Page 1 A4 MFP User's Guide Avision Inc.
Page 2 User’s Guide Copyrights and Trademarks Ethernet is a registered trademark of Xerox Corporation. Windows 7, 8, 9, 10, 11 are registered trademarks of Microsoft Corporation in the United States and/or other countries. Other product names used herein are for identification purposes only and may be trademarks of their respective companies.
Page 3 Federal Communications Commission (FCC) compliance information statement Part 15 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 4 User’s Guide Safety Information When using this equipment, the following safety precautions should always be followed. Safety During Operation In this manual, the following important symbols are used: WARNING: Indicates potentially hazardous situations, which if instructions are not followed, could result in death or serious injury. CAUTION: Indicates a potentially hazardous situation which, if instructions are not followed, may result in minor or moderate injury or damage to property.
Page 5 The following symbols indicate that the related section includes information on actions which must be performed. Specifics of the required action are indicated inside the symbol. [Alert of required action] [Remove the power plug from the outlet] Installation and the Operating Environment Warning Do not install the equipment near direct sun light, heating or air conditioning Direct sunlight or high temperature may damage the machine.
Page 6 User’s Guide Caution Place the device in an independent, well-ventilated area. Place the device in a place with good environmental conditions. Operating the machine beyond the recommended temperature and humidity may cause an electrical fire. Do not place heavy objects on the unit. It may cause unbalance and the device may fall down.
Page 7 Do not attempt to remove the covers and panels which have been fixed to the product. Some products have a high-voltage part or a LSU beam source inside that could cause an electrical shock or blindness. Do not modify this product, as a fire, electrical shock, or breakdown could result. If the product employs a LSU printhead, the LSU beam source could cause blindness.
Page 8 User’s Guide About the Consumables Warning Do not unpack the consumables and store the machine’s consumables in any of these locations: Outdoors  Near excessive dirt or dust, water, or heat sources  In locations subject to shocks, vibrations, high temperature or humidity, ...
Page 9 Use only the USB cable that came with your device and avoid abrasions, cuts, fraying, crimping, and kinking. Using any other USB cable could cause fire, electrical shock, or injury. Do not store the cables in the following locations: Outdoors ...
Page 10 User’s Guide This document is intended to be used for these models -AXH2030, AXH2030N (Network), and AXH2030NW (Network, Wi-Fi). The product drawing and screenshots use AXH2030N as examples.
Page 11 1. Overview Introduction Thank you for choosing Avision’s state-of-the-art MFP which can be used for printing, and copying. Through the easy-to-use control panel and LED lights, operation becomes simple and easy. Features  Easy Copy: As long as paper is loaded in the side feeder, copy can be made automatically.
Page 12 External View The Front View 1. Output Tray 5. Paper Stopper 2. Handle of the Front Cover 6. Control Panel 3. Main Paper Tray 7. Scan Module 4. Front Cover...
Page 13 The Rear View 1. USB Port (Type B, to PC) 4. Rear cover 2. LAN Port 5. Handle of the Rear Cover 3. Power Receptacle...
Page 14 Package Contents Software CD (*MFP Driver, User Manual) Main unit Calibration Sheet Power Cable USB Cable * You may also download the driver and manual at www.avision.com/download.
Page 15 The Control Panel Panel A Panel B Panel C Panel A: For the model comes with a Wi-Fi module. Panel B: For the model comes without a Wi-Fi module. Panel C: For the model comes without Ethernet network or Wi-Fi module. Button Name Description Mode Selection...
Page 16 LED Light Description Status Green Light Indicates 1-Sided copy has been selected. Green Light Indicates 2-Sided copy has been selected. Indicates users need to insert a page with the Blinking Green other side facing outward to the document feeder. (timeout: 10 seconds) Blinking Green Indicates a blank page has been detected.
Page 17 Extinguished Indicate power has been turned off. Network Description Indicated Status Solidly lit in Ethernet+AP (Access Point)+Station white The product is connected to both a wired and wireless network and the wireless network in both the AP mode and station mode. Flash in green Ethernet+AP mode The product is connected to a wired network...
Page 18 User’s Guide 2. Installation Operation Space Please reserve the following operation space. Measuring unit: mm Machine dimension: 404 x 380 x 204 mm (WxDxH) Removing the Tapes Remove the packing material and tapes of the product.
