Operating instructions Power supply 160 mA Art. no. 60031020 Power supply 320 mA Art. no. 60032020 Power supply 640 mA Art. no. 60033020 Power supply 1280 mA Art. no. 60034020 Insta GmbH Postfach 1830 58468 Lüdenscheid Germany Telefon +49 (0) 2351 936-0 www.insta.de...
Power supplies Safety instructions Electrical devices may only be mounted and connected by electrically skilled persons. Serious injuries, fire or property damage possible. Please read and follow manual fully. Danger of electric shock. During installation and cable routing, comply with the regu- lations and standards which apply for SELV circuits.
Power supplies Connection of mains LED Betrieb, green On: Normal operation Flashes: Overload or overvoltage Off: No mains voltage or internal error LED Überlast, red On: Overload or short-circuit on KNX bus line or output DC 30 V LED Überspannung, yellow On: Overvoltage on KNX bus line or output DC 30 V Output DC 30 V Output Bus for KNX bus line...
Power supplies – No-load proof – Suitable for operation in systems with emergency power supply – Potential-free signal contact for operating and diagnostic message – Two identical power supplies can be connected in parallel (with the versions 160 mA, 320 mA and 640 mA) Operation Acknowledging the diagnostic message After detecting a overvoltage or a short circuit the LED and the signal contact signal...
Power supplies Resetting the bus line for 20 seconds ■ Press the Reset button (8) between 2 ... 4 seconds. The bus line is short-circuited for 20 seconds. The LED Reset (7) flashes quickly. After 20 seconds the bus voltage is switched on again and the LED Reset switches off.
Page 7
Power supplies Connecting the device to mains voltage and bus Image 3: Wiring example – mains voltage and bus line Image 4: Clampable conductor cross-section ■ Connect the mains voltage to the terminals L and N (1). Connect the protective conductor PE to the terminal Ʈ. ■...
Page 8
Power supplies Connecting the diagnostic analyser The voltage supply signals overvoltage, overload, short circuit and KNX voltage fail- ure using a floating contact (9). A monitoring device can detect the switching status and forward it for diagnostic purposes. The signal output serves only for signalling purposes and may not be used as a load output.
Page 9
Power supplies Image 6: Application example – KNX binary input on main line for detecting and cent- rally signalling diagnostic messages Observe the wiring! Install the cables for the signal contact such that no loops are created. During operation loops can cause interference voltages to be coupled into.
The device is operable in the range of 180 V AC … 264 V AC. Mains frequency 50 / 60 Hz Power loss (max. load on all outputs) Art. no. 60031020 max. 1.5 W Art. no. 60032020 max. 1.8 W Art. no. 60033020 max.
