Mack V-MAC IV Operator's Handbook Manual

Vehicle management and control with co-pilot display
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
E
L
E
C
T
R
O
N
I
C
V-MAC IV
VEHICLE MANAGEMENT
AND CONTROL WITH
CO-PILOT DISPLAY
22196032
© Mack Trucks, Inc. 2014
Printed in U.S.A.
https://truckmanualshub.com/
E
L
V-MAC IV
VEHICLE MANAGEMENT
AND CONTROL WITH
CO-PILOT DISPLAY
22196032
January 2014
E
C
T
R
O
N
I
C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-MAC IV and is the answer not in the manual?

Questions and answers

Summary of Contents for Mack V-MAC IV

  • Page 1 V-MAC IV V-MAC IV VEHICLE MANAGEMENT VEHICLE MANAGEMENT AND CONTROL WITH AND CONTROL WITH CO-PILOT DISPLAY CO-PILOT DISPLAY 22196032 22196032 © Mack Trucks, Inc. 2014 January 2014 Printed in U.S.A.
  • Page 2 https://truckmanualshub.com/...
  • Page 3 2014 Mack Trucks, Inc., Greensboro, NC USA All rights reserved. No part of this publication may be reproduced, stored in retrieval system, or transmitted in any forms by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of Mack Trucks, Inc.
  • Page 4 https://truckmanualshub.com/...

  • Page 5: Table Of Contents

    https://truckmanualshub.com/ Contents Introduction........................1 SAFETY INFORMATION....................2 Service Procedures and Tool Usage................3 V-MAC Co-Pilot Operator's Manual................7 SYSTEM OVERVIEW....................7 System Summary .......................7 SYSTEM COMPONENTS....................9 Vehicle Electronic Control Unit (VECU) ..............9 Engine Control Module (ECM) ................11 INDICATORS, LIGHTS AND DASHBOARD SWITCHES ........17 Cab and Dashboard Switches...................17 Electronic Malfunction Indicator................19 High Exhaust System Temperature (HEST) Indicator..........20 Shutdown Warning Indicator ...................21...
  • Page 6 Up & Down Buttons ....................82 CO-PILOT® LAYOUT ....................83 Screen Types ......................83 Driver's ID Screens ....................84 Change Driver ID.....................88 CO-PILOT® START UP SCREENS ................90 MACK Logo Intro ....................90 Theft Deterrent......................91 GuardDog™ Status ....................92 Compass Screen .......................93 Current Conditions....................94 CO-PILOT® MENU SCREENS .................95 Main Menu —...
  • Page 7 https://truckmanualshub.com/ Fleet Management....................102 Diagnostics......................104 Maintenance......................106 DEL Messages .......................109 Set Up........................110 CO-PILOT® INTERRUPT SCREENS..............111 Idle Shutdown Warning ..................111 Driver Overspeed Warning (if Available) .............. 111 Warning Severe Engine Overspeed................112 Engine Brake Overspeed Warning.................112 Severe Engine & Engine Brake Overspeed Warning..........113 Maintenance Reminder (for Future Support)............114 GuardDog™...
  • Page 8 https://truckmanualshub.com/...

  • Page 9: Introduction 1

    No part of this publication may be reproduced, stored in a retrieval system, or be transmitted in any form by any means including (but not limited to) electronic, mechanical, photocopying, recording, or otherwise without prior written permission of MACK TRUCKS, Inc.

  • Page 10: Safety Information

    https://truckmanualshub.com/ Introduction SAFETY INFORMATION IMPORTANT: Before driving this vehicle, be certain that you have read and that you fully understand each and every step of the driving and handling information in this manual. Be certain that you fully understand and follow all safety warnings.

  • Page 11: Service Procedures And Tool Usage

    https://truckmanualshub.com/ Introduction 3 Service Procedures and Tool Usage Anyone using a service procedure or tool not recommended in this manual must first satisfy himself thoroughly that neither his safety nor vehicle safety will be jeopardized by the service method he selects. Individuals deviating in any manner from the instructions provided assume all risks of consequential personal injury or damage to equipment involved.
  • Page 12 https://truckmanualshub.com/ Introduction DANGER WARNING Before starting a vehicle, always When working on a vehicle by using be seated in the driver's seat, place wireless communication units, it is not the transmission in neutral, apply always apparent to others that work the parking brakes, and push in the is in progress on the vehicle.
  • Page 13 https://truckmanualshub.com/ Introduction 5 CAUTION CAUTION When regeneration occurs, the When the inhibit position is pressed, temperature of the exhaust will be the DPF switch will remain in a locked elevated. DO NOT park the vehicle position. It is important, therefore, to with the exhaust outlet under low immediately set the switch back to the hanging overhead flammable objects...
  • Page 14 https://truckmanualshub.com/ Introduction Every possible occurrence that may involve a potential hazard cannot be anticipated. Accidents can be avoided by recognizing potentially hazardous situations and taking necessary precautions. Performing service procedures correctly is critical to technician safety and safe, reliable vehicle operation. The following list of general shop safety practices can help technicians avoid potentially hazardous situations and reduce the risk of personal injury.

  • Page 15: V-Mac Co-Pilot Operator's Manual

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 7 SYSTEM OVERVIEW System Summary The vehicle management and control (V-MAC) IV System is an electronic engine control system consisting of the following major components: • Engine Control Module (ECM) • Gauge Driver Module GDM (MRU and LEU models only) •...
  • Page 16 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual To enable vehicle management and control (V-MAC) IV to perform its engine management and control functions, the following sensors provide information to the system. • Interior Cab Temperature Sensor (Optional) • Engine Oil Level (EOL) Sensor •...