Page 19 Installation Remove the tape and cushion on the paper tray. Removing the Tapes, Protective Sheet, and Seal on the Drum and Toner Cartridge Assembly WARNING! Be careful not to inhale toner.  To avoid print quality problems, DO NOT touch the toner rollers. ...
Page 20 User’s Guide   Remove all the tapes, protective sheets on the drum and toner cartridge assembly. DO NOT touch the drum surface. Important! DO NOT touch the drum surface since the fingerprints or other  marks may affect the print quality. DO NOT expose the drum unit under light for a few minutes.
Page 21 Installation Push the latch in the middle of the toner cartridge forward in the direction of the arrow to separate the toner cartridge from the drum. Pull out the protective seal of the toner cartridge until it is completely removed. Install the toner cartridge to the drum unit until you hear it lock into place.
Page 22 User’s Guide Press down the handle of the toner cartridge to fix the toner cartridge. Close the front cover.
Page 23 Installation Lifting Up the Paper Stopper Gently lift the paper stopper and its extension to collect the paper. Paper Stopper...
Page 24 User’s Guide Loading Paper into The Main Tray To insert paper to the main paper tray, Fan your paper first to ensure that the pages do not stick together. Align the edges of the documents by tapping the bottom of the stack against the table top.
Page 25 Installation   Push the width guide tab ( ), and move the width guide ( )to the correct position for the paper size being loaded.     Push the length guide ( ), and slide the guide ( ) to the correct position for the paper size being loaded.
Page 26 User’s Guide   To move the tray back to the original A4 length, press down the second length  adjustment latch , and at the same time slide the manual tray to the left   ...
Page 27 Installation Printing Side Facing Down Load the paper stack with the as illustrated. Insert the tray to the MFP.
Page 28 User’s Guide Paper sizes and weights used for Main paper tray Paper capacity 250 pages（70 g/m² plain paper） A4 (210 x 297 mm) Paper size A6 (105 x 148 mm) B6 (JIS) (125 x 176 mm) B5 (JIS) (176 x 250 mm) Executive (184 x 267 Letter (216 x 279 mm) Legal (216 x 356 mm)
Page 29 Installation Important: To avoid the chance of miss-fed, make sure the length guide tab and length slider are installed in their proper positions. Make sure the end of your paper slightly touch the length guide as  indicated in below. Length Guide Tab Make sure the length slider is installed in the specified location in either...
Page 30 User’s Guide Loading the Manual Tray To insert paper to the manual tray, Load the paper with the print side Facing UP as illusrated. Slide the paper guides so that they lightly touch the paper stack.
Page 31 Installation Paper size and weights used for Manual Tray 1 page（70 g/m² plain paper） Paper capacity A4 (210 x 297 mm) Paper size A6 (105 x 148 mm) A5 (148 x 210 mm) B6 (JIS) (125 x 176 mm) B5 (JIS) (176 x 250 mm) Executive (184 x 267 Letter (216 x 279 mm) Legal (216 x 356 mm)
Page 32 User’s Guide Connecting to Power Connect the of the power cable to the power jack of your product. Connect the other end to an appropriate power outlet. Turning On The MFP To turn on the MFP, press the power button located on the control panel. Ready LED will be lit.
Page 33 Installation Connecting to the Network Connect the MFP to the network to use the network printing function. Connect one end of your network cable to an available port of your Ethernet Hub Connect the other end to the LAN port at the back of the product as shown. Note: To obtain the IP address, press and hold the [Cancel] button for 5 seconds.
Page 34 Please follow these steps to install the MFP driver if this machine is connected to your computer via a USB cable. *You may also download the driver and manual at www.avision.com/download. Important!  DO NOT connect the USB cable before installing the MFP’s driver.
Page 35 When the Finish dialog box appears, click Finish to complete. If you have successfully installed the driver, you will find “Avision AXH2030N Printer” has been added in the “Printers and Faxes” option from the Control Panel.
Page 36 Please follow these steps to install the scanner, MFP drivers if this machine is connected to your computer via a network. You may also download the driver and manual at our web site www.avision.com. Insert the supplied CD into your CD-ROM drive. The installation menu wil be displayed.
Page 37 Use your mouse to choose your desired host name to be connected. When the Finish dialog box appears, choose 「Finish」to complete. If you have successfully installed the MFP’s driver, you will find「Avision AXH2030N NetWork」, has been added in the 「Printers and Faxes」option from the Control Panel.
