Summary of Contents for Delstar DS 700

  • Page 1                        ...
  • Page 2 Delstar DS 700  User Manual ...
  • Page 4 ABOUT MICROSOFT WINDOWS CE    Microsoft Windows CE operating system was initially developed by Microsoft to run small personal  computing devices, (PDAs etc).  Because PDAs and personal computing devices require minimal resources, the Windows CE operating system  was developed for efficiency, requiring less processing power and very little RAM memory.  Windows CE is a great operating system for Netbooks where the primary function is to access the internet  and surf the Web.    Because of its efficiencies it may struggle when dealing with resource intensive programs and applications.    Some limitations users may experience are:  * Difficulty opening large PDF files. (In this case, user can simply "save" the file to the hard drive, then open).  * When reading & replying to email via remote access, user may need to use “Plain text” mailing function  * Printer hook‐up. Windows CE was designed for portable units, so the programming will only work with  portable printers. Netbook users can simply transfer or email documents to another computer for printing.      * Downloading. Windows CE won't be able to accept all downloads.    Some are just too large. Please check  all software minimum requirements before download.       ...
  • Page 5: Adjusting Time And Date

    Important!  Please adjust date and time before accessing the internet. This will  keep security certificates to a minimum as you surf the web.          Adjusting time and date:  Move curser to bottom of screen to view toolbar. A tool bar will pop up. Click on the start button.  Select settings then open control Panel and double click on the “date and Time” icon. Please set the  correct time zone then the date and time. Once you have set the date and time, press the ok button  on the top right of the window. ...
  • Page 6: Specifications

    Specifications Software Package      Samsung 533 MHz CPU    RAM: 128 MB  Word Viewer  HDD: 2GB Solid State Drive  Presentation Viewer  OS: Windows CE  Spreadsheet Viewer    7" WVGA LCD Backlights (800 x 480)  Software package:  Network:  Windows CE    Wireless Lan 802.11 b/g  Fast Launch User Desktop Interface  10/100M Ethernet Controller  Document creator    SD Card Slot  Spreadsheet creator  Audio:    Presentation creator    Dual speakers  PDF Viewer    Input/output:  Media Player    3 x USB 2.0    Microphone jack    Headphone jack   ...
  • Page 7: Basic Operation

    Basic Operation    Understanding Netbook Components  Screen and Keyboard Panels  Speaker Speaker Power On/Off...
  • Page 8 Power Indicator  Light  Capital  Lock Light  Touchpad    Battery  Left    Pointing    Right  Indicator  Click  Device Click  Light   ...
  • Page 9 Components    SD card Slot  Microphone Slot  Earphone Slot  USB Port  Network Cable  Power Socket ...
  • Page 10: Operation

      Operation  Charging your device  Before using this Netbook, the battery  will need to be fully charged. To  maximize the life of the battery, the  first charge must be a full charge. We  recommend that you charge the unit  for 12 hours in order to achieve the  full charge. Subsequent charge times  will be shorter.        Tip: When using external USB equipment, please be sure the Netbook is connected with the AC  adapter. USB devices that are powered by USB ports will increase battery consumption.       ...
  • Page 11: Functions And Operation

    Functions & Operation  Powering Up .  To turn on the unit, press  the “Power” button on  the lower right side of  the screen, (hold for 2  seconds).              Shutting Down.  Drag the pointer to the bottom of the screen. This will cause a tool bar to pop up. Click the Start  button on the left end of the tool bar, and select the “shutdown” option.         ...
  • Page 12: Checking Battery Level

    Checking Battery Level  To check battery level, click “start”, select “settings”, click “control panel”,  Then double click on the “power” icon    Adjusting time and date:  Move curser to bottom of screen to view toolbar. A tool bar will pop up. Click on the start button.  Select settings then open control Panel and double click on the “date and Time” icon. Please set the  correct time zone then the date and time. Once you have set the date and time, press the ok button  on the top right of the window.      Reminder…… Setting the date and time will help eliminate multiple security certificate pop‐ups  when using the internet.             ...
  • Page 13 Fast Launch User Desktop Interface      This Netbook comes  equipped with a    with a great quick  launch interface, making  it easy to navigate  through the different  programs.    You will see the  interface, once  you click the  blue “UI” icon on  your desktop.                 ...
  • Page 14 Hooking up to a wireless network (WI‐FI)  1) Double click the UI icon on the desktop to access the Quick Launch interface window.    Click the  Wi‐Fi on/off button, and then click the “ON” button that appears. Drag the pointer to the bottom of  the screen to pull up the tool bar. On the right side of the tool bar there will be an icon of a  computer with a red X through it. Double click on the computer icon. A WiFi window will pop up.  Click on the “wireless information” tab. The netbook will start searching for available networks.    Click on an available network, and then click the “connect” button on the bottom of the window.    The “wireless network properties” screen will show up.    Click “OK” on the bottom of the screen.    It will take you back to the “WIFI” window, where you can see the status and signal strength of the  network you selected.    Click “OK” in the upper right hand corner of the WIFI screen.  From the desktop of the quick launch interface, you can now access the Internet.  (NOTE once you have a connection, there will no longer be a red “X” through the computer icon on  the bottom tool bar.      2) With WEP key: To Set up and begin using a wireless network that requires a WEP key, follow the  same instructions as above. If your computer finds a network that is secured, (meaning it requires a  WEP key), simply double click on that network and fill in the Network name, and Password.         ...
  • Page 15   Your Network    Password                                      Your Network      Name     ...
  • Page 16: Setting Up A Wired Network