  • Page 17: System Components

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 9 SYSTEM COMPONENTS Vehicle Electronic Control Unit (VECU) The Vehicle Electronic Control Unit (VECU) is mounted underneath panel D as shown in . (CHU/CXU/GU model shown.) The Vehicle Electronic Control Unit (VECU) is an electronic control module which provides a wide variety of functions including: •...
  • Page 18 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual C0035359 VECU...

  • Page 19: Engine Control Module (Ecm)

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 11 Engine Control Module (ECM) The Engine Control Module (ECM) is located to the left side of the engine and is mounted to the fuel cooler, which is mounted beneath the inlet manifold (see graph reference).
  • Page 20 V-MAC Co-Pilot Operator's Manual C0035360 Engine Control Module (ECM) (MACK MP7)
  • Page 21 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 13 Instrument Cluster The vehicle management and control (V-MAC) IV Instrument Cluster is a one-piece unit composed of gauges and an information display. The Instrument Cluster receives information from the VECU and EECU and then sends information back to the VECU and EECU.
  • Page 22 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual W3036315 Instrument Cluster Module...
  • Page 23 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 15 Gauge Driver Module (GDM) The vehicle management and control (V-MAC) IV (GDM) is a black box controller used in the LEU and MRU model chassis. The GDM contains a warning light bar, an hour meter located in the tachometer and an odometer located in the speedometer. A separate push button is available to toggle through different functions such as to retrieve fault codes and view trip information.
  • Page 24 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual C0035357 Figure 6 — Location of GDM (Passenger Side Against Back of Cab) C0035431 Figure 7 — Location of GDM...

  • Page 25: Indicators, Lights And Dashboard Switches

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 17 INDICATORS, LIGHTS AND DASHBOARD SWITCHES Cab and Dashboard Switches Various functions of the vehicle management and control (V-MAC) IV system are controlled by the operator through switches located on the dashboard (CHU/CXU/ GU model shown in Figure 8). These functions include: •...
  • Page 26 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual W2076077 Figure 8 — Cab and Dashboard Switches (Example)

  • Page 27: Electronic Malfunction Indicator

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 19 Electronic Malfunction Indicator The electronic malfunction indicator, amber in color, illuminates to alert the driver of an electrical problem with the vehicle management and control (V-MAC) IV system. The vehicle management and control (V-MAC) IV system does a self-test when the ignition key is turned to the ON position.

  • Page 28: High Exhaust System Temperature (Hest) Indicator

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual High Exhaust System Temperature (HEST) Indicator The High Exhaust System Temperature (HEST) indicator, amber in color, illuminates to alert the driver when engine exhaust gas temperatures (EGT) are high. The HEST indicator will also illuminate during a aftertreatment diesel particulate filter (DPF) parked regeneration event and will turn off after the regeneration is completed and the exhaust EGT has returned to normal.

  • Page 29: Shutdown Warning Indicator

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 21 Shutdown Warning Indicator The Shutdown Warning indicator, red in color, illuminates if the engine coolant level (ECL) is below the minimum level allowed, the engine oil pressure (EOL) is below the minimum allowed, the engine coolant temperature (ECT) or aftertreatment diesel particulate filter (DPF) soot level trigger are above the maximum allowed.

  • Page 30: Engine Derate

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Engine Derate For some conditions (see table below), an engine derate can occur first and if a condition worsens, then an engine shutdown can occur. INDI- ENGINE ENGINE DERATE CATOR CONDITION SHUTDOWN LIGHTS Intake Manifold Derate starts at 120°C (248°F).
  • Page 31 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 23 INDI- ENGINE CATOR ENGINE DERATE CONDITION SHUTDOWN LIGHTS Engine Oil Derate starts with 10% derate Engine Amber malfunction Temperature at 129°C (264.2°F) or more shutdown if indicator (EOT) for 75% of a 4 second period. temperature lights when At 132°C (269.6°F) a 100%...

  • Page 32: Idle Shutdown Override Switch

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Idle Shutdown Override Switch The idle shutdown override switch permits the operator to override an idle shutdown. W2076075 Figure 13 — Panel Idle Shutdown Override Switch Aftertreatment DPF Smart Switch W2076076 Figure 14 — Aftertreatment DPF Smart Switch...
  • Page 33 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 25 The aftertreatment diesel particulate filter (DPF) smart switch is a three-position rocker switch where the UP position is momentary, the MIDDLE position is neutral (standby mode) and the DOWN position is locked. The switch allows the operator to interface with the vehicle's exhaust aftertreatment system.

  • Page 34: Exhaust Aftertreatment System

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual EXHAUST AFTERTREATMENT SYSTEM Aftertreatment DPF Regeneration A DPF in the exhaust is used to meet environmental protection agency (EPA) requirements to help reduce soot and particulate emissions into the atmosphere. The particulates are typically removed by collecting in a DPF, with continuous or periodic regeneration of the filter.

  • Page 35: Aftertreatment Dpf Passive Regeneration

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 27 Aftertreatment DPF Passive Regeneration Aftertreatment diesel particulate filter (DPF) passive regeneration can be automatic (no operator input needed to start regeneration) or manual (operator input needed to start regeneration). The operator is notified that a regeneration is needed when the icons on the DPF Smart switch illuminate.

