Summary of Contents for PV logic 100wp
- Page 1 PV Logic ® MHD Rigid User manual MHD Rigid Solar Panels 100wp/125wp/150wp/200wp Important: please read before first use. Technical helpline 01684 774 000...
- Page 2 2 x 3m cable with MC4 connectors Charge Controller Upgrade (not shown) All PV Logic Rooftop Kits can be supplied with an upgraded 15Ah, 20Ah or 30Ah MPPT 1 x Fuseholder and fuse (b) charge controller instead of the standard PWM controller.
- Page 3 Please read all instructions carefully before work begins IMPORTANT: When connecting a solar panel to a battery, it is always recommended that a voltage regulator is used to prevent both reverse current feed (at night) and overcharging of the battery. Step 1: Connecting cables to solar charge controller NOTE: for 200wp panel with twin cables, connect MC4 connectors attached to panel cable to 2 x 3m cable (supplied) with MC4 connectors and follow instructions below:...
- Page 4 Warranty PV Logic MHD rigid solar panels are supplied with a 10 year panel build warranty from the date of purchase from Solar Technology International. This guarantees the panel from mechanical failure and water ingress during this period. The warranty is void if the outer layers, or edges, of the panel have been penetrated, damaged or cracked or the recommended handling, storage, installation and care procedures have not been followed.
