Summary of Contents for KYY K3-1
- Page 1 User Guide K3-1 15.6 " Full HD Portable Monitor Note: Any technical problem pls contact support team [support@kyytech.com]...
- Page 2 Service Not Satisfied? Monitor Damaged? Can’t Connect? We apologize for any inconveniences, if the monitor you received damaged or can’t connect the monitor successfully with your devices, Please Contact: support@kyytech.com provides 12-MONTH WARRANTY plus online responsive customer service...
-
Page 3: Table Of Contents
Content Package List ...............1 Introduction ..............2 Smart Cover ..............4 Connect with Devices ........... 6 Mode Settings ............... 11 Supported Devices and Models ......17 Speci cations ..............19 Notices ................20 Troubleshooting ............21... -
Page 4: Package List
Package List 15.6 " Portable Monitor Magnetic Smart Cover USB-C to Mini HDMI to USB-C to USB-A 5V/2.4 A Power USB-C Cable HDMI Cable Cable (Power Supply) Adapter... -
Page 5: Introduction
Introduction Dual Speakers Listen to music, movies, games, and multimedia les. Power Button/Back Button Long press for 3s to turn the screen on/o . Short press to back to the previous page. Trackwheel • Press the trackwheel to turn to the OSD menu. Scroll the trackwheel to control the cursor on the menu, and press to con rm;... - Page 6 Introduction Type-C Full Function Port • Supply power(5~20V voltage input); • Transmit the audio, video signal. Type-C Full Function Port • Supply power(5~20V voltage input); • Transmit the audio, video signal. Mini HDMI Port Audio and video signal transmission.
-
Page 7: Smart Cover
Smart Cover Place the screen on the backside of the smart cover. Cover the screen side of the smart cover on the screen for protection. - Page 8 Smart Cover Use the smart cover to make the monitor stands at a proper viewing angle. Fold the screen side of the smart cover back to support the screen's bottom.
-
Page 9: Connect With Devices
Connect with Devices Connect with External Power Supply Connect your monitor to the power supply with the [usb-c to usb-a cable] and the Adapter provided, plug in the [usb-c to usb-c cable] OR [mini HDMI to HDMI cable] for video output. Connect without External Power Supply Only works with full-function USB-C port. - Page 10 Connect with Devices USB-C Laptop USB-C to USB-C External Power Supply Needed Conditions 1. Brightness or volume is greater than 80%. 2. The type-c cable does not have a power supply function. Note: Please check if the USB-C port of your laptop is compatible with audio and video signal transmission.
- Page 11 Connect with Devices USB-C Phone USB-C to USB-C If there is no external power supply, the phone would supply power to the monitor. Then the monitor would turn to energy-saving mode (30% brightness). If plugin a 5V/2.4A (or above) external power, the monitor can reversely charge the phone.
- Page 12 Connect with Devices HDMI PC/Laptop USB-A to USB-C Computer HD to Mini HD （external power supply) USB-C to USB-A Computer HD to Mini HD Note: HDMI port does not supply power. The monitor needs an external power supply (5V/2.4A or above) or USB-A to USB-C cable to supply.
- Page 13 Connect with Devices HDMI Other Devices USB-A to USB-C HD to Mini HD USB-C to USB-A （external power supply) HD to Mini HD Note: Please connect the external power supply rst then the mini HDMI to HDMI cable to ensure smooth transmission.
-
Page 14: Mode Settings
Mode Settings Multiple-Display Setting for Windows Right-click the desktop and select either Screen Resolution (Windows 7/8) or Display Settings (Windows 10) Screen Rotate Setting: Click the Orientation drop-down list, and then select Landscape or Portrait. Duplicate & Extend Mode Setting: Click the Multiple displays drop-down list, and then select Extend/Duplicate these displays. - Page 15 Mode Settings Multiple-Display Setting for Mac Choose Apple menu > System Preferences, then click Displays. Click the Arrangement tab. To change the position of a display, drag it to the desired position. A red border appears around the display as it's movable.
- Page 16 Mode Settings OSD (On Screen Display) Menu Press the trackwheel to turn on the OSD menu. Scroll the trackwheel to control the cursor on the menu. Press the trackwheel to con rm. Short press the back button to back to the upper page.
- Page 17 Mode Settings OSD (On Screen Display) Menu BRIGHTNESS Adjust the brightness of display. CONTRAST Adjust the di erence in color and light between parts of an image. BRIGHTNESS BLACK Adjust the level of brightness at the darkest part of a visual image. LEVEL SHARPNESS Adjust the sharpness of graphics.
- Page 18 Mode Settings OSD (On Screen Display) Menu COLOR TEMP. Adjust the screen color temperature. COLOR TEMP. Adjust the brightness GREEN of the RGB colors. BLUE LANGUAGE Modify the OSD Menu interface language, default is English. OSD TIMER OSD TIMER Adjust the time th OSD SETTING OSD Menu display remains on the screen.
- Page 19 Mode Settings OSD (On Screen Display) Menu RESET Reset all the items to factory defaults. RESET MUTE Mute the display. VOLUME Adjust the display volume. SIGNAL SOURCE Switch signal sources such as HDMI or Type-C. LOW BLUE LIGHT Filters out harmful blue light, which can MISC cause eye fatigue.
-
Page 20: Supported Devices And Models
Supported Devices and Models Phone Brand Model SAMSUNG DEX, S8/S9/S10/S20 Series, Note 8/Note 9/Note 10 Series HUAWEI Mate 10/Mate 20/Mate 30 Series, Mate RS, P20/P30/P40 Series HONOR Note 10, V20/V30 Seris OPPO R17 Pro, Reno, Find Razer Razer Phone, Razer Phone 2 U Ultra G5, G6, G7 ASUS... - Page 21 Supported Devices and Models Laptop Brand Model Apple MacBook 12 in, MacBook Pro 2016/2017/2018 MacBook Air 2018, iPad Pro 2018 Google Chromebook Pixels, Pixelbook Pen Lenovo Savior Y7000, Savior Y7000P, Savior Y9000K, YOGA 6 Pro, ThinkPad X1 Carbon, Yoga 5 Pro, Miix 720 DELL G3 Series, G5 Series, G7 Series, Inspiron 5000, Inspiron 7000, XPS13, XPS15...
-
Page 22: Speci Cations
Specifications Product: KYY K3-1 Portable Monitor Visible Area: 344.16*194.59mm 368mm Panel Type: IPS LCD Contrast Ratio: 1000: 1 Resolution: 1920*1080 15.6 inch Color Temperature: 6800K Brightness: 300cd/m² Aspect Ratio: 16:9 Display Color: 16.7M Speaker: Built-in Speaker (1W*2) Visual Angle: H 85°/85°Min V 85°/85°Min Product Dimensions: 368*225*9.0mm... -
Page 23: Notices
Notices • Before setting up the monitor, carefully read all the instructions with the package. • To prevent re or shock hazards never expose the monitor to rain or moisture. • Never attempt to open the monitor cabinet. • Before using, make sure all the cables are correctly connected and power cable is not damaged. -
Page 24: Troubleshooting
• Check if the monitor and the computer are in the "ON" mode. • Make sure the cable is properly connected between the KYY monitor and the computer. • Please make sure that the monitor has been charged Can't connect by the connected device or by the included 5V/2.4A... - Page 25 Problem Possible Solution • Long press the power button for 3s to turn o the The screen ickers in monitor and restart it again. various colors when starting up. • Please make sure that HDR mode is turned o and Brightness/Volume Scene(ECO) Mode is not adjusted shows grey and can't...