Page 38 Make sure the product is connected to your computer via a USB cable. Start Network Setup Tool by choosing the Start button and then select All Programs>Avision AXH2030N MFP>Network Setup Tool in succession. The following Network Setup Tool screen will be prompted.
Page 39 Installation Check [Obtain an IP address automatically] to obtain the IP address directly from the DHCP server or you may enter your static IP on the [IP Address], [Subnet Mask], and [Gateway] field respectively. If you have assigned a specific IP, enter your domain name server and WINS server as well and then click [Update Setting] to update the IP information to the product.
Page 40 Make sure the product is connected to your computer via a USB cable. Start the Network Setup Tool by choosing the Start button and then select All Programs>Avision AXH2030N MFP>Network Setup Tool in succession. The following Network Setup Tool screen will be prompted.
Page 41 Installation Check [Obtain an IP address automatically] to obtain the IP address directly from the DHCP server or you may enter your static IP on the [IP Address], [Subnet Mask], and [Gateway] field respectively. Click [Join a Wi-Fi network] and the currently connected wireless networks will be displayed.
Page 42 User’s Guide Uninstalling the Driver From the 「Start」 menu, select 「All Programs」 , 「Avision AXH2030N MFP」 , and then 「Uninstall Driver」. Or from the 「Start」menu, select 「Control Panel」, 「Add or Remove Programs」, 「Avision AXH2030N MFP」, and then 「Remove」. Follow the instructions on the screen to complete removing the scanner driver...
Page 43 3. Copying Making A Copy for a 1-Sided Document Make sure that [1-Sided Copy] LED light is lit, as shown in the figure below. If not, press the [Mode] button until the [1-Sided Copy] LED light is lit as indicated. text facing outward Load your document with the...
Page 44 User’s Guide Making Multiple Copies for a 1-Sided Document Make sure that [1-Sided Copy] LED light is lit, as shown in the figure below. If not, press the [Mode] button until the [1-Sided Copy] LED light is lit. text facing outward Load your document with the side , and align the document...
Page 45 Customizing the Product’s Settings Making A Copy for a 2-Sided Document Press the [Mode] button until the [2-Sided Copy] LED light is lit as indicated. the Front Side facing outward Load your document with side , and align it with the size marks on the feeder. The paper will be automatically feeding through the feeder.
Page 46 User’s Guide Making Multiple Copies for 2-Sided Document Press the [Mode] button until the [2-Sided Copy] LED light is lit as indicated. Front Side facing outward Load your document with the , and align your document with the size mark indicated on the feeder. The paper will be automatically feeding through the feeder.
Page 47 Customizing the Product’s Settings To make more copies, repeat step 5. Making ID Card Copy When [2-Sided Copy] is selected, and your original is smaller than A5 size (210x 148 mm), for example, a name card or an ID card, the machine will enter into the ID card mode and automatically print the front and rear sides of your original on the same side of the sheet.
Page 48 User’s Guide 4. Customizing the Product’s Settings This chapter is specifically targeted to the persons who are responsible for the administration of the product. It is recommended that the administrator read this chapter before installing the machine. The product’s settings can be customized via the product’s embedded web page. How to customize the product’s settings via the webpage will be described in the following sections.
Page 49 Customizing the Product’s Settings Customize System’s Settings via the Embedded Web Page Note: Any update of the web page requires administrator’s login. Refer to the preceding section to setup the product’s network settings. Open your browser and type the product’s IP address on the URL address, for example, http://10.1.21.46 and press Enter.
Page 50 User’s Guide Setting Items to be Customized Status Displays the status and basic information of the product. *Factory Default Item Description Information Display the following basic information of the product. Machine Status Displays the machine status. Host Name Displays the host name. Machine Serial Displays the machine’s series number.
Page 51 Customizing the Product’s Settings System Settings *Factory Default Item Description Option The language displayed on the web Language The displayed language page. varies depending on your operating system Choose if you wish to enter energy Sleep Mode saving mode and how long to enter mode/5Min/*15Min/30M the energy saving mode after your in/1Hr...
Page 52 User’s Guide Password Settings (If these two fields are left blank, this means the password has not been changed.) Enter a password to enable modifying the web page. Password Password should be 8~16 characters or digits in length. Retype Retype new password. Password Copy Settings *Factory Default.