      Setting up a wired network:    To set up a wired network, simply connect the Ethernet cable to the back of the Netbook, and go to  Start/Control Panel/Network connections. Here you will see your LAN connection. You may double  click on the network icon to see the connection speed.    Microsoft Remote Desktop Client    With Remote Desktop, you get complete access to your work/home computer via an Internet or  network connection. For example, you can connect to your office computer from home and work  with files, programs, and resources as though you were in front of your computer at work.  Please go to      http://www.microsoft.com/windowsxp/downloads/tools/rdclientdl.mspx for full detailed instructions. Tip.   Please save files to your SD Memory Card(s). This will allow you to: A) Transfer the files, and B)  Protect your files from computer crashes. There is a special feature this unit has and to take full  advantage of it saving your work to the SD card will prove vital. The feature is called “Reset” and will  is explained next.     ...
  • Page 17: Reset Feature

    Reset Feature   Computers can at times “freeze”. There is a master reset button on the bottom of the unit. You will  find it valuable in recovering your netbook. When you initiate the button it restores the netbook to  factory default settings.    It’s like formatting your hard drive and reinstalling windows CE. You’ll be  ready to go in about 30 seconds. Use a small jeweler’s screwdriver or bent paper clip. You will feel a  soft click when you access  the button correctly. It’s  recommended that you save  all your work on a SD Card  (not included). Remember to  again set the time and date  before connecting to the  internet .        Master Reset Button    ...
  • Page 18 Links    Skype Link  Internet  Browser              Messenger  YouTube    Services link  Link    YouTube is a video sharing website where users can upload, view and share video clips.  Once you click on the “YouTube” icon you will see the YouTube homepage, and then you can click on or  search for any video you would like to watch.     ...
  • Page 19   Skype  This Netbook also comes equipped with Skype  software. Skype is software that allows users to  make telephone calls over the Internet, calls to  other users of the service, and to free‐of‐charge  numbers.    Calls to other landlines and mobile  phones can be made for a fee. Additional  features include instant messaging, file transfer  and video conferencing. To use the Skype  software, simply click on the Skype icon and this  will bring you into the “sign in” page. Enter your  information, and enjoy!    Instant Messaging    This Netbook comes with great instant  messaging solution. You can choose from a list  of seven different messaging providers, such as:  MSN, AIM, Yahoo, Google, ICQ, Myspace, and  Facebook. To use these features, simply click on the “IM” icon on your desktop, or from the quick launch  screen.     ...
  • Page 20 Software      Media  Spreadsheet  Player  Editor            Document  Presentation    Editor  Editor    ...
  • Page 21: Media Player

    Document  Document, is word processing software that allows you to create essays, notes, writings, etc., It will allow you  to read and edit Microsoft Word documents. You can access this software by simply clicking on the Document  icon on the desktop, or from the quick launch screen.    Spreadsheet  Spreadsheet is a spreadsheet‐application for Microsoft Windows. It will allow you to create, read, and edit  Microsoft Excel documents. It features calculation, graphing tools, pivot tables and a macro programming  language called VBA. You can access this software by simply clicking on the Spreadsheet icon on the desktop,  or from the quick launch screen.  Presentation  Presentation, is a presentation program used to easily make electronic presentations for work, school,  lectures, and more. It will allow you to create, read and edit Microsoft PowerPoint documents.    You can  access this software by simply clicking on the Presentation icon on the desktop, or from the quick launch  screen.  Media Player  Media Player is a digital media player and media library application that is used for playing audio, video and  viewing images. This player can play files from your SD card, the internet, and even certain USB flash media  devices.   ...
  • Page 22: Frequently Asked Questions

    Frequently Asked Questions    1) Can I print a document?  You will have to transfer the file to another computer. Simply transfer file to SD card or USB flash card  and transfer to computer with a printer attached. You also may email your file to the other computer  as an attachment.    2) Why does my wireless internet connection speed differ from place to place?  Connection speeds will vary because of a few factors but, usually the culprit is signal strength. Signal  strength will vary because of your location in relation to the transmitting router as well as  interference. Try moving closer to the transmitting router.  3) How long do the batteries last on a full charge?      The batteries should last about 3hrs before you will need to recharge them. Battery life will vary  depending on the usage. For example, a USB device that is powered thru the USB port will drain &  shorten battery life faster.    4)    My computer’s "locked‐up"! I can't get it to do anything. I can't even turn it off. What should I do?  In the event of a lock‐up, you can reset the unit to the factory defaults quickly & easily by pressing  the master reset button. It’s explained in this manual under the section”Reset Features”.   ...