  • Page 36: Aftertreatment Dpf Parked Regeneration

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Aftertreatment DPF Parked Regeneration Aftertreatment diesel particulate filter (DPF) parked regeneration allows the operator to start and/or stop the regeneration manually when the vehicle is parked. The operator is notified that a regeneration is needed when the icons on the DPF Smart switch illuminate.

  • Page 37: Aftertreatment Dpf Inhibit/Stop Regeneration

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 29 Aftertreatment DPF Inhibit/Stop Regeneration Aftertreatment diesel particulate filter (DPF) regeneration, whether the moving or parked variety, can be stopped if the vehicle is equipped with a DPF Smart switch (refer to “Aftertreatment DPF Smart Switch”, page 24 for more information). A regeneration should be stopped only when necessary.
  • Page 38 https://truckmanualshub.com/ AFTERTREATMENT DPF PASSIVE REGENERATION (AUTOMATIC) Soot Load Level 1 Level 2 Level 3 Level 4 Level Indicators (Amber) (Solid) (Flashing) (Flashing) (Flashing) (Red) Aftertreatment Regeneration needed. Regeneration is Aftertreatment System Service Required. Aftertreatment System Service Required. System DPF is becoming full. required.
  • Page 39 https://truckmanualshub.com/ AFTERTREATMENT SYSTEM PASSIVE REGENERATION (AUTOMATIC) Soot Load Level 1 Level 2 Level 3 Level 4 Level Action to Take Continue to drive or Continue to drive or Perform a parked manual regeneration A serious engine problem has occurred. park the vehicle in park the vehicle in IMMEDIATELY to avoid further engine Seek service immediately.
  • Page 40 https://truckmanualshub.com/ AFTERTREATMENT SYSTEM PASSIVE REGENERATION (MANUAL) (IF AVAILABLE) Soot Load Level 1 Level 2 Level 3 Level 4 Level Indicators (Solid) (Amber) (Red) (Flashing) (Flashing) (Flashing) Aftertreatment Regeneration needed. Regeneration is Aftertreatment System Service Required. Aftertreatment System Service Required. System DPF is becoming full.
  • Page 41 https://truckmanualshub.com/ AFTERTREATMENT SYSTEM PASSIVE REGENERATION (MANUAL) (IF AVAILABLE) Soot Load Level 1 Level 2 Level 3 Level 4 Level Action to Take Continue to drive and Continue to drive or Perform a parked manual regeneration A serious engine problem has occurred. press and hold the park the vehicle in IMMEDIATELY to avoid further engine...
  • Page 42 https://truckmanualshub.com/ AFTERTREATMENT SYSTEM PARKED REGENERATION (MANUAL) Soot Load Level 1 Level 2 Level 3 Level 4 Level Indicators (Amber) (Red) (Solid) (Flashing) (Flashing) (Flashing) Aftertreatment Regeneration needed. Regeneration is Aftertreatment System Service Required. Aftertreatment System Service Required. System Aftertreatment Diesel required.
  • Page 43 https://truckmanualshub.com/ AFTERTREATMENT SYSTEM PARKED REGENERATION (MANUAL) Soot Load Level 1 Level 2 Level 3 Level 4 Level Action to Take Park the vehicle in Park the vehicle in Perform a parked aftertreatment diesel A serious engine problem has occurred. a safe location away a safe location away particulate filter (DPF) regeneration Seek service immediately.
  • Page 44 https://truckmanualshub.com/ AFTERTREATMENT SYSTEM PARKED REGENERATION (MANUAL) Aftertreatment If parked manual aftertreatment diesel particulate filter (DPF) regeneration is allowed to run, the following normal processes may be diesel particulate observed. filter (DPF) regeneration • Engine speed (RPM) will ramp up to around 1,100 RPM and stay there until the DPF regeneration process is Condition complete.** •...

  • Page 45: Aftertreatment Driver Warning And Inducement

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 37 Aftertreatment Driver Warning and Inducement Aftertreatment DEF Tank Level - Driver Warning & Inducement Aftertreatment DEF tanks are sized to have no less than two times the diesel fuel tank mileage or one hour range. The vehicle instrument cluster has an aftertreatment DEF tank level gauge.
  • Page 46 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Triggers Aftertreatment DEF Driver Information Tank Low Level Display Screen Indicator DEF tank empty and refueling Refill DEF Tank event with parking brake Vehicle Speed Limited applied to 5 Mph W2029415 Vehicle Stationary for 20 Refill DEF Tank minutes or Engine re-start Vehicle Speed Limited...

  • Page 47: Aftertreatment Def Quality - Driver Warning & Inducement

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 39 Aftertreatment DEF Quality - Driver Warning & Inducement Triggers Aftertreatment DEF Driver Information Quality Indicator Display Screen Good DEF Quality None None Poor DEF Quality DTC SCR Performance Low Initial Detected Engine will Derate in ___ mins Poor DEF Quality DTC SCR Performance Low...
  • Page 48 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Triggers Aftertreatment DEF Driver Information Quality Indicator Display Screen Refueling Event with Parking SCR Performance Low Brake ON Service SCR System Veh Speed Limited to 5 Vehicle Stationary for 20 SCR Performance Low minutes or Engine re-start Service SCR System (Key OFF, Key ON) Veh Speed Limited to 5...

