Summary of Contents for Swisstone SW 750 Pro

  • Page 1 SW 750 Pro Instructions...
  • Page 2 Overview front 1. Microphone. 2. Shortcut button. Shortcut to sports mode. 3. Turn knob/confirmation button. Turn the knob to switch screen. Press to select/confirm: 4. Power button. Longpress to power on/off. Press to go back to main menu. Press to turn on/off display.
  • Page 3 2. Overview back 5. Heart rate sensor. 6. Charging connectors. 7. Magnetic charging cable.
  • Page 4 3. How to charge While it’s possible that your SW 750 Pro will already come with enough charge to be powered on right out of the box, we recommend to fully charge it before first use. Place the magnetic charging cable on the back of the watch (as shown in the figure ).
  • Page 5 5. Install the app Download and install the app SwissFit HR Pro from Google Play or App Store on your smartphone. Compatible devices • Android version 6.0 and later • iOS version 9.0 and later • Bluetooth 4.0 and later compatible device See more about the app and how to pair the watch with the smartphone on 7.
  • Page 6 Clock display Long press the clock and then swipe LEFT/RIGHT to select the clock interface. Tap to select Swipe left-right from the main screen From the main screen (clock) you can swipe RIGHT for the notification screen. Press to view a notification Longpress to clear all notifications.
  • Page 7 Note! It will only clear the notifications on the clock, not ton the phone Options from the main screen From the main screen (clock) you can swipe UP/ DOWN to view the statistics for your exercise. See the screens for single exercise, sleep monitor, heart rate testing, GPS position.
  • Page 8 Main menu From the main screen (clock) you can swipe LEFT for the main menu. Tap to select mode Swipe UP to get to the second screen of the main menu. Swipe RIGHT to return. Icon Explaination Function View your phone’s Phonebook. Tap to call contact.
  • Page 9 View your phone notifications in the watch (Notification type must be set Notification up in the phone). If you delete notifi- cations on your smartphone, they will also no longer be displayed on the SW 750 pro. Swipe up/down between the main menu screens.
  • Page 10 Icon Explaination Function Take photos by watch,photos will be saved in your mobile.(You should Remote open the mobile’s camera first for camera iPhone). Control the music on your phone and adjust the volume. Music IMPORTANT: For remote music control, the SW 750 Pro must be connected twice in the Bluetooth settings of the smartphone! The second connection...
  • Page 11 Icon Explaination Function Turn on the display by a simple twist of your wrist. Gesture Set to on or off. Select sports mode: walking, running, trail run, run indoor, biking, hiking, swimming. Sports You can see the day’s movement (step, distance, calorie, time) by clicking the corresponding screen.
  • Page 12 Settings menu This is the options in the settings menu. Tap to select setting Most settings can be done in the app also. Icon Explaination Function Set gender, height, weight, date of birth. Profile Turn Bluetooth on/off. Note: You must establish the Bluetooth Bluetooth connection if you want to access contacts, call lists, etc.
  • Page 13 Icon Explaination Function Select between Celsius or Fahrenheit degrees for temperature. Tempera- ture Set sound, volume and notification type for calls and notifications. Sound Set the screen brightness and backlight off time. Display Displays the device name and software version. Information Select the language synchroniz- ing with the mobile phone or not,or...
  • Page 14 Location Make sure that the GPS is enabled Slide down to find the location page, then wait up to 3 minutes while the GPS searches for your position. If the positioning is successful, latitude and longitude will be displayed. If the positioning fails no data will be displayed.
  • Page 15 If the GPS fails to get a fix within 3 minutes you will be asked to Wait/Skip. GPS off GPS on, but GPS fix GPS fix failed successful...
  • Page 16 3. Find your watch: Bluetooth ID: Settings - Watch info When found, tap your Bluetooth ID in the app. 4. Tap Yes to pair your SW 750 Pro to your smartphone. 5. Allow requested permissions for best function. Android screens...
  • Page 17 8. Synchronise the device SW 750 Pro automatically synchronises the data with your phone after the first pairing. Steps, active calories, distance, date and time is included in the synchronisation.
  • Page 18 9. Disconnection If the watch is outside the Bluetooth range of the connected smartphone, the message “Discon- nected” appears. When the connection is reestablished, a note will also appear. 10. Call and message notifications Tap the Device tab, then tap Device setting.