Page 53 Customizing the Product’s Settings Network Displays the network information of the product. *Factory Default Item Description Option Host Name Host Name Dipslay the host name for the product. Ethernet Settings Obtain an IP address *Off/On automatically IP Address: Set up an IP Input the IP address of the product.
Page 54 Update the firmware of the product. Before updating the product’s firmware, you need to first download the latest firmware from our web site at www.avision.com onto your computer. On the webpage, choose [Browse] to find the firmware file on your...
Page 55 5. Configuring the MFP Driver Displaying the MFP Driver Properties Dialog Box (Windows) To display the MFP Driver Properties dialog box, Click Start on the system tray and choose MFPs and Faxes. Right-click the product’s MFP name and choose Printing Preferences. The Printing Preferences dialog box.
Page 56 User’s Guide Configuring MFP Driver Settings The Printing Preferences dialog box consists of the Basic tab, the Paper tab, the Layout tab, the Watermark tab, the Duplex tab, and the More tab. The contents of each tab will be explained in the following sections. The Basic Tab The Basic tab contains settings for Orientation, Copies, Effect, Density, Toner Save, and Invert.
Page 57 Configuring the MFP’s Driver Copies Choose the number of copies to be printed. You can enter up to 999. Collate: Click to print your document in the page order such as 1/2/3, 1/2/3, 1/2/3. N to 1: Click to reverse the printing order of your document. As a result, the last page of your document will be printed first and vice versa.
Page 58 User’s Guide The Paper Tab The Paper tab contains settings for Original Size, Tray, and Media Type. Paper Original Size: Choose the size of paper loaded in the designated tray. Choice: *A4, A5, A6, B5 (JIS), B6 (JIS), Legal, Letter, User Define Tray: Choose the tray from which your paper should be fed.
Page 59 Configuring the MFP’s Driver The Layout Tab The Layout tab contains settings for N-up, and Output Paper Size. N-up N-up: Choose number of pages to be printed on a single sheet of paper. Choice: *Off, 2up(2-in-1), 4-up(4-in-1), 9-up(9-in-1), 16-up(16-in-1) Border: Choose if you wish to add border around each page when printing more than one page on a single sheet of paper.
Page 60 User’s Guide N-up Choose the style you want when printing multi-page Style: document on a single sheet. Choice: *Right, then Down/Down, then Right/Left, then Down/Down, then Left Right, then Down Down, then Left Down, then Right Left, then Down * Factory Default Setting Output Paper Size *Actual Size Print the actual size of your document.
Page 61 Configuring the MFP’s Driver The Watermark Tab The Watermark tab allows you to add some text or image (such as CONFIDENTIAL, IMPORTANT, DRAFT, etc) for your document. First Page only Check to print watermark only on the first page. Clear the check box will print watermark on all pages.
Page 62 User’s Guide Adding a new waterk text To add a new watermark text, Choose Text and then click the Add/New button. The following Watermark dialog box appears. Name Name your watermark text. This name will be shown in the Watermark text list. String Enter your watermark text, such as confidential, important, and so on.
Page 63 Configuring the MFP’s Driver Editing a current watermark text To edit a current watermark text, Choose the waternark name that you wish to edit from the Text list. Click the Edit button. The Watermark Edit dialog box appears. Change your settings for the selected watermark text and choose OK to complete. Removing a current watermark text To remove a current watermark text, Choose the waternark name that you wish to remove from the Text list.
Page 64 User’s Guide Adding a new waterk image To add a new watermark image, Choose Image and then click the Add/New button. The following Watermark dialog box appears. Name Name your watermark image. This name will be shown in the Watermark image list. File Click the Browse button to locate your watermark image.
Page 65 Configuring the MFP’s Driver Editing a current watermark image To edit a current watermark image, Choose the waternark name that you wish to edit from the Image list. Click the Edit button. The Watermark Edit dialog box appears. Change your settings for the selected watermark image and choose OK to complete.
Page 66 User’s Guide The Duplex Tab The Duplex tab allows you to print your document on two sides of the paper. Choice: Flip Horizontal, Flip Vertical. Duplex Check to flip the duplex document on the left edge. *Flip Horizontal Flip Vertical Check to flip the duplex document on the bottom edge.
Page 67 Configuring the MFP’s Driver The More Tab On the More tab, a Wait Timeout option is provided to set the amount of time the MFP waits for data to come from computer during a job. If the data stream pauses for longer than the specified number of seconds, the job is cancelled.