  • Page 49: Aftertreatment Tampering - Driver Warning & Inducement

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 41 Aftertreatment Tampering - Driver Warning & Inducement When the SCR tampering fault is active for one or more hours a new Driver Information Display screen appears. The text changes for the Driver Information Display (DID) screen associated with this fault are listed in the table below. Triggers Aftertreatment Driver Information...
  • Page 50 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Triggers Aftertreatment Driver Information Tampering Indicator Display Screen Driving with Active Fault for SCR System Fault + 1 hrs Engine In Derate 5 Mph Limit in ___ mins W3031200 Note: Once this SCR tampering fault occurs the DID timer displays.

  • Page 51: Misfilling Diesel Or Aftertreatment Def Tanks

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 43 SCR Sensor Disconnected Tampering Type Exhaust Temperature Sensors Disconnected Aftertreatment Control Module (ACM) Disconnected Aftertreatment NOx Sensor Disconnected Aftertreatment NOx Sensor Disconnected DEF Pump Disconnected DEF Dosing Valve Disconnected DEF Tank Level Sensor Disconnected DEF Supply Line to DEF Pump Disconnected DEF Return Line Blocked or Plugged Misfilling Diesel or Aftertreatment DEF Tanks...

  • Page 52: Aftertreatment Dpf Regeneration And Pto Operation

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Aftertreatment DPF Regeneration and PTO Operation For aftertreatment diesel particulate filter (DPF) regeneration to occur, enough heat must be generated in the diesel oxidation catalyst (DOC). Heat is generated by increasing engine speed (RPM) to around 1,100 RPM on vehicles with a catalyzed aftertratment system.

  • Page 53: Aftertreatment Dpf Regeneration And Pto Engaged

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 45 C0035440 Figure 21 — Minimum Engine Speeds for MP7 with Cat DPF Vehicle 21173561 Note: Beginning with 21198958 and newer software, the only requirement for aftertreatment diesel particulate filter (DPF) regeneration on vehicles equipped with an MP7 with non-catalyzed DPF and PTO is no less than 650 RPM.

  • Page 54: Aftertreatment System Conditioning (Periodic Heat Mode)

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Aftertreatment System Conditioning (Periodic Heat Mode) During periods of extended idling (typically 8 or more hours), the aftertreatment system will accumulate unburned hydrocarbons that are released from a diesel engine. Accumulation of these hydrocarbons can oxidize in the aftertreatment system and can cause damaging temperature spikes and potential hardware failures upon resumed driving or during aftertreatment DPF stationary regeneration events.

  • Page 55: Aftertreatment System Conditioning And Pto Operation

    The engine must be allowed to idle as normal. If prolonged engine idling is necessary, it is recommended that the ECM be programmed with California Air Resources Board (CARB) 2010 compliant files. Please refer to the Emission Control Systems for MACK Class 8 Diesel Engines (MACK MP7 and MP8 Engines) manual for more information.

  • Page 56: Starting The Vehicle

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual STARTING THE VEHICLE The following procedure is used to start and warm up a vehicle management and control (V-MAC) IV engine during any ambient air temperature (AAT) condition: Note: Release the clutch and make sure the transmission is in neutral before starting the engine.

  • Page 57: Cruise And Engine Speed Control

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 49 CRUISE AND ENGINE SPEED CONTROL With vehicle management and control (V-MAC) IV, the operator has the ability to precisely control engine speed (RPM) and set cruise control speeds, as well as setting the engine low idle speed. These functions are performed by using the speed control switches located on the dashboard.

  • Page 58: Cruise Control

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Cruise Control DANGER DO NOT use the cruise control in heavy traffic, with ice/snow on the road or during other unfavorable conditions. This may lead to a loss of vehicle control, causing a vehicle crash, personal injury or death.
  • Page 59 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 51 Once the above conditions are satisfied, activate the cruise control as follows. 1 Move the Speed Control ON/OFF switch to the ON position. 2 At the desired road speed, press and release the SET switch. The vehicle will maintain at the set speed.
  • Page 60 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Accelerating to a Higher Speed To accelerate to a higher speed, three methods are available: 1. Press the accelerator pedal (AP). This method will accelerate the vehicle for as long as the pedal is pressed. (Release the pedal to return to the speed set previously.) 2.
  • Page 61 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 53 Disengaging Cruise Control To disengage cruise control, use any one of the following methods: 1 Apply the service brake. This method will disengage the cruise control while maintaining the set speed in the system memory. To resume the previously set speed, press and release the RESUME switch.

  • Page 62: Engine Speed Control

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Engine Speed Control Engine Speed Control Operation The vehicle management and control (V-MAC) IV system also allows the operator to set and maintain increased engine speeds. The system provides two different speed control functions: Electronic Hand Throttle control and PTO control. electronic hand throttle (EHT) controls engine speed when PTO is not engaged.
  • Page 63 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 55 Variable Speed Control (VSC) To use the variable speed control functions, the following conditions must be met: 1 The clutch must be engaged. 2 The park brake must be set. To activate VSC, move the Speed Control switch to the ON position. Increase engine RPM using the accelerator pedal (AP).
  • Page 64 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Maximum Engine Speed Limit This mode allows the maximum engine speed (RPM) to be limited, based on preprogrammed speeds, when PTO or Electronic Hand Throttle (EHT) controls are engaged. The engine will not operate beyond these speeds when the control (PTO or EHT) is engaged.