  • Page 19: Weather Function

    Incoming call/messages (WhatsApp, SMS, etc.) will be displayed on the watch and it will vibrate. If it’s a known caller the name will be displayed, otherwise the number. For messages, you will see the sender and the content of the messages. 11.
  • Page 20 12. My sports data Note! All sport activities should be started/paused/stopped via the watch. Click on the step target view to enter the My Sport Data page. This shows the cumulative sport time, calories burned, active days, continuous sport days, today’s sport steps and details of the last sport for each type of sport data.
  • Page 21 GPS sport details Under Total you can also find each recorded sports activity. The recorded activities can also be found if you click the motion icon in the top right of the homepage. The blue line on the map indicates the activity track, with green as the starting point and red as the end point.
  • Page 22 Click to share the activity with others via Strava, Google Fit, Apple Health or simply as an image that you can send with the app you choose. See more on Sharing sports activity. 13. Steps Click the Today’s steps to see the latest week’s walking data.
  • Page 23 14. Weekly workouts In the weekly workouts, you can freely set the target for each sport type of the day. Click free setting or recommended mode to set the sport type target within one week. The recommended mode of exercise intensity is available in three types: lower, moderate or high.
  • Page 24 After setting the target, re-enter the screen to view the details of your targets as well as a weekly report.
  • Page 25 Click Set up to set the daily registration period between 4 to 12 hours. 16. Sleep monitor Wear the bracelet SW 750 Pro at all times, also at night, to analyze your sleep quality according to your nocturnal movements and to monitor your entire sleep schedule.

  • Page 26: Heart Rate Monitor

    Click Synchronize to receive the latest measurements from the watch. Important: The SW 750 Pro does not replace a doctor. Heart attacks can not be detected. If pain or pressure in the chest area is felt, immediately alert the rescue service.
  • Page 27 Important! Your SW 750 Pro is a screening device designed primarily for diagnostic review. The monitored heart rate data are not for medical purposes and are not intended for the diagnosis, treatment, cure or prevention of disease or physical condition.
  • Page 28 Dynamic heart rate Click on Detailed to enter the dynamic heart rate test. Note! The watch must be set to Auto for dynamical Heart rate mode for the dynamic measuremet to function. Click Start to start collection of heart rate data. A graph of the heart rate will be drawn.
  • Page 29 18. Sharing sports activity After the watch’s sport data is synchronized with the app, you can share the data by clicking the Share button in the upper right corner. Strava Strava is a social fitness network, that is primarily used to track cycling and running exercises, using GPS data.
  • Page 30 Android Google fit You can share your sports data on Google Fit. You need to log in google account first. iOS Apple Health You can share your sports data on Apple Health. In Apple Health check Allow of the data that should be shared.

  • Page 31: Send Feedback

    21. Send feedback Click the menu and then Device. Click the About tab and then the settings cogwheel and tap Feedback to send suggestions and feedback at any time to help us to improve the product. 22. Other information Li-ion battery This product contains a Li-ion battery.
  • Page 32 Health Warnings • If you have a pacemaker or other internal electronic device, consult your physician before using a heart rate monitor. • The Sport Watch optical wrist heart rate monitor emits green light and flashes occa- sionally. Consult your physician if you have epilepsy or are sensitive to flashing lights. •...
  • Page 33 Correct disposal of this product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or manual indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste.
  • Page 34 SW 750 Pro is in compliance with Directives: 2014/53/EU and 2011/65/EC (RoHS). A copy of the Declaration of Conformity is available at www.swisstone.de. Warranty In case you need support during setup or usage of your product you will find the relevant contact details on the following website: www.swisstone.de.
  • Page 35 Technical Specifications Bluetooth version Bluetooth frequency band 2402-2480 MHz Bluetooth max output power 10 mW (dBm) GPS receiver: Category 3 Dimensions Diameter: 5,2 cm Height: 1,5 cm Weight 65 g Display 240 x 240 pixels, 1.3“ IPS colour Waterproof IP68 Battery 450 mAh Li-ion battery Operating ambient temperature...
  • Page 36 Changes and errors excepted. © IVS GmbH 2019 • All rights reserved Manual_SW_750_Pro_en_70x95_v30...