Page 68 6. Printing Cancelling a print job You can stop a print request by using the control panel or by using the software program. For instructions about how to stop a print request from a computer on a network, see the online Help for the specific network software. Stopping the current print job from the control panel Press the Cancel button on the control panel.
Page 69 Printing Documents from a Mobile Device In the list of MFPs, double-click the name of this product to open the print queue or spooler. Select the print job that you want to cancel, and then press Delete from the Document menu.
Page 70 Printing Documents from a Mobile Device For the model comes with a Wi-Fi module, the product can be converted into a wireless device and your mobile device is able to print emails and documents by simply tapping Print from the menu. Making Preparation To connect the product to a wireless LAN, prepare the followings: An environment in which a wireless LAN is available...
Page 71 Printing Document from A Mobile Device Print via Software Application (depending on your mobile phone)  You can also turn on Wi-Fi on your mobile phone, connect it directly to the printer, then open the document on the mobile phone, use the software that opens the document and select the printer to print it out.
Page 72 User’s Guide Launch the program by clicking the Start>All Programs>Avision AXH2030N MFP>Network Setup Tool. The main window appears. AXH2030N MFP On the [General] page, check [Wi-Fi (Station)]. Click the [Wi-Fi (Station)] tab to prompt the [Wi-Fi (Station)] page. Check [DHCP] to obtain the IP address directly from the DHCP server or you may enter your static IP on the [IP Address], [Subnet Mask], and [Gateway] field respectively.
Page 73 Printing Document from A Mobile Device Click [Connect] to start connecting the SSID (wireless network name) and then update the IP information to the product. If update is successfully, an [Update Device Successfully] message will be displayed and the Network Setup Tool will be automatically closed.
Page 74 User’s Guide Printing Your File from a Android Mobile Device Make sure that the Mopria Print Service (Print App) has been installed on your Android mobile device. The Mopria Print App can be purchased for free from an application store such as Google Play. Select the same wirelss network as your MFP.
Page 75 Printing Document from A Mobile Device Select your MFP. Select [XXX at XXX] from the MFP list. (XXX=Modellnummer) xxx at xxx Mopria Print Service Open the file which you want to print. Open the file you want to print. Choose [Print] from the menu and select your MFP. xxx at xxx Mopria Print Service...
Page 76 User’s Guide Choose print settings and print. If you do not need to change xxx at xxx  Mopria Print print options, tap Print to Service send the print job. If you need to change print  options, continue to the next section.
Page 77 Printing Document from A Mobile Device Printing Your File from a iOS Mobile Device Turn on your mobile devices such as iPhone or iPad. Tap 「Settings」 and then open Wi-Fi. Select the network same with your MFP. Open the picture or the document that you want to print. Tape the Share icon ) and then the print icon ( 4.
Page 78 User’s Guide 8. Troubleshooting Monitoring Your MFP Using MFP Status Monitor The MFP Status Monitor allows you to monitor your MFP’s status, get information on consumable parts, and alerts you when MFP errors occur. MFP Status Monitor is available when the MFP is connected directly to a host computer via the USB port or a network port.
Page 79 Troubleshooting Getting MFP Status Details You can monitor MFP status and get information on consumable products using the MFP Status Monitor dialog box. a Port Name Port name for the specified MFP. B Progress Bar The progress bar to access the latest data of the specified MFP.
Page 80 User’s Guide Click to show the information of the paper tray and J Consumables the consumables parts such as Drum Unit, Toner Cartridge. k IP for a Click here to enter the IP for a shared MFP to get Shared MFP the MFP status.
Page 81 Troubleshooting Setting Monitoring Preferences To make specific monitoring settings, click the Setting tab on the Avision Status Monitor window. Displays the language of the window. Language Check Device Stastus Interval Define the interval to refresh the MFP error status. Choice: 1, 5, 10 (minute), Custom (1 ~ 1440) minute Check this box to show the error message.
Page 82 User’s Guide Clearing A Warning or An Error If a problem occurs during operation, the Error LED will be flashing to indicate a warning or an error status. To solve the problem, please refer the following table for more detailed information. Warning Message Message Description or Solution...
Page 83 Troubleshooting Please replace toner cartridge from the original Toner cartridge manufacturer. error. (200036, 201505, 201515 Error Message Possible Causes or Solution Error Message and Codes System error Restart MFP. If this error persists, call service MFP error. (100111) personnel for help. Call service for further help.