  • Page 65: Manual Soft Top

    V-MAC Co-Pilot Operator's Manual 57 Manual Soft Top In accordance with 2014 US Green House Gas regulations, MACK Trucks Inc. is offering optional tamper resistant Vehicle Speed Limits (VSL) with customer selectable configuration. If a vehicle is configured as a soft top vehicle, it will have an additional vehicle speed limit called Soft Top Speed Limit (STSL) which is higher than the Default Speed Limit (DSL).
  • Page 66 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Enabling / How to use Cruise control is engaged and the vehicle is cruising at the DSL speed Available Time is above zero Accelerator Pedal is pressed The vehicle will accelerate above DSL. A pop up will be shown indicating that soft top is active and the amount of minutes that are available will start decreasing.
  • Page 67 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 59 Operation Example: The driver should check the settings in the cluster of his vehicle as this is just an example. DSL = 93.3 km (58mph) STSL = 120 km (75mph) Exp Mileage = 804672 km (500000 miles) Allowed Time Per Day = 50 minutes At the start of the soft top operation, let’s say there are 20 minutes of soft top operation accumulated in the soft top bank.
  • Page 68 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual W3082726 W3082727...

  • Page 69: Engine Brake

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 61 Engine Brake W2076080 Figure 26 — Engine Brake Switch To activate the engine brake, move the engine brake switch to the 1st or 2nd ON position. The 1st position activates the engine brake unit for 50% power. The 2nd position provides 100% power.

  • Page 70: Programmable Features

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual PROGRAMMABLE FEATURES The vehicle management and control (V-MAC) IV system allows operating parameters of certain system functions to be programmed. These functions include the following: • Audible Alarm • Auto Start (iTAS) [Optional; Future Support] •...

  • Page 71: Cruise 'N Brake Engagement Delay

    (V-MAC) IV system. Note: If the rear tire sizes are changed, or the rear axle ratios are changed, you must contact your local MACK TRUCKS dealer. Failure to notify your local MACK TRUCKS dealer of these changes may cause inaccurate speedometer readings.

  • Page 72: Low Idle Adjustment

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Low Idle Adjustment Note: On chassis equipped with an automatic transmission, the speed control switches cannot be used to adjust engine low idle speed. Attempting to set low idle in this manner will cause the vehicle electronic control unit (VECU) to enter the reprogramming mode resulting in the idle speed dropping to 550 RPM (650 RPM for non-catalyzed exhaust aftertreatment system), but it will not be possible to set a new idle speed.

  • Page 73: Smart Idle Elevated Idle Rpm Time

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 65 W2076074 Figure 27 — Speed Control Switches Note: If the idle speed does not drop to 550 RPM after meeting the requirements listed, there may be other possible problems which will not allow the idle to be reset.

  • Page 74: Idle Shutdown

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Idle Shutdown This feature will shut off the engine after it has been idle for a specified period. The time period is customer programmable using the VCADS software. An alarm will warn 30 seconds (a programmable time frame) before the engine will shut down. The idle shutdown override switch can be used during this 30 second period to override idle shutdown or the service brake or accelerator pedal (AP) can be applied.

  • Page 75: Idle Cooldown

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 67 Idle Cooldown This feature provides a means of cooling down the engine and turbocharger. If the idle cooldown option is enabled using VCADS software and the system senses that the turbocharger may be hot, the engine will not shut down when the vehicle stops, the parking brake is set and the ignition key is turned to the OFF position.

  • Page 76: Fan Override Switch (Optional)

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Fan Override Switch (Optional) With the fan override switch, the operator has the option of overriding the preset parameters for fan engagement to engage the fan when necessary. The fan may be engaged while the vehicle is moving or while parked. Enabling the fan override option, and the parameters for override time limits, are customer programmable using a personal computer running the VCADS software.

  • Page 77: Daytime Running Lights (Drl) Override Switch (Optional)

    Daytime Running Lights (DRL) Override Switch (Optional) Daytime Running Lights (DRL) come standard on all MACK vehicles and can be optioned with or without an override switch. When the DRL override switch has been specified, different conditions can be selected that cause the DRL to automatically activate.

  • Page 78: Integrated Temp-A- Start (Optional; For Future Support)

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Integrated Temp-A- Start (Optional; For Future Support) Integrated Temp-A-Start (i TAS) is a fully integrated vehicle management and control (V-MAC) IV system designed to improve fuel economy by reducing unnecessary engine idling. When i TAS is enabled via a dash switch, the system will automatically start and stop the engine to maintain a minimum engine coolant temperature (ECT), minimum battery voltage, or a comfortable cab and sleeper interior.

  • Page 79: Electrical Accessory Connection Points

    V-MAC Co-Pilot Operator's Manual 71 ELECTRICAL ACCESSORY CONNECTION POINTS This MACK chassis is electrically ready for convenient installation of electrical accessories. Use the designated battery post (+12 V), ground post, CB jack, buffered RPM outputs, buffered mi/h outputs, and the SAE/ATA J-1708 post located on the electrical equipment panel for the installation of any electrical accessories.

  • Page 80: Mi/H Output

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Mi/h Output This is a 50% duty cycle, 5-volt TTL-compatible, square-wave signal that is calibrated to provide a standard pulse rate of 30,000 pulses per mile. Note: TTL compatibility of this output may be affected by other devices connected to this output.

