INSTALLATION & OPERATION MANUAL
Gas Countertop Thermostat Griddle
Models:
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION,SERVICE OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE
INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
Please call the ROCKET COOKING Service Department and ask for contact information
RCTG-24
24
" Thermostat griddle
RCTG-48
48 " Thermostat griddle
For Service on Your Gas Griddle:
for your local service company.
1
RCTG-36
36
" Thermostat griddle
RCTG-60
60 " Thermostat griddle
Advertisement
Table of Contents
Related Manuals for ROCKET COOKING RCTG-24
Summary of Contents for ROCKET COOKING RCTG-24
- Page 1 MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT. For Service on Your Gas Griddle: Please call the ROCKET COOKING Service Department and ask for contact information for your local service company.
-
Page 2: Installation
This manual contains important safety instructions which must be strictly followed when using this equipment. Please retain this manual for future reference. Instructions must be posted in a prominent location. All safety precautions must be taken in the event the user smells gas. - Page 3 the carrier within 15 days of delivery. Carefully unpack your griddle and make sure that no parts are discarded with packaging material. A pressure regulator designed to operate with the griddle has been supplied and must be installed before the griddle is placed into service (Refer to GAS PRESSURE REGULATOR INSTALLATION in this manual).
-
Page 4: Gas Connections
personnel. From the termination of the flue to the filters of the hood venting system, a minimum clearance of 18” must be maintained. Information on the construction and installation of ventilating hoods may be obtained from the standard for “Vapor Removal from Cooking Equipment”, NFPA No. 96 (latest edition), available from the National Fire Protection Association, Battery march Park, Quincy, MA 02269. - Page 5 PROPANE GAS CONVERSION This griddle is shipped from the factory equipped with fixed burner and pilot orifices for natural gas operation. The burner and pilot orifices required to convert the griddle to propane gas are shipped with the griddle in the shipping packaging.
-
Page 6: Operation
OPERATION The griddle and its parts are hot. Use care when operating, cleaning or servicing the griddle. BEFORE FIRST USE Remove all packing material and protective plastic from surfaces of the unit. Before leaving the factory, the griddle plate is coated with protective coating as a rust inhibitor. Remove this film when the griddle plate is being cleaned prior to its first cooking use. -
Page 7: Cleaning The Griddle
When zone cooking, it is suggested that you start with your lowest temperature setting at either side of the griddle, increasing the zone temperature as you move up the zone line. These zone cooking guidelines will vary depending on product temperatures, size and shape. This guide should be adjusted to suit your product and operational cooking preference. - Page 8 2. The pilots will remain lit and monitored by the safety valve as long as the main gas supply is on. EXTENDED SHUTDOWN 1. Shut off the main gas supply valve. Apply a heavy coat of vegetable oil over the griddle plate to inhibit rust. ROCKET COOKING...
- Page 10 Conversion Kit Instructions Gas Countertop Thermostat Griddle Models: 24 ” 36” 48” 60” Thermostat Controlled: WARNING This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
- Page 11 L.P. Position of insert. Regulator is now converted to L.P. Continue with installation 9. Attach gas conversion label on appliance Gas conversion label ROCKET COOKING Gas Countertop Thermostat Griddle 84 Progress Lane Waterbury , CT 06705...
- Page 12 Limited Warranty ROCKET COOKING warrants to the original purchaser of new equipment that said equipment, when installed in accordance with our instructions within North America and subjected to normal use, is free from defects in material or workmanship for a period of 1 year. The labor warranty is one year from original installation or 18 months from actual factory shipment date whichever date occurs first.