Page 84 User’s Guide Please load paper in manual tray Paper empty in the manual tray. (200080). Pick up error. Paper empty, paper jam, or Please check tray 1 (200003). pickup failed in tray 1. Tray 1 paper empty. Please load paper to tray1 (200081) IP conflict (500000).
Page 85 Troubleshooting The Full page feature does not support N in 1 Full page not support N in 1 (2 in 1 or 4 in 1). The Custom Zoom feature does not support Custom zoom not support N in 1 N in 1 (2 in 1 or 4 in 1). Paper Jam ADF paper jam (002013).
Page 86 User’s Guide Locations of the Jammed Paper Front Cover: Open the front cover Rear Cover: Open the rear cover by by pulling the handles of the front pulling the handle of the rear cover as cover on both sides as illustrated. shown.
Page 87 Troubleshooting Fuser: The area around the fuser is hot. To avoid a burn injury, be careful not to touch the fuser until it cools down and follow these steps to remove the jammed paper: Open the Front Cover and the Pull down the Fuser Path as Rear Cover.
Page 88 User’s Guide Possible Causes or Solution Error Message and Codes Runtime error Restart MFP. If this error persists, call service personnel for Error (Number). help. Write Data Smaller Error -Engine 201516 Black LPH Type Error 201631 Red LPH Type Error 201632 MFP LPH Error，LPH cable connection fails.
Page 89 Troubleshooting 300202 MFP FLASH_CHIP_ERASE_FAILED 300203 MFP FLASH_PROGRAM_FAILED 302651 Network_INIT_FAIL , network initialization fails. Image Problem Troubleshooting Problem Image Example Solution Use paper of standard weight: If you are using thin paper, try to use paper of standard weight (70 Use paper with less moisture: Load Paper curls the paper to the paper tray immediately after removing them...
Page 90 User’s Guide Vertical white lines Call the service personnel for help. Vertical black Please clean the EP charger according to lines the procedure described in this manual (p. 102). Dirty Check if toner is not leaked from the background(pa toner cartridge. If so, replace the toner rtial page) cartridge.
Page 91 Troubleshooting Defective image Use a clean and soft cloth to wipe of regular the off the dust or particle on the interval drum unit. (See page 98) If the error occurs again, contact the service personnel. If you have observed a rougher texture on one side of your paper, try printing on the Loose toner...
Page 92 No. 20, Creation Road I, Science-Based Industrial Park, Hsinchu 300, Taiwan, ROC TEL: +886 (3) 578-2388 FAX: +886 (3) 577-7017 E-MAIL: service@avision.com.tw Web Site: http://www.avision.com.tw US and Canada Area Avision Labs, Inc. 6815 Mowry Ave., Newark CA 94560, USA TEL: +1 (510) 739-2369 FAX: +1 (510) 739-6060 E-MAIL: support@avision-labs.com...
Page 93 Maintaining the Product 9. Maintaining the Product Calibrating the Scan Module Calibrate only if the scanned image looks fuzzy, the color looks abnormal (e.g., darker than normal), after more than 8,000 scans, or the scanner has been stored without use for a long time.
Page 94 User’s Guide Calibration Hold the calibration Sheet sheet Only, and do not touch the white area. Important: Hold the calibration sheet Only, and do not touch the white area. The calibration sheet will be feeding into the scan module indicating the calibration is undergoing.
Page 95 Maintaining the Product U sing the Clean Mode 4 5 B From time to time, the Feeding Rollers may be contaminated with ink, toner particles, or paper dust. In this case, the paper may not be fed smoothly. Please follow the following steps to clean the feeding rollers to ensure the best of the scanner.
Page 96 User’s Guide Press the mode button ( ), the tool LED will be flashing three times repeadedly. Press the mode button ( ), the rollers will move forward a little bit automatically. Repeat step 3 and 4 for several time until the surface of the rollers have been completedly cleaned.
Page 97 Maintaining the Product Cleaning the Paper Path Refer to the preceding section to remove the Toner Cartridge. Check if there is paper dust on the Paper Path. If so, remove the dust. Paper Path...
Page 98 User’s Guide Cleaning the IR Sensors If too much paper dust or dust accumulates on the IR sensors, it may cause the misjudgment of paper jam. For example, there is error code of paper jam occurs yet in fact no jammed paper found inside the MFP. In this case, please clean the IR sensor according to the following steps.