  • Page 81: Instrument Cluster Display

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 73 INSTRUMENT CLUSTER DISPLAY The instrument cluster display is an in-dash component that lets the driver monitor information supplied by vehicle management and control (V-MAC) IV and also permits the driver to change functions to accommodate his needs. The instrument cluster display is user friendly and prompts the driver with messages on the driver information display.

  • Page 82: Instrument Cluster Components

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Instrument Cluster Components The dash cluster consists of the following eight major components: function light indicators, electronic malfunction indicator, engine shutdown indicator, driver information display, low fuel indicator, gauges, speedometer and tachometer, on board diagnostic (OBD) fault and warning indicators. Although not a part of the dash cluster components, but nevertheless part of the dash cluster tool, is the stalk switch (for Co-Pilot®...

  • Page 83: Driver Information Display

    V-MAC Co-Pilot Operator's Manual 75 Driver Information Display There are two types of driver information displays available for MACK TRUCKS vehicles: basic display or Co-Pilot® Display. The basic display provides limited information (current conditions, trip information and diagnostic information). The Co-Pilot®...

  • Page 84: Co-Pilot® Display

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual CO-PILOT® DISPLAY Introduction and Purpose The Co-Pilot is an in-dash computer that lets the vehicle operator monitor information supplied by the vehicle management and control (V-MAC) IV electronic control system and enhance the functions of V-MAC by entering requested information with the stalk switch.

  • Page 85: Co-Pilot System Overview

    Many Co-Pilot features and functions listed in this Operator's Guide can be customized to meet individual company or operator needs. V-MAC can easily be programmed by the dealer or customer using MACK's scan tool with VCADS software to make these features available through the Co-Pilot.
  • Page 86 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Table 4 Programmable Co-Pilot Features Feature Function/Selections Factory Default Settings Bill of Lading Enter in Bill of Lading number Change Driver Change to a new Driver Enabled Drain Water (optional and for Drains the sediment bowl Enabled automatically if the possible future support) automatically from menu...
  • Page 87 1. Time 7. Engine Brake 2. Mileage 8. Maintenance 3. Ambient Air Temp (AAT) 9. Overspeed/Idle 4. Information Area 10. Gear (with automated transmission) 5. Sweet Spot Indicator 11. Active Cruise Control 6. Bonus/Penalty 12. MACK Road Stability Advantage Target Detected...
  • Page 88 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual The stalk switch (for Co-Pilot® display only) is located on the right side of the steering column and contains three depressible buttons: ESC, Enter (↵ ↵ ↵ ) and Up & Down. The stalk switch is used to access, navigate, view and change information available in the driver information display (Co-Pilot®...

  • Page 89: Co-Pilot® Operations

    When the ignition key is turned to the ON position, the Co-Pilot® automatically turns on. The MACK Logo Intro screen appears for several seconds and is usually followed by the last Anytime screen that was active prior to power-down. If Vehicle Management and Control (V-MAC) IV is programmed to “get driver”...

  • Page 90: Co-Pilot System Overview

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual CO-PILOT SYSTEM OVERVIEW ESC Button The ESC (Escape) button on the stalk switch takes the Co-Pilot back to the previous screen or level in the menu. Note: The ESC button does not function at Start-Up. Enter (↵...

  • Page 91: Co-Pilot® Layout

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 83 CO-PILOT® LAYOUT Screen Types The Co-Pilot® contains six types of display screens: • Start-Up Screens — A group of screens that appear when the vehicle management and control vehicle management and control (V-MAC) IV system is energized. Individual Start-Up screens are discussed in more detail in .

  • Page 92: Driver's Id Screens

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Driver's ID Screens The following screens allow a driver specific ID to be entered via the Driver Information Display. This option allows various vehicle information to be recorded for the driver associated with the driver ID. The ID can be changed from the Driver Information Display (DID) using the stalk switch control lever.
  • Page 93 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 85 Once the Driver ID has been entered press the Enter button on the stalk switch control lever. The Command Accepted screen displays. Press Enter again. W3067469 If driver does not enter the Driver ID after starting the vehicle the Enter Driver ID screen displays.
  • Page 94 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Once the Driver ID has been entered press the Enter button on the stalk switch control lever. The Command Accepted screen displays. Press Enter again. W3067469 If there is a system issue with confirming the Drivers ID the ERROR Driver Number Not Available screen displays.
  • Page 95 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 87 If driver does not enter the Driver ID the Driver ID not Entered screen displays. The Driver ID should be entered at the next vehicle stop. This screen will display every 30 minutes until the proper ID is entered. There is also an audible warning emitted until the Driver ID is entered as well.

  • Page 96: Change Driver Id

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Change Driver ID To change the current Driver ID, use the Up and Down arrows and Enter button on the stalk switch control lever. From the main DID screen scroll to Fleet Management . Press Enter. Then scroll to Change Driver ID.
  • Page 97 V-MAC Co-Pilot Operator's Manual 89 The Change OK... screen displays. The DID will interface with the Vehicle ECU. Then all information is sent for confirmation via MACK Link to a vehicles main office. The new Driver ID is received and confirmed.

  • Page 98: Co-Pilot® Start Up Screens

    • Compass Screen MACK Logo Intro The MACK LOGO INTRO screen is displayed for six seconds when the vehicle ignition key is turned to the ON position. It is for viewing purposes only. C0035444 Figure 38 — MACK Logo Intro...

