Listen LS-88 Quick Start Manual

Quick Start Guide
LS-88

How to Set Up Your ListenIR Portable System

Your Portable ListenIR System Comes
1
with the Following Products
• LT-84 ListenIR Transmitter/Radiator Combo
• Power Supply
• Tripod
• Microphone
• LR-4200-IR iDSP Receivers
• Universal Ear Speakers
• Neck Loop/Lanyards
• 4-Port USB Charger
• USB to Micro-USB Charging cables
• Assistive Listening Compliance Sign
• Portable IR Carrying Case
2
Transmitter & Microphone Set-Up
POWER
POWER
SWITCH
Step One: Remove the LT-84, power supply, tripod
and microphone.
Step Two: Screw the tripod into the bottom of the LT-84.
Step Three: Plug the power supply into the back of the
LT-84.
Step Four: Plug the microphone into the back of the
LT-84.
VOLUME CONTROL
MICROPHONE
INPUT
PRO TIP:
Make sure that the LT-84 is not concealed
behind walls, curtains, or treated glass, as
Infrared light needs a clear line-of-sight to
the receiver for the best performance.
Step Five: Plug power supply into an outlet. Turn
on power switch.
Make sure the microphone is placed
Step Six:
close to the sound source.
Step Seven: Turn the volume all the way up.