Page 99 Maintaining the Product Cleaning the Paper-In Sensors If too much paper dust or dust accumulates on the Paper-in sensors, it may cause the misjudgment of paper jam. For example, there is error code of paper jam occurs yet in fact no jammed paper found inside the MFP. In this case, please clean the Paper-in sensor according to the following steps.
Page 100 User’s Guide Cleaning the Pad in the Cassette If the Pad in the Cassette is smeared with paper powder or dirt or every 30K copies, paper may not feed smoothly or noise occurs during paper feeding. Follow the procedure below to clean the Pad in the Cassette. You need to prepare: cotton swab Remove all paper in the cassette.
Page 101 Maintaining the Product Cleaning the Drum Unit If the drum unit is smeared with paper powder or dirt, the print out may appear defective image of regular interval. Follow the procedure below to clean the drum unit. Turn off the power and remove the power cord from the power outlet. Open the front cover by pulling the handles on both sides as shown.
Page 102 User’s Guide Remove the toner cartridge from the drum unit as shown. Drum unit Toner Cartridge Clean the drum unit with a clean and soft cloth. Clean this area.
Page 103 3,000 pages. When the toner cartridge is running low, you will be prompted with a [Toner Low] message through the MFP monitoring program – [Avision Status Monitor]. Buy a new toner cartridge and have it ready before you receive [Replace Toner] message.
Page 104 User’s Guide Lift the handle of the drum unit and toner cartridge assembly and gently remove the assembly.   Remove the toner cartridge from the drum unit as shown. Drum Toner Cartridge Protective Cover Important! Do not dispose of the toner cartridge. Put the used toner cartridge into the bundled plastic bag, and then return it to a dealer or service representative.
Page 105 Maintaining the Product Installing the Toner Cartridge Unpack the new toner cartridge、and remove the protective cover and tape. Tilt the new toner cartridge up and down and then right and left 10 times to distribute the toner evenly inside the toner cartridge. Install the new toner cartridge to the drum unit.
Page 106 User’s Guide Note: Be sure to return the tab to the Home position (▲). The arrow on the tab must be aligned with the arrow on the drum unit. If it is not, printed pages may have a vertical stripe. Hold the handle of the toner cartridge assembly and insert the toner cartridge assembly to its original place.
Page 107 12,000 pages. When the drum unit is running low, you will be prompted with a [Drum Unit Low] message through the MFP monitoring program – [Avision Status Monitor]. Buy a new toner cartridge and have it ready before you receive [Replace Drum Unit] message.
Page 108 User’s Guide Remove the toner cartridge from the drum unit as shown. Drum unit Toner Cartridge...
Page 109 Maintaining the Product Installing the Drum Unit Remove the protective film and the label in the center of the drum unit. Be sure not to touch the drum during unpacking. Your finger print may affect the print quality. Label Black Film Install the toner cartridge to the new drum unit.
Page 110 User’s Guide Note: If toner gets on your clothing or other fabric, wipe off the toner  with a dry cloth. Wash the items in cold water and air dry. Do not dispose of the toner cartridge. Put the used toner cartridge ...
Page 111 Specifications 10. Specifications All specifications are subject to change without notice. General Regulatory model number AXH2030, AXH2030N, AXH2030NW Processor 500MHz 512M Flash Memory 512M Max media size Legal size Resolution 600 × 600 dpi Printing speed 30 ppm First print out time From Ready Mode 9.5 seconds (A4 SEF) From Sleep Mode...
Page 112 User’s Guide Paper output capacity 150 pages Duplex printing unit Build-in A4, Letter, B5 (JIS) Paper size Duplex print Paper weight 60~105 g/m² (16~28 lbs) USB2.0，10/100Mbps Ethernet Connectivity Wi-Fi (For the model includes Wi-Fi module) MFP language Supported operation system Windows 7, Windows 8, Windows 10 <=Mac OS 10.11 Dimemsion (WxDxH)
Page 113 Specifications Wi-Fi Spec. Model: CF-WU810N Main Chipset RTL8188EUS Host interface USB 2.0 Frequency Range 2.412~2.484 GHz IEEE 802.11b Wi-Fi Standard IEEE 802.11g IEEE 802.11n 11b: 1/2/5.5/11 Mbps Transmit Speed 11g: 6/9/12/24/36/48/54 Mbps 11n: 150 Mbps Transmit Power Max. 18 dBm WPA-PSK/WPA2-PSK Security WPA/WPA2...
