Summary of Contents for Arion KRF110-01
- Page 1 Orion Trade Name DRY PUMP Orion Model KRF110-01 Date March.4.2008 APPD ...
- Page 2 Spec.No. KRF110-01E 1. Warranty 1-1. Warranty period The product shall be warranted for a period of one year from the date of purchase, or for 3000 hours of operation, whichever comes first. 1-2. Items exempted from warranty ① Consumable parts and periodic replacement parts. ② ...
- Page 3 Spec.No. KRF110-01E 2.Consumable parts / Periodic replacement parts (1) Consumable parts (Parts to be replaced depending on the state at the time of inspection) Name of Parts Parts Number Qty/ unit Inspection period Replacement criterion To be decided by Replacement of 040028390□0 Liner * When damaged.
- Page 4 Spec.No. KRF110-01E 3. Specifications Model KRF110-01 Frequency Ｈｚ Designed capacity 1850 2200 Ｌ／ｍｉｎ *１ Continuous operative Vacuum and pressure in total: 60 or less ｋＰａ pressure *２ Ultimate vacuum *３ 90or more ｋＰａ Phase・output・pole Three-phase・3.7 ｋＷ・6 Ｐ Necessary power Setting for thermal Rated current shown in the name plate of motor Ａ...
- Page 5 Spec.No. KRF110-01E 4. Precautions Observe precautions, and operate the product within specifications. Read the instruction manual prior to installation, operation, maintenance and inspection of the product. Especially pay attention to safety. The vanes may get damaged if the residual pressure reverses the rotation when the pump stops.
-
Page 6: Pressure Specification
Spec.No. KRF110-01E 6. Pressure-Flow rate diagram KRF110-01 Vacuum Specification (Note) In case exhaust pressure is 0kPa 2000 60Hz 50Hz 1500 1000 Vacuum (kPa) Pressure Specification (Note) In case vacuum is 0kPa 2000 60Hz 1500 50Hz 1000 Exhaust (kPa) Conditions: 1 atmospheric pressure 20℃ −5− ... - Page 7 Detail of shaft shape 4-φ11 ＯＵＴＬＥＴ ＩＮＬＥＴ Ｒｃ１ Ｒｃ１ Ａ Ａ...