  • Page 99: Theft Deterrent

    V-MAC Co-Pilot Operator's Manual 91 Theft Deterrent The THEFT DETERRENT screen, if programmed, will appear after the MACK LOGO INTRO screen. Messages prompt the driver to enter a password. If an incorrect password is entered after a predetermined number of attempts, access is denied and the vehicle will shut down and not allow engine start until the correct password is entered.

  • Page 100: Guarddog™ Status

    V-MAC Co-Pilot Operator's Manual GuardDog™ Status The GUARDDOG™ STATUS screen, if equipped, will appear after the MACK LOGO INTRO screen and the THEFT DETERRENT screen (if programmed). The screen waits to acquire data from the truck and will display maintenance items needing service.

  • Page 101: Compass Screen

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 93 Compass Screen The Compass Screen will appear after the Guard Dog if equipped, The way to enter this is MENU —> Gauges —>VIEW Other Gauges. W3083580...

  • Page 102: Current Conditions

    V-MAC Co-Pilot Operator's Manual Current Conditions The CURRENT CONDITIONS screen will appear after the MACK LOGO INTRO screen or after the THEFT DETERRENT and GUARDDOG STATUS INTRO screens (if equipped and programmed). When the truck is stationary, the time, mileage, outside temperature and battery voltage are displayed.

  • Page 103: Co-Pilot® Menu Screens

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 95 CO-PILOT® MENU SCREENS Main Menu — Stationary Vehicle The MAIN MENU screen consists of two screens for a stationary vehicle: stationary MAIN MENU 1 screen and stationary MAIN MENU 2 screen. To cause the stationary MAIN MENU 1 screen to appear, press and hold the stalk switch Enter (↵...

  • Page 104: Main Menu - Moving Vehicle

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Main Menu — Moving Vehicle The MAIN MENU screen consists of one screen for a moving vehicle: moving MAIN MENU screen. To cause the moving MAIN MENU screen to appear, press the stalk switch Enter (↵ ↵ ↵ ) button when in the CURRENT CONDITIONS screen (see).

  • Page 105: Co-Pilot® Anytime Screens

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 97 CO-PILOT® ANYTIME SCREENS Co-Pilot® Anytime screens include the following main screens: • Fuel Economy • Trip Information • Digital Gauges • Black Panel To navigate through the screens, remember the following: • Use the stalk switch Up & Down button to scroll and highlight an item, scroll to the next screen, or enter a value.

  • Page 106: Trip Information

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Trip Information • The TRIP INFORMATION submenu screen is displayed by selecting Trip Info from the moving MAIN MENU screen (see) or from the stationary MAIN MENU 1 screen (see) and then pressing the Enter (↵ ↵ ↵ ) button. W3036614 Figure 45 —...
  • Page 107 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 99 The following table displays the available LOV trip information. Average Fuel Economy PTO Time Average Vehicle Speed Sweet Spot Time Cruise Time Total Fuel Used Engine Brake Time Vehicle Highest Speed Engine Highest RPM Vehicle Time Idle Time Total Time...

  • Page 108: Gauges

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Gauges The GAUGES submenu screen, selected from the moving MAIN MENU screen (see) or from the stationary MAIN MENU 1 screen (see) provides the speedometer value and sensor information. To view the screens of the Gauges submenu, highlight “Gauges”...

  • Page 109: Black Panel

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 101 Black Panel • The BLACK PANEL screen is used to black out the Co-Pilot® display. Highlight “Black Panel” from the moving MAIN MENU screen or stationary MAIN MENU 1 screen, and then press the stalk switch Enter (↵ ↵ ↵ ) button to select it. •...

  • Page 110: Co-Pilot® Stationary Screens

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual CO-PILOT® STATIONARY SCREENS Co-Pilot® Stationary screens include the following main screens: • Fuel Economy • Trip Information • Digital Gauges • Black Panel • Fleet Management • Diagnostics • Maintenance (if available) • DEL (Driver Event Logging) Messages •...
  • Page 111 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 103 The FLEET MANAGEMENT submenu screen contains the following main screens: • Change Driver W3065134 — Allows the user to change drivers. There are three ways to change driver entries: W3065133 1 Enter driver ID using the stalk switch Up & Down button to type in the driver identification number.

  • Page 112: Diagnostics

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Diagnostics The Diagnostics submenu screen is accessed from the stationary MAIN MENU 2 (see). To view the screens of the DIAGNOSTICS submenu, highlight “Diagnostics” with the stalk switch Up & Down button and then press the Enter (↵ ↵ ↵ ) button to select the screen.
  • Page 113 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 105 W3036629 Figure 52 — Diagnostics Submenu Screens...

  • Page 114: Maintenance

    • Manually through the GuardDog™ Status screen After power-up initiation and the MACK LOGO screen appearance, the Co-Pilot will display the ACQUIRING DATA screen. After activation on this screen, if no maintenance item is due, the GUARDDOG™ NO MAINTENANCE ITEMS DUE screen will appear.
  • Page 115 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 107 C0035403 Figure 54 — GuardDog™ Maintenance Screens Note: The oil level indicator takes between 15 and 20 seconds to provide data. If the engine is started within this time period with no valid oil level reading, the Co-Pilot will display the message, “Unable to obtain the oil level data.
  • Page 116 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Water-in-Fuel (WIF) [if equipped] Allows the user to send a “drain water” command to the EMS module. If the Water in Fuel sensor detects liquid in the water-separator bowl, the WIF indicator on the instrument cluster will illuminate to notify the driver. DPF Inhibit Status Indicates why the aftertreatment diesel particulate filter (DPF) regeneration was not started.

