Live & Neutral supply. • The WR1 does not need to be paired to any receivers or thermostats, the WR1 only requires a 230v power supply. • The repeater will detect the signal that is being sent from the thermostat, and...
- Page 2 LED Status Wiring Diagram - WR1 There are 4 LED lights on the repeater. Power LED - Permanently on when the WR1 is powered. Mains Supply In TX LED - Flashes when signal received. RX LED - Flashes when boosting signal to the receiver.
