Totevision LCD-641VL User Manual

6.4” rack mounted lcd panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model No.: LCD-641VL
6.4" Rack Mounted LCD Panel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCD-641VL and is the answer not in the manual?

Questions and answers

Summary of Contents for Totevision LCD-641VL

  • Page 1 Model No.: LCD-641VL 6.4” Rack Mounted LCD Panel...
  • Page 2 Key Define: Œ UP: Press this button to increase or decrease the value of the adjustment functions. • DOWN: Press this button to increase or decrease the value of the adjustment functions. Ž ENTER: Press this button for menu adjusting, selecting the menu you want with “UP”...
  • Page 3 * Contrast : Adjust the white color level of the image. * Back Light : Adjust the back level of the panel. * Recall: When you run the function, the monitor will be setting to last status of the saving value.

  • Page 4: Exit Menu

    ---Press “ENTER” button to enter this mode. ---Press “UP” or “DOWN” button to select the desired adjustment item. * Recall All: When you run the function, the monitor will be setting to last. * Exit: Return to last menu. 6. Exit Menu...
  • Page 5 ---Press “ENTER” button to enter this mode. ---Press “UP” or “DOWN” button to select the desired ad adjustment item. * Auto Config: Select “YES” to make the monitor have the best efficiency. * Exit: Return to last menu. 2. Position ---Press “ENTER”...
  • Page 6 Phase Phase * Phase: Adjust the noise of the image. Recall Recall * Recall: When you run the function, the monitor will be Exit Exit * Exit: Return to last meun. 5. Color ---Press “ENTER” button to enter this mode ---Press “UP”...
  • Page 7 Image Mode Select Dithering Select Input Up/Down Right/Left Exit Information Recall Recall All Exit Exit Menu 7. Image ---Press “ENTER” button to enter this mode. ---Press “UP” or “DOWN” button to select the desired adjustment item. * Mode Select: Change DOS mode resolution 640 x 400 or 720 x 350 or 720 x 400 * Dithering: N/A * Select Input: Press to select inputs VGA / S-video /Video...
  • Page 8 Operating Temperature: Storage Temperature: DC Power Supply: Power Consumption: Connectors: Response: Dimensions: LCD-641VL 6.4” (Diagonal) 640 (H) x 480 (V) 0.203 (H) x 0.203 (V) 129.6 (H) x 97.44 (V) R.G. B. Vertical Stripe 300 Nit typ NTSC / PAL (DUAL.CAPABLITY) / SECAM / NTSC4.43...