  • Page 117: Del Messages

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 109 DEL Messages The DEL MESSAGES submenu screen is accessed from the stationary MAIN MENU 2 screen (see). The DEL MESSAGES submenu contains a list of driver event logging messages. A driver may choose to log a driver event logging message depending on the driver's activity.

  • Page 118: Set Up

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Set Up The SET UP submenu screen is accessed from the stationary MAIN MENU 2 screen (see). To view the SET UP submenu, highlight “Set Up” with the stalk switch Up & Down button and then press the Enter (↵ ↵ ↵ ) button to select the screen. The SET UP submenu screen contains the following main screens: •...

  • Page 119: Co-Pilot® Interrupt Screens

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 111 CO-PILOT® INTERRUPT SCREENS Idle Shutdown Warning The IDLE SHUTDOWN WARNING screen displays a timer warning and an alarm sounds to inform the driver that the vehicle is going to shut down until the condition goes away or the driver acknowledges the warning by pressing the Enter (↵...

  • Page 120: Warning Severe Engine Overspeed

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Warning Severe Engine Overspeed The WARNING SEVERE ENGINE OVERSPEED screen appears and an alarm sounds when the driver exceeds the Severe Engine Overspeed threshold. This screen is displayed until the driver decelerates below the threshold. W3036653 Figure 61 —...

  • Page 121: Severe Engine & Engine Brake Overspeed Warning

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 113 The WARNING: ENGINE BRAKE OVERSPEED screen is displayed and an alarm sounds if the driver operates the engine speed over the engine brake speed threshold. This screen is displayed until the driver acknowledges the warning and alarm by pressing the Enter button and correcting the situation.

  • Page 122: Maintenance Reminder (For Future Support)

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Maintenance Reminder (for Future Support) The MAINTENANCE REMINDER screen appears and an alarm sounds if a maintenance item, such as engine oil change, becomes due. The screen shows the item needing maintenance and the message “Check Maintenance Log.” If more than one maintenance item becomes due at the same time, the screen becomes scrollable so that the driver can press the Down button on the stalk switch to see other items needing maintenance.

  • Page 123: Low Voltage Disconnect Active

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 115 Low Voltage Disconnect Active The LOW VOLTAGE DISCONNECT ACTIVE screen appears when a low voltage disconnect has been detected by the V-MAC system. The driver should acknowledge this message by pressing the Enter (↵ ↵ ↵ ) button and turn off unnecessary accessory functions that may have caused low voltage.

  • Page 124: Smart Idle Active

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Smart Idle Active The SMART IDLE ACTIVE screen appears to alert the driver that the Smart Idle system is active and will not stop idling until the voltage threshold has been satisfied. The driver should acknowledge the message by pressing the Enter (↵ ↵ ↵ ) button. W3036659 Figure 67 —...

  • Page 125: Priority Message In Road Connect (If Available)

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 117 Priority Message in Road Connect (If Available) The PRIORITY MESSAGE IN ROAD CONNECT screen appears when an important message in the Road Connect system is sent to the driver. The driver should acknowledge the message by pressing the Enter (↵ ↵ ↵ ) button, and read the message at the next scheduled stop.

  • Page 126: Trip Advanced

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual Trip Advanced The TRIP ADVANCED screen appears whenever the driver advances to the next fleet trip. To advance to the next fleet trip, the driver must select “Next Fleet Trip” from the FLEET MANAGEMENT submenu. C0035413 Figure 71 —...

  • Page 127: Warning Screens

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 119 Warning Screens When certain conditions exist, warning screens will appear to alert the driver. For example, if the vehicle has a low fuel quantity, the low fuel indicator will illuminate on the cluster display and the Co-Pilot will display the LOW FUEL WARNING screen. The driver should acknowledge these screens by pressing the Enter (↵...

  • Page 128: Co-Pilot® Optional Systems Screens

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual CO-PILOT® OPTIONAL SYSTEMS SCREENS The vehicle management and control (V-MAC) IV system provides optional functions that the driver can access through the Co-Pilot (if available and enabled). The Co-Pilot Optional Systems screens include the following main screens: •...

  • Page 129: Road Connect* (If Available)

    https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual 121 Road Connect* (if Available) Road Connect* is an advanced fleet management system that uses satellite communication and the Internet to provide uninterrupted truck information. The Road Connect system provides the following main services depending on package selected. •...
  • Page 130 https://truckmanualshub.com/ V-MAC Co-Pilot Operator's Manual W3036663 For more information about Road Connect, please refer to the Road Connect Driver's Handbook (when available). *ROAD CONNECT is a service mark owned by First Advantage Tax Consulting Services, LLC. First Advantage offers a complementary line of fleet management services.

  • Page 131: Co-Pilot® Operations

    When the ignition key is turned to the ON position, the Co-Pilot® automatically turns on. The MACK LOGO INTRO screen (refer to Figure 40) appears for several seconds and is usually followed by the last Anytime screen that was active prior to power-down.
  • Page 132 https://truckmanualshub.com/...
  • Page 133 https://truckmanualshub.com/...

Table of Contents
